Side 1/2

PL44

Dynamic Supercardioid

Vocal Microphone

General Description:

Key Features:

• Sonic voicing for transparency and high-mid lift

• Plug-and-play placement of vocals in any mix

• Supercardioid polar pattern

• Powerful Neodymium magnet structure

• Shock mounted capsule and low handling noise

• Fine mesh Memraflex™ grille

Thank you for purchasing the Electro-Voice® PL44. This product is

a professional-grade supercardioid dynamic microphone designed

for plug-and-play placement of vocals in any mix. The PL44’s high-

mid frequency content design lifts the vocal into the precise spot in

the mix where they need to be, resulting in fast and effective vocal

placement. With its extremely accurate frequency response, the

PL44’s sonic performance is robust and articulate delivering highly

detailed imaging across the critical vocal frequency range. The

enhanced isolation provided by its supercardioid polar pattern is

an excellent defense against system feedback and cross-talk bleed

emanating from other nearby sound sources. The result is higher

gain before feedback and cleaner stage mixes. Although designed

to be a vocal microphone for music and spoken word, the PL44 will

also function well as an instrument or amplifier microphone where a

dynamic element capsule would be desired.

Application Notes:

As with most directional microphones, the low frequency response

of the PL44 microphone varies with the distance from the sound

source. Known as “proximity effect”, the bass response of the

microphone increases as the working distance to the microphone is

reduced. This “bass boost” is only audible when working at distances

closer than 6 inches. Using this microphone at distances greater

than 6 inches provides minimal coloration from proximity effect.

Proximity effect can be used to your advantage when a thin voice

is being recorded. As the vocalist decreases their working distance

to the microphone, the low frequency content is enhanced. Close-

up positioning of the microphone will also reduce the potential for

feedback from the sound reinforcement system. When close-talked,

the bass-boost provides an increase in overall microphone output

level. The mixer gain may be proportionately reduced, resulting in

a reduction of the system’s sensitivity to feedback caused by the

sound entering the microphone from the loudspeakers.

Warranty:

This Electro-Voice® PL44 product is guaranteed against malfunction

due to defects in materials or workmanship for a period of three (3)

years from the date of original purchase. Please refer to the Limited

Warranty card included with your product for further warranty infor-

mation.

Technical Specifications:

Element Type: Dynamic, Neodymium Magnet

Structure

Frequency Response: 80 Hz - 18,000 Hz

Polar Pattern: Supercardioid

Sensitivity, Open Circuit

Voltage, 1 kHz:

2.2 mV/Pa (-53 dBV)

Polarity: Positive pressure on diaphragm

produces positive voltage on pin 2

relative to pin 3

Rated Impedance: 600 ohms

Microphone Connector: 3-pin, XLR-type

Finish: Textured black satin handle with

Memraflex

grille

Dimensions: Length = 7.33” (186.2 mm)

Width = 2.00” (50.7 mm)

Shank = 0.93” (23.6 mm)

Accessories Included: Stand adapter with Euro-thread

insert, Soft zippered gig bag

Net Weight: 10.0 oz (282 g)

Shipping Weight: 18.9 oz (536 g)

12000 Portland Avenue South, Burnsville, MN 55337

Phone: 952/884-4051, Fax: 952/884-0043

www.electrovoice.com

Part Number LIT000244 Rev B

U.S.A. and Canada only. For customer orders, contact Customer Service at:

800/392-3497 Fax: 800/955-6831

Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:

+ 49 9421-706 0 Fax: + 49 9421-706 265

Other Internatonal locations. For customer orders, Contact Customer Service at:

+ 1 952 884-4051 Fax: + 1 952 887-9212

For warranty repair or service information, contact the Service Repair department at:

800/685-2606

For technical assistance, contact Technical Support at: 866/78AUDIO

Specifications subject to change without notice.

Electro-Voice

Dimension Drawing:

Frequency Response: Polar Response:

Microphone Use and Placement

Please note that micing techniques are a matter of personal preference. These are merely guidelines to assist in the placement of the

microphone to gain optimal performance.

Usage Optimal Placement

Vocals 0 to 6 inches away, aimed directly at the sound source.

Spoken Word 5 to 10 inches away, aimed directly at the sound source.

Standard Placement & Use Guidelines

1. Always point the microphone at the desired source of sound, and away from any unwanted sources.

2. The microphone should be located close to the sound source to minimize interference from other potential sound sources.

3. Use the 3-to-1 rule when using multiple microphones. Place each microphone three times farther from other microphones as from

the desired sound source.

4. Minimize over-handling of the microphone to reduce unwanted mechanical noise.

PL44 Part Numbers

PRD000158000 PL44, Dynamic Supercardioid Vocal •

Microphone

ACC000045000 SAPL-1, Replacement Microphone Stand •

Adapter

ACC000048001 WSPL-1, Optional Foam Windscreen, Black•
