Side 1/10

A Pusher

B Ram press

C Hopper

D Ejector

E Cutting chamber

F Drive shaft

G Body

H Casing

I Inclinable base

J Strut

K Control panel

L Locking pin

M Bowl

N Bowl handle

O Lid locking handle

P Rotor

Q Lid

R Scraper handle

1.1 DESCRIPTION

The combined vegetable slicer/cutter is a preparation machine

that provides two functions:

1) Cutting vegetables (cut - slice - shred - grate - ) Cutting chips

and dices.

2) Cutter-mixer for reducing condiments, emulsions, and sauces,

various liquidising operations, and cuttering meat. The vegeta-

ble cutting function is designed to allow cutting of all types of

products, by means of a lever-operated hopper. This combined

appliance equipped with the lever-operated hopper and cutter is

very appropriate for restaurant and small community kitchens.

• Control panel

A ON switch, to operate at the selected speed.

B STOP switch.

C ON switch, to operate at the selected speed,

while held pressed in.

E Display of selected speed

F Increase speed

G Decrease speed

TRK2 GB 02 2018

1.1

1.2

Refer to the numbered drawings that go with the numbered

paragraphs in the instructions.

Contents

Introduction 1

Installation. 1

Use, Safety 3

Cleaning, Hygiene, Storage 7

Fault ﬁnding 8

Maintenance 9

Compliance with regulations 10

Introduction

The User Manual contains useful information for

the user on how to work correctly and in complete

safety, and is designed to make it easier to use the

machine (called “machine” or “appliance” below).

What follows is in no case intended to be a long list of warnings

and constraints, but rather as a series of instructions meant

to improve the service provided by the machine in every res-

pect, and particularly to avoid a series of injuries or damage to

equipment that might result from inappropriate procedures for

use and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or

dismantling the machine should consult this manual and read

it carefully before proceeding with the various operations, in

order to avoid any incorrect or inappropriate handling that

might be result in damage to the machine or put people’s

safety at risk.

It is just as important that the Manual should always be avai-

lable to the operator and it should be kept carefully where the

machine is used ready for easy and immediate consultation in

case of any doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who

is constantly available to ensure quick and careful service for

improved machine operation and optimum efﬁciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

Introduction

Installation

04/2022

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by staff trained to use, clean and maintain it, in terms or reliability

and safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury

to the lower limbs.

The machine is not designed for use in explosive atmospheres.

The reference language for these instructions is French.

• Motor speciﬁcations:

A Number of phases (1 single phase)

B Nominal voltage range in volts

C Frequency (Hertz)

D Nominal power (Watts)

E Nominal current (Amperes)

F Rating of fuse for protecting the electrical line (Amperes)

• The combined appliance runs on single-phase current.

• Warning for the installer:

This electronic combined appliance is ﬁtted with a ﬁlter

which discharges disturbance from the network directly

to earth without passing through the variator. In order

to be efﬁcient, the earth connection for the installation must

be good quality, for otherwise disturbances may transit via the

variator and damage it.

2.3

TRK2 GB 09 2021

2.2 POSITIONING AND ORGANISATION

Always place the machine on a strong, ﬂat, stable

support.

• On a table of height between 700 and 900 mm maximum, the

vegetable slicer can take a standard receiving bowl of maximum

height 200 mm.

• On a functional, mobile stand (delivered as an option).

• When using large bowls, place the vegetable slicer at the

edge of the table or use a mobile stand.

2.3 ELECTRICAL CONNECTION

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualiﬁed and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions;

- Maximum voltage variation: ±5%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the speciﬁcation plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) by using

fuses or thermal relays of the appropriate gauge relative to the place of installation and machine speciﬁcations.

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC

60204-1) with the use of protection devices for automatic shut-off of power in the event of an insulation fault with a TN or

TT, system, or for the IT system, with the use of a permanent insulation or differentials controller for automatic shut-off.

The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TT system, a differential circuit breaker must be installed upline of the power supply, with a suitable

power cut-off (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

Earthing is mandatory, using a green/yellow

conductor.

NO EARTH PLUG = NO PROTECTION =

RISK OF ELECTROCUTION = RISK OF FAILURE

Note: The earth values are deﬁned according to the residual

differential current. Non-compliance with these instructions may

result in invalidation of the warranty.

No damage caused by an earth connection fault

will be covered by the warranty.

In certain cases depending on the protection differentials

it may be necessary to install SI (Super Immunity) type

devices to avoid any inappropriate triggering.

To PAT test the Electrolux Range of Food Preparation Equipment,

the PCB board needs to be disconnected before any test is done.

This is due to the fact that the boards are ﬁtted with a grounding

diode that can give incorrect result during such a test. Also on

a standard appliance a ﬂash test of 25 amps and up to 3000v is

used but, as you would expect, to use this on equipment, which

has a printed circuit, board would be quite destructive to that

board. We would recommend the use of a PAT tester approved

for computer systems which use a lower rate of amps.

The appliance is perfectly safe and is CE certiﬁcated. There are

two ways to get overcome this problem.

• Disconnect the board as instructed and test using test for

PC’s,

• Or install the mixer on a fused spur (no plug) as this takes it

away from being a portable appliance and the PAT test is then

not needed.

2.1 DIMENSIONS - WEIGHT (for information only)

• see table:

P1 : Gross weight

2.1

P2 : Net weight of vegetable slicer

P3 : Net weight of cutter

Produkt Specifikationer

Mærke:	Electrolux
Kategori:	Skæremaskine
Model:	TRK45
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	200-240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	252 mm
Dybde:	585 mm
Højde:	505 mm
Vægt:	30500 g
Produktfarve:	Rustfrit stål
Kontroltype:	Berøring
Antal hastigheder:	10
Strøm:	1000 W
Variabel hastighed:	Ja
Strømforbrug (typisk):	1000 W
Rotationshastighed:	3700 rpm
Skål volumen:	4.5 L
Skål, materiale:	Rustfrit stål
Impulsfunktion:	Ja
Materiale, knive:	Rustfrit stål
Kødhakker:	Ja
Tåler opvaskemaskine:	Ja
