Mini Volume Pedal
O w n e r ’s M a n u a l
Thanks for purchasing the DOD® Mini Volume Pedal, the miniature passive volume pedal that gives
you a full range of volume control, without robbing you of valuable pedalboard space.
Features:
• Small form factor occupies minimal pedalboard space
• Long-throw treadle for full range of control
• High-quality, high-cycle 500kΩ potentiometer for smooth volume adjustments
• Built-in treble bleed circuit prevents loss of treble at lower volume settings
• Removable rubber feet for pedalboard mounting
• 1/4” TS input and output jacks
• Skid-free treadle pad
• Rugged construction
Setup:
1. Turn your amp o, then connect your cables (see connection diagram below).
2. Turn your amp volume down, push the DOD Mini Volume Pedal’s treadle toe down, then turn
your amp on.
3. Slowly raise your amp volume until the desired level is reached.
Use only unbalanced TS cables.
Out
Eect Pedals
In
In
In
Out
Out
****IMPORTANT USAGE NOTE****
The two hex screws on the bottom of the pedal are part of a spring-loaded adjustment
mechanism. If over time you experience slop, loosen these screws slightly and then re-tighten.
This will cause the main engagement gear to re-tighten against the treadle gear.
DO NOT remove these screws or operate the treadle while the screws are loosened. This can
cause the gears to become misaligned and cause the pedal to malfunction. There are no user-
adjustable components inside the pedal. Under no circumstances should the pedal be
opened up.
