Side 1/6

This document is to be used in conjunction with the original manufacturer’s manual.

The symbols correspond with the numbered drawings of the original manual

Contents

05/2024

Fault nding 4

Maintenance 5

Conformity with regulations 6

Introduction 1

Installation 1

Use, safety 2

Cleaning, hygiene and storage 4

1.1

Introduction

1.1 DESCRIPTION

• The automatic French fries cutter is a machine for profesisonal

use that allows obtaining fresh fries of excellent quality and to cut

potatoes in slices.

A Cutter block

B Mobile stainless steel stand (option)

C Polished aluminium body

D Stainless steel feed hopper

E Hopper locking lever

F START button

G STOP button

H Outlet chute

• Thanks to its high output and adapted cutting equipment, the

machine satises the requirements of restaurants, catering

kitchens and food industries.

Installation

2.1

2.1 DIMENSIONS - WEIGHT (For information only)

• Dimensions of packaging:

- machine L x W x H (mm): 755 x 410 x 680

- stand L x W x H (mm): 750 x 500 x 200

• Dimensions of the machine:

- without stand: L x W x H (mm): 670 x 360 x 556

2.2

- with stand: L x W x H (mm): 736 x 458 x 1264

• Weight :

- gross when packaged: 45 kg

- net equipped (with rotor and without cutting equipment): 37 kg

- net of stand: 15 kg

2.2 LOCATION AND LAYOUT

• The machine (whether packed or not) is meant to be lifted

using a forklift truck. If manual handling is going to be used for

the machine on its own, two people are needed (for all machines

weighing more than 25 Kg)

• On a table of between 600 and 750 mm maximum in height.

• On a stand (available as an option) which can hold large capacity

collection tubs.

• To block and level the stand:

- Unscrew the lock screw on the two adjustable feet (10 mm

socket spanner).

- Adjust the foot then lock in position.

- Check that the machine is stable.

• If necessary, anchor the stand in position:

- Counter drill the attachment holes of the feet (5 mm dia.

screws x 40 mm long and rawl plugs not supplied).

Introduction

The User Manual contains useful information for the user on how

to work correctly and in complete safety, and is designed to make

it easier to use the machine (called «machine» or «appliance»

below).

What follows is in no case intended to be a long list of warnings and

constraints, but rather a series of instructions meant to improve the

service provided by the machine in every respect, and particularly

to avoid a series of injuries or damage to equipment that might

result from inappropriate procedures for use and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dis-

mantling the machine should consult this manual and read it

carefully before proceeding with the various operations, in order

to avoid any incorrect or inappropriate handling that might be

result in damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who is

constantly available to ensure quick and careful service for im-

proved machine operation and optimum e󰀩ciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

1 RC14 GB 02 2016

The reference language for these instructions is French.

• Motor characteristics:

B Number of phases (1 single phase - 3 three phase)

C Nominal voltage in Volts (value, range or commutation)

D Frequency (Hertz)

E Nominal power (Watts)

F Nominal current (Amperes)

G Rating of fuse protecting electrical supply (Amperes)

H Approximate electrical consumption (Kwh)

I Thermal relay setting (Amperes)

1) Dual voltage three phase motor

•Provide an accessible wall-mounted power outlet standardized

with 3 poles + Ground, rated 20 A compliant with IEC60309, and a

corresponding waterproof plug to be mounted on the power cord.

• Check the direction of rotation of the rotor tted to the machine.

- Press the START button

- Release the hopper locking lever and lift the hopper.(see §3.3)

- The rotor must turn in an anti-clockwise direction .

• If the direction of rotation is incorrect, change over any two

phase wires at the plug/isolator.

• The connection is pre-set for high voltage (e.g. 400 V).

For use with low voltage (e.g. 230 V), proceed as follows:

- Unplug the machine and turn it upside down.

- Unscrew the four feet to remove the base and gain access to

the electrical components.

- Change the wire on the integrated power board by moving the

cable spade from the terminal connection marked at the higher

voltage (400V) onto that marked at the lower voltage (230V).

- Modify the position of the connector strips of the motor connec-

tion housing.

Note: Do not change the current setting on the thermal

relay.

2) Single phase motor

• Provide an accessible standardized wall outlet with 2 poles

+ ground, rated at 10/16A in accordance with IEC60309, and a

corresponding waterproof plug to be installed on the power cord.

The machine must be earthed with a green / yellow wire.

2.3a

2.3 ELECTRICAL CONNECTION

Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions EN60204-1;

- Maximum voltage variation: ±10%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Before connecting the machine to the electrical power supply, check that the voltage of the electrical system is the same as that

marked on the rating plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using

a circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and

machine specications - see the specications shown in column G of gure 2.3a

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1

(IEC 60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with

a TN or TT system, or, for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic

shut-o󰀨. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TN or TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a

suitable power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

ATTENTION !!

To PAT test the Electrolux Range of Food Preparation Equipment,

the PCB board needs to be disconnected before any test is done.

This is due to the fact that the boards are tted with a grounding

diode that can give incorrect result during such a test. Also on a

standard appliance a ash test of 25 amps and up to 3000v is

used but, as you would expect, to use this on equipment, which

has a printed circuit, board would be quite destructive to that

board. We would recommend the use of a PAT tester approved

for computer systems which use a lower rate of amps.

The appliance is perfectly safe and is CE certicated. There are

two ways to get overcome this problem.

· Disconnect the board as instructed and test using test for PC’s,

· Or install the mixer on a fused spur (no plug) as this takes it

away from being a portable appliance and the PAT test is then

not needed.

2.3b

RC14 GB 04 2024 2
