1.1 INTRODUCTION ............................................................................................... 2
1.2 REVISION HISTORY.......................................................................................... 2
1.3 UNDERSTANDING THIS MANUAL’S SAFETY CONTENT............................... 2
1.4 COPYRIGHT © NOTICE .................................................................................... 2
2.1 CONTENTS ........................................................................................................ 3
3.1 WARRANTY ....................................................................................................... 4
4.1 SCOPE ............................................................................................................... 4
4.2 SPECIFICATION ................................................................................................ 4
4.3 HANDLING AND STORAGE .............................................................................. 4
5 HEALTH AND SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS................................................................ 4
5.2 CONNECTION TO THE POWER SUPPLY (CHARGER)................................... 5
6 IDENTIFICATION.............................................................................................................. 5
6.1 IDENTIFICATION ............................................................................................... 5
6.2 WHAT´S IN THE BOX? ...................................................................................... 5
7.1 PACKAGING....................................................................................................... 5
8 PREPARING THE HEAD TORCH
8.1 CHARGING......................................................................................................... 5
9 OPERATING THE HEAD TORCH
9.1 USING THE ON/OFF SWITCH........................................................................... 5
10 MAINTENANCE ................................................................................................................ 5
10.1 MAINTENANCE.................................................................................................. 5
11 EXPLANATION OF SYMBOLS
11.1 EXPLANATION OF SYMBOLS .......................................................................... 5
12.1 DISPOSAL .......................................................................................................... 5
Draper Tools Limited, Hursley Road,
Oude Graaf 8, 6002 NL, Weert, Netherlands.
Chandler's Ford, Eastleigh, Hampshire. SO53 1YF. U.K.
Help line: +44 (0) 23 8049 4344
Sales desk: +44 (0) 23 8049 4333
Internet: www.drapertools.com
E-mail: sales@drapertools.com
General enquiries: (023) 8026 6355
Service/Warranty Repair Agent:
For aftersales servicing or warranty repairs, please contact the
Draper Tools Helpline for details of an agent in your local area.
©Published by Draper Tools Limited.
No ar ubli ion ay be reprod ced,p t f t o his p cat m u stored in trie al syst m transmi ny rma e r v e or tted in a fo or by any ean m s,
electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
IMPORTANT: rea t i Please d hese ns ructi ll surt on fus care y nto e e the a s fe and eff t u oec ive se f th roduct and avis p s e
th e i ues nstr ct on fu ure ref reni s for t e ce. hi man T s ual s een ha b compiled b a r Tools an an te a pay Dr pe d is in gr ted rt theof
pr duct wi whio th ch it e is nc os d nd sh ldl e a ou be e t r f u e es. k pt th wi i fo ut re refer nc
Thi anual des i ts m cr bes he pu pos whi r e r fo ch e th product has been des gned d i an cont a th ec y i r ains ll e n essar nfo mation
to n e e sur its orrec d c t n a saf e. e s u W
e reco me at thism n hd t ma d fo ny a r, b p f nual is rea be re a oper tion o efore er orming
an f justmen ty kind o ad t o he pro uct d t n a d or to anpri y i ma nte an tas s.n ce k By fo a genllowing ll the eral etysaf
instr ctio aine inu ns cont d thi manua , sures l it n will e both pro uct and d operat safety, toge or ther wit onger li f h l fe o the
AlI ot gr ph ph o a s an d n ad rawings i this m nual pplied y ra er a ure s b D p Too s elp ill trl to h us ate th te opera io f th roducn o e p t.
Whilst vere y ff s e t n e ort ha been mad o e su cur cy f nf rmation r ce a a o i o con i d this al e Draper Tta ne in manu , th ools lic po y
of o i ous i o m t c nt nu mpr ve en d te rm este in h i e odifi ione r ght to mak m cat s without pr or nini war g.
WIRELESS/USB RECHARGEABLE HEAD TORCH
As our user manuals are continually updated, users should make sure that they use the
Downloads are available from: http://www.drapertools.com/manuals
DRAPER TOOLS LIMITED WEBSITE: drapertools.com
HURSLEY ROAD PRODUCT HELP LINE: +44 (0) 23 8049 4344
CHANDLER’S FORD GENERAL FAX: +44 (0) 23 8026 0784
1.3 UNDERSTANDING THIS MANUAL’S SAFETY CONTENT
WARNING! Information that draws attention to the risk of injury or death.
CAUTION! Information that draws attention to the risk of damage to the product or
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other
form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
Date first published: March 2021.
WIRELESS/USB RECHARGEABLE
Carefully remove the head torch from the
packaging and examine it for any sign of
damage that may have happened during
shipping. If any part is damaged or missing;
please contact the Draper Helpline (the
telephone number appears on the Title page)
and do not attempt to use the lamp.
Warning! Some of the packaging materials used
may be harmful to children. Do not leave any of
these materials in the reach of children.
If any of the packaging is to be thrown away,
make sure they are disposed of correctly;
according to local regulations.
5. HEALTH AND SAFETY INFORMATION
Part of our Expert range, this product is intended for trade use with the quality & features to meet and
exceed the expectations of the most demanding user. This twin beam head torch is virtually
indestructible and has four output settings. The sturdy torch can rotate 125° and the strong magnet
makes it simple for wireless charging. It has ABS+TPE+PC housing.
