Electro-Voice | RE92L

RE92L

▪Wide, Smooth Frequency Response

▪Cardioid Polar Pattern

▪12 dB/Octave Switchable High Pass Filter

▪Transformerless Differential Output to Drive Long

Cables

▪Includes Both Single and Dual Mic Tie Clips

The RE92L is a professional quality miniature cardioid,

electret condenser lavaliere microphone. It is designed

for unobtrusive miking of speech and instruments,

making it an excellent choice for use in many

broadcast, stage performance, and presentation

purposes. Its small size makes the RE92L ideal for

theatre, interviews, public address systems, and

houses of worship. The RE92L has a cardioid polar

pattern for high gain before feedback. The RE92L

condenser element provides clear and natural sound

reproduction. The included two-stage windscreen

minimizes wind noise and popping. The RE92L

includes an inline module for connection to any

standard microphone input capable of supplying 24 to

48 Volt phantom power. The RE92L comes supplied

with 4 feet of cable, both single and dual tie clasps,

and a belt clip for the inline module with a non-

reflecting black finish.

Technical specifications

Generation Element: Self-Biased condenser, back electret

2-micron thick, gold sputtered

diaphragm

Frequency Response: 40 Hz to 20,000 Hz

Polar Pattern: Cardioid

Sensitivity, Open Circuit

Voltage, 1 kHz:

5.6mV/Pascal

Clipping Level (1% THD): >135 dB SPL

Equivalent Noise: <30 dB SPL “A” weighted (0 dB=20

micropascals)

Dynamic Range: >105 dB

Signal to Noise (RE: 94 dB

SPL):

64 dB

Output Impedance, 1 kHz: 250 ohms

Power Requirements: 24 to 52 Volt Phantom Power

Current Consumption 6 mA typ. with P48 supply

Microphone Dimensions: Diameter = 0.412 in (10.5 mm)

Length = 0.948 in (24.1 mm), less

strain relief

Inline Module Dimensions: Diameter = 0.875 in (22.2 mm)

Length = 5.350 in (135.9 mm)

Cable: 0.100 in (2.54 mm) diameter x 4 ft

(1.2 m) long

Polarity: Pin 2 positive, reference to pin 3, with

positive pressure on the diaphragm

Accessories Included: Two Stage Windscreen

Single Tie Clip

Dual Tie Clip

Belt Clip for inline module

Color: Nonreflecting black

Environmental Conditions: Relative Humidity 0-50%: -29° to 74°C

(-20° to 165°F)

Relative Humidity 0-95%: -29° to 57°C

(-20° to 135°F)

Net Weight: 5.6 oz (160 gram) with inline module

System overview

Frequency Response:

Application Notes:

Using the Windscreen

This microphone includes a windscreen that can be

used anytime wind noise or breath pop is a problem.

To install the windscreen, simply press it on the top of

the microphone. The windscreen has an internal frame

that includes a stop, to help position the windscreen

correctly. When installing the windscreen, make sure

to push it down on the microphone as far as it can go.

This ensures the frame inside the windscreen does not

cover any of the acoustic side ports on the

microphone.

Microphone Positioning (For Best Results)

Best results are achieved with the mic positioned 3 to

6 inches below the neckline. Typical locations are on

the lapel, shirt collar, or on the shirt directly below the

chin. You should avoid covering the microphone with

any cloth, since this could change the frequency

response characteristics of the microphone.

If mechanical noise pickup from the cable is a

problem, it can be minimized by looping the cable up

and through the tie clip, as shown.

Cable Position with Tie Clip

Polar Response:

Dimensions:

5.350 in

[135.9 mm]

Ø0.875 in

[22.2 mm]

Inline Module Dimensions

Ø0.412 in

[10.5 mm]

0.948 in

[24.1 mm]

Microphone Dimensions

Ordering information

RE92L

Premium Lavalier Microphone, Cardioid, XLR

Connector black

Order number RE92L

2 | RE92L
