Side 1/7

This document is to be used in conjunction with the original manufacturer’s manual.

The symbols correspond with the numbered drawings of the original manual

Contents

06/2024

Fault nding 5

Maintenance 6

Conformity with regulations 7

Introduction 1

Installation 1

Use, safety 3

Cleaning, hygiene 5

2.1a

2.1b

Introduction

1.1 DESCRIPTION

• The vegetable peeler is mainly used for peeling, scrubbing and

washing vegetables by adapting the equipment to the task to be

performed.

A Water inlet

B Removable cover

C Electrical control housing

D Adjustable drain

E Stainless steel cylinder

F Stand

G Tray for collecting the water

H Feet

I Removable lter basket (9 litre capacity)

J Hinged door and handle

K Outlet chute for vegetables

L Lid locking handle

1.1

Installation

2.1 DIMENSIONS - WEIGHT (for information only)

- Dimensions of packaging : 520 x 410 x 480 mm

Overall dimensions of T5S : 500 x 320 x 450 mm

- Overall dimensions of stand : 690 x 454 x 680 mm

- Gross weight packed, excluding equipment : 20Kg

- Net weight excluding equipment : 17Kg

- Gross weight of stand + lter : 18Kg

- Net weight of stand + lter : 16,5Kg

Introduction

The User Manual contains useful information for the user on how

to work correctly and in complete safety, and is designed to make

it easier to use the machine (called «machine» or «appliance»

below).

What follows is in no case intended to be a long list of warnings and

constraints, but rather a series of instructions meant to improve the

service provided by the machine in every respect, and particularly

to avoid a series of injuries or damage to equipment that might

result from inappropriate procedures for use and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dis-

mantling the machine should consult this manual and read it

carefully before proceeding with the various operations, in order

to avoid any incorrect or inappropriate handling that might be

result in damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who is

constantly available to ensure quick and careful service for im-

proved machine operation and optimum e󰀩ciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by sta󰀨 trained to use, clean and maintain it, in terms or reliability and safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the

lower limbs.

The machine is not designed for use in explosive atmospheres.

1 T5S GB 02 2021

The reference language for these instructions is French.

Choice of vegetables discharge on left . G

• Install as follows :

Connect the hose to the peeler and secure it with a collar .B C

- Place the machine on the stand, introducing the equipped outlet

pipe into the hole provided.

- Attach the machine to the stand (4 screws and washers ).D

The screws to x the peeler to the table are inside the

machine. Respect the length of the screw.

Note : Ensure that sucient space is available above the ma-

chine so that the lid may be opened, and in front of the stand

so that the basket may be removed.

- If necessary, pack and level the stand by unscrewing the re-

taining screw of the feet (10 mm socket spanner).

- Adjust the foot then lock in position.

- Check that the machine is completely stable.

- The feet may be anchored by counter drilling their retention

holes (dia. 5 x 40 screws and rawl plugs not supplied).

2.2c

2.2 LOCATION

• Handling - Transport

The machine is packaged with table in such a way as to be lifted

with a fork-lift truck. In the event of manual handling of the machine

alone, two persons will be required.

• The vegetable peeler needs :

- connecting to the cold water system near a stop cock (see § 2.3).

- an adequate evacuation to the drains (see § 2.4).

- an electrical power supply (see § 2.5).

• The vegetable peeler must be tted either :

- On a support that is fully stable, horizontal and not reso-

nant (table, unit, sink top, etc.) of between 500 and 900 mm

in height.

Note: In this case, the peeling machine can be removed easily

after disconnecting the power outlet and the exible water supply

pipe or unclipping the water inlet from the cover.

- On a standard lter stand (optional)

or a special pivoting stand (upon request)

Never place the T5S in a sink (water may enter the motor)

2.2a

2.1b

2.2b

2.2d

2.3 CONNECTION TO THE WATER MAINS SYSTEM

• The vegetabla peeler uses the mains pressure and reduced

ow rate.

• In conformity with the sanitary regulations, the machine’s water

inlet is located above the overow level, at a standardised distance

(overow device).

• Connect the machine to a stop cock with a reinforced pipe of

15 mm internal diameter and clamped by means of a collar.

Note : If the machine is to be moved around regularly, use a

connection pipe that is tted with quick release connectors.

2.4 DRAIN USED WATER AND SEPARATION OF WASTE

• The waste must be separated according to their size (peelings,

skins, starch, moss, earth, etc.) depending on the di󰀨erent equip-

ment that is used (see § 3.2).

• Some installations have starch decantation tanks that may be

directly connected. For other installations, we recommend installing

the machine on a lter stand in order to avoid blockages and bad

smells.

• Possible installations :

- Vegetable peeler without stand (near to a sink) : Place a lter

basket or a strainer next to the peeler.

- Vegetable peeler on lter stand :

Attach the outlet pipe (B),

internal diameter 88 mm to the under side of the tank for col-

lecting the used water , using the collar to fasten to the drain.

• Tips :

To drain used water correctly, avoid :

- vertical drops onto inspection chambers (formation of foam),

- sharp angles,

- attened, deformed or narrow pipes,

- counter slopes, or slopes which are not steep enough.

2.2a

2.2C

T5S GB 06 2024 2

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than those

of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions EN60204-1;

- Maximum voltage variation: ±10%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the specication plate are the same.

- -The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using a cir

cuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and machine

specications.

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC

60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with a TN or

TT, system, or for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic shut-o󰀨.

The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a suitable power

cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or accidents

due to direct or indirect contacts.

2.5 ELECTRICAL CONNECTION
