SD Disk Drive™™ Introduction
Introduction: Thank you for purchasing the SD Disk Drive™ from
Elation Professional®, the perfect companion to any Show Designer™
controller. The SD Disk Drive™ is a 19” rack mount accessory that
allows you to back-up and upload vital information to and from any
member of the Show Designer™ family (Show Designer™, Show
Designer 1™, or Show Designer 2™ ). The SD Disk Drive connects
directly to a Show Designer and provides a 3.5” floppy disk drive, a
PS-2 keyboard jack, a MIDI “IN” port, a MIDI “OUT” port, and two RS-
232 jacks. The MIDI connections can be used to connect to other MIDI
devices that use MIDI as a method to back-up memory.
Unpacking: Every SD Disk Drive™ has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your unit for
any damage and be sure all accessories necessary to operate the unit
have arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Please do not return this unit to your dealer without
first contacting customer support.
Customer Support: Elation Professional® provides a customer sup-
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.elationlighting.com for any comments
or suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacific Standard Time.
Voice: (323) 582-3322 Fax: (323) 582-2610
E-mail: support@elationlighting.com
Warning! To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
Elation Professional.
At Elation Professional
® we are concerned about the environment, and
package all our units in recyclable material. Please do not dispose of
the shipping carton in the trash, recycle whenever possible.