Stock no. ...................................................................................................................................... 65689
Part no...................................................................................................................................WL/HT400
SMD LED ..........................................................................................................................................6W
COB LED...........................................................................................................................................6W
Spot ..................................................................................................................................400 lumens
High ..................................................................................................................................400 lumens
Medium.............................................................................................................................200 lumens
Low.....................................................................................................................................25 lumens
Spot ............................................................................................................................................ 4 hrs
High ............................................................................................................................................ 4 hrs
Medium....................................................................................................................................... 8 hrs
Low........................................................................................................................................... 21 hrs
Total dimensions ......................................................................................................71 x 51 x 45 mm
Adjustable head band strap....................... Minimum diameter 140mm / Maximum diameter 200mm
Type ...........................................................................................................................................Li-ion
Rated voltage ..............................................................................................................................3.7V
Rating ........................................................................................................................................1.5Ah
Charging time ..............................................3 hrs via Type-C USB cable / 4.5 hrs via charging base
Do not drop the head torch as this can damage and shorten the life span of the unit.
Store in a dry location as damp conditions can damage the head torch.
Charging on a regular basis is advised to prolong the life of the battery cells.
Important: Fully charge before first use.
Make sure the light is switched off before
To charge it, connect the cable into the socket
under the dust cover, then connect it to either a
mains power supply or a USB power source.
The battery indicator will start flashing a green
LED to indicate that it is charging. Once it is fully
charged, the battery indicator will go solid green.
Alternatively, place the light on the charging pad,
using the magnet on the back of the light.
Note: Disconnect from the mains as soon as the
charge is complete. Unplug the charging lead
Note: Do not leave the battery in a fully
discharged condition. Recharge it at least once
every six months and always fully charge it.
8. PREPARING THE HEAD TORCH
Keep light clean and check for damage before
every use. If damage is observed remove from
Note: There are no user serviceable parts on
this light. For battery replacement etc. please
return to your nearest Draper authorised dealer
Important: LED arrays are designed to allow
individual LEDs to cease functioning without
causing the entire array to fail. This could be as
a result of shock or impact. Shock or impact with
- At the end of the product’s working life,
or when it can no longer be repaired,
ensure that it is disposed of according to
- Contact your local authority for details of
collection schemes in your area.
• Do not dispose of power tools with
• Do not abandon in the environment.
• Do not dispose of WEEE*
as unsorted municipal waste.
* Waste Electrical & Electronic Equipment.
As well as the product; there is a
part not fitted or attached to it.
9.1 USING THE ON/OFF SWITCH – FIG. 1
The first press of the on/off switch will operate the spot light.(1)
The second press will operate the low mode of the main light.
The third press will operate the medium mode of the main light.
The fourth press will operate the high mode of the main light.
The fifth press will turn the light off.
Direct the lens away from eyes before switching on.
Note: There is a memory function for the on/off switch. If you
leave the head torch in one mode for 5 seconds, then switch it off,
next time it is switched on, it will be in the mode last used.
9. OPERATING THE HEAD TORCH
11.1 EXPLANATION OF SYMBOLS
11. EXPLANATION OF SYMBOLS
Short-circuit-proof safety
Do not dispose of Waste Electrical
& Electronic Equipment in with
(separated extra-low voltage (SELV)).
Draper tools have been carefully tested and
inspected before shipment and are guaranteed
to be free from defective materials and
Should the tool develop a fault, please return the
complete tool to your nearest distributor or
Draper Tools Limited, Chandler's Ford,
Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: (023) 8049 4333 or
Product Help Line (023) 8049 4344.
A proof of purchase must be provided with
If upon inspection it is found that the fault
occurring is due to defective materials or
workmanship, repairs will be carried out free of
charge. This warranty period covering
parts/labour is 12 months from the date of
purchase except where tools are hired out when
the warranty period is 90 days from the date of
purchase. This warranty does not apply to any
consumable parts, any type of battery or normal
wear and tear, nor does it cover any damage
caused by misuse, careless or unsafe handling,
alterations, accidents, or repairs attempted or
made by any personnel other than the
authorised Draper warranty repair agent.
Note: If the tool is found not to be within the
terms of warranty, repairs and carriage charges
will be quoted and made accordingly.
This warranty applies in lieu of any other
warranty expressed or implied and variations of
its terms are not authorised.
Your Draper warranty is not effective unless you
can produce upon request a dated receipt or
invoice to verify your proof of purchase within the
Please note that this warranty is an additional
benefit and does not affect your statutory rights.
5.2 CONNECTION TO THE POWER SUPPLY (CHARGER)
Make sure the power supply information on the machine’s rating plate are compatible with the power
supply you intend to connect it to.
It is Class 3 (SELV); is designed for connection to a power supply matching that detailed on the rating
label and compatible with the plug fitted.
If an extension lead is required, use an approved and compatible lead rated for this appliance. Follow all
the instruction supplied with the extension lead.
This product requires no earth connection as supplementary insulation is applied to the basic insulation
to protect against electric shock in the event of failure of the basic insulation.
OUDE GRAAF 8, 6002 NL, WEERT, NETHERLANDS.
