Eaton 9PX 2000 Manual

Eaton Uafbrydelig strømforsyning (UPS) 9PX 2000

Læs gratis den danske manual til Eaton 9PX 2000 (46 sider) i kategorien Uafbrydelig strømforsyning (UPS). Denne vejledning er vurderet som hjælpsom af 5 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 3 anmeldelser. Har du et spørgsmål om Eaton 9PX 2000, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/46

ENGLISH

9PX 5000

9PX 6000

9PX 6000 G

9PX EBM 180V

Installation

and user manual

Service and support:

Call your local service representative

5-6kVA US_EN

Page 2

5-6kVA US_EN

SAVE THESE INSTRUCTIONS. This manual contains important instructions

that should be followed during installation and maintenance of the UPS and batteries.

The 9PX models that are covered in this manual are intended for installation

in an environment within 0 to 40°C, free of conductive contaminant.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will

be required to correct the interference at his own expense.

Certication standards

• Safety: IEC/EN 62040-1 / Ed.1: 2008.

UL 1778 4th edition

• EMC: IEC/EN 62040-2 / Ed.2: 2006.

FCC part 15 Class A.

• Performance: IEC/EN 62040-3 / Ed.2.0: 2011.

• IEC 61000-4-2 (ESD): level 3.

• IEC61000-4-3(Radiatedeld):level3.

• IEC 61000-4-4 (EFT): level 4.

• IEC 61000-4-5 (Fast transients): level 4.

• IEC61000-4-6(Electromagneticeld):level3.

• IEC61000-4-8(Conductedmagneticeld):level4.

Special symbols

The following are examples of symbols used on the UPS or accessories to alert you to important

information:

RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric shock symbol.

Important instructions that must always be followed.

Do not discard the UPS or the UPS batteries in the trash.

This product contains sealed lead acid batteries and must be disposed as it's explain in this manual.

For more information, contact your local recycling/reuse or hazardous waste center.

This symbol indicates that you should not discard waste electrical or electronic equipment (WEEE)

in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center.

Information, advice, help.

Refer to the user manual of UPS accessories.

SAFETY INSTRUCTIONS

Produkt Specifikationer

Mærke:	Eaton
Kategori:	Uafbrydelig strømforsyning (UPS)
Model:	9PX 2000
Bredde:	440 mm
Dybde:	605 mm
Højde:	86.5 mm
Vægt:	27900 g
Brugervejledning:	Ja
Produktfarve:	Sort, sølv
Skærmtype:	LCD
USB-port:	Ja
Batteriteknologi:	Blybatterier (VRLA)
Formfaktor:	Reolbeslag/tårn
Responstid:	0 ms
Opbevaringstemperatur (T-T):	0 - 35 °C
Relativ luftfugtighed ved drift (H-H):	0 - 96 %
Relativ luftfugtighed ved opbevaring (H-H):	0 - 96 %
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	1
Driftstemperatur (T-T):	0 - 40 °C
Kabler inkluderet:	RS-232, USB cable
Pakketype:	Kasse
Støjniveau:	47 dB
Udgangseffekt:	1800 W
Certificering:	CE, cULus, NOM
Webbaseret administration:	Ja
LED-indikatorer:	Status
Kabellængde:	2.44 m
Bæredygtighedscertifikater:	RoHS, ENERGY STAR
Driftshøjde:	0 - 3000 m
Indgangsfrekvens:	50/60 Hz
RS-232-porte:	1
Seriel grænsefladetype:	RJ-45, RS-232
Effektivitet:	91 %
Strømstik:	NEMA 5-20P
AC udgange, antal:	7 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 5–20R, NEMA L5-20R
Indgående driftsspænding (maks.):	144 V
Rackkapacitet:	2U
Output strømkapacitet (VA):	2 kVA
Indgående driftsspænding (min.):	100 V
Udgangs driftsspænding (min.):	100 V
Udgangs driftsspænding (maks.):	125 V
UPS topologi:	Dobbeltkonvertering (online)
Beskyttelsesfunktioner mod strømstød:	Netværk
Beskyttelse ved overspænding:	Ja
Bølgeform:	Sine
Beslag:	Ja
Koldstart:	Ja
Hot-swap batteri:	Ja
Seriegrænseflade:	Ja
Automatisk genstart:	Ja
Udgangsspænding total harmonisk forvrængning (THD):	3 %
Uddgående frekvens:	50/60 Hz
THD, indgående strøm:	3 %
