Side 1/8
• Element of the PocketHome® system
• Transmitter for the PH-BP1-P9 receiver
• Detects the room temperature and
sends requirement for circuit switching
P
DISPLAY DESCRIPTION: CONTROL ELEMENTS:
: used for selection of functions
: selection of preset temperatures
: information button (when pushed in the AUTO
mode, it gradually shows information on the
required temperature (PO:t), current hour/
temperature (CL:O/tE:P), operating hours
(SU:MA) and day (dE:n).
confi rmation button (ENTER)
for selection of functions and temperature
setting
1, indication of the preset time and temperature
program
2, indication of the selected function AUTO, MANU,
PROG, etc.
3, indication of anti-freeze temperature (3°C)
4, indication of temperatures, comfortable ,
economical , party P
5, indication of time / temperature
Fce
i
1
2
3
4
5
P
The PH-BP1-V transmitter in connection with the 9-channel receiver PH-BP1-P9 is used for wireless
control of individual rooms (zone control) in a fl oor heating system. There is no need to install any con-
necting cables between the receiver and transmitters (room thermostats)! The entire set can be included
in the PocketHome® system and all zones controlled from a single point by means of a central unit and/
or through a PC. In that case it is fi rst necessary to activate the PH-BP1-V transmitter in the central unit
(see Putting in operation in the PocketHome® system)!
In objects which do not necessitate central control the assembly can also work autonomously without a
central unit. The PH-P1-P9 receiver can be controlled by means of up to 9 PH-BP1-V transmitters.
DESCRIPTION
INSTALLATION
1) The transmitter is easily portable, yet we recommend that it be located in a suitable place where its activity will not
be affected by direct fl ow of hot air from a heater, solar radiation or other disturbing effects. Also avoid its
installation on an external wall.
2) Install the transmitter (indoors) as far as possible (at least 0.5 m) from big metal objects and from power lines to
avoid interference of signal reception!
3) We recommend that the installation be done by a person adequately qualifi ed in electrical engineering!
4) To prevent interference and affection of systems, every system is protected by its unique factory-saved code!
5) For correct communication of all elements in the PocketHome® system with the PH-CJ37 / Plus central unit, the
code must be learned = every element ACTIVATED in the central unit!!!
6) As the entire system works at two-way radio frequency of 433.92 MHz, follow the installation and location
instructions!
! Caution:
LOCATION AND EXCHANGE OF BATTERIES
- Lift off the back part by pushing the latch at the arrow
and remove the protective paper from the batteries (at
fi rst use); thus the transmitter becomes functional.
- Necessity to exchange the batteries is indicated by the
“ ” symbol fl ashing on the display (this information Ba:tt
can also be directly obtained on the central unit or in the
PC program (see the PH-CJ37/Plus manual).
- Always use alkaline batteries 2 x 1.5 V type AA
Dispose of used batteries in conformity with
regulations for dealing with hazardous waste! 2
