NANO BATTALION
BASS PREAMP + OVERDRIVE
Congratulations on your purchase of the Electro-Harmonix Nano
Battalion. The all-analog circuitry of the Nano Battalion provides you
with an amazing variety of bass tones in a sturdy and compact pedal. At
the core of the Nano Battalion’s tone is a versatile MOSFET drive circuit
that can range from a subtle, light overdrive to fully saturated distortion.
A flexible three band equalizer includes a three way EQ Position switch
to select where the EQ falls in the pedal’s signal path.
The Nano Battalion features a normal ¼” input, plus a ¼” output that
can output either a normal, unbalanced signal (with a normal TS cable)
or a balanced signal (with a TRS cable) to go right into a mixing console
or recording interface. The Nano Battalion features buffered bypass and
runs on a standard 9.6VDC center negative supply, drawing 45mA.
- Using the Nano Battalion -
Plug the 9VDC adapter into the jack on the top of the Nano Battalion.
The unit must be powered to pass signal even in bypass. Connect an
instrument cable from your bass into the jack. Insert a normal INPUT
TS instrument cable between the jack and a suitable amplifier, OUTPUT
or insert a TRS cable (or TRS to male XLR cable) between the OUTPUT
jack and a suitable mixing console or recording interface. Click the
BYPASS footswitch to engage the Nano Battalion. The LED lights to
indicate that the unit is active.
WARNING:
Your
Nano Battalion
comes equipped with an Electro
-
Harmonix 9.6DC
-
200BI
power supply (same as used by Boss
®
& Ibanez
®
: 9.6 Volts DC 200mA). The Nano
Battalion requires at 9VDC with a center negative plug. Use of the wrong adapter 45mA
or a plug with the wrong polarity may damage your Nano Battalion and void the warranty.
- Main Control -
BYPASS Footswitch & LED – The LED illuminates when the effect is
engaged. The LED will not light if the Nano Battalion is bypassed. Press
the footswitch to toggle between effect on and buffered bypass mode.
VOL Knob – Sets master output level of the pedal.
BLEND Knob – Sets the ratio between clean signal and distorted signal.
Turn BLEND up for more distorted signal.
DRIVE Knob – Sets the intensity and saturation of the distortion.
TONE Knob – Cuts high frequencies from the distortion as you turn the
knob down.
EQ CONTROLS:
TREBLE Knob – Boost or cut high end. No effect when the knob is at
50%. Boosts/cuts frequencies starting above 1kHz. Maximum boost/cut
about +/-12dB around 5kHz.
BASS Knob – Boost or cut low end. No effect when the knob is at 50%.
Boosts/cuts frequencies starting below 200Hz. Maximum boost/cut
about +/-12dB around 60Hz.
MID Switch – No effect when the switch is in the middle position. In
the upwards position, 9dB boost around 500Hz. In the downwards
position, 9dB cut around 500Hz.
- EQ POS. & Signal Path -
The EQ POS switch determines where the EQ (TREBLE, BASS, and MID
controls) falls in the Nano Battalion’s signal path. In all cases, the TONE
control comes immediately after the distorted signal, and the VOL control
is last in the signal path. There are three EQ POS modes, illustrated on
the next page.
