Side 1/14
Wireless control unit
Two-way radio communication on 433.92 MHz
Comfortable solution of room heating
Energy cost saving during holiday
Control of room temperature according to preset requirements
PH-BSP
Operating instructions PH-BSP
Version 11.08
WIRELESS CONTROL UNIT
FOR CONTROL OF ELECTRIC HEATING DEVICES
(WITHIN ONE ROOM)
Possibility of integration in the PocketHome
®
system, in which it becomes
a subordinate element of the central unit PH-CJ37 / PH-CJ37 Plus
Predictive system (providing for the given temperature at the required time, in autonomous mode only)
SYSTEM FUNCTIONS
PH-BSP Wireless control unit
- measures temperature in the room and switches the individual heating devices centrally as
required (functions as a room thermostat);
- able to control up to 255 switching elements (PH-SP1, PH-SP2, PH-SP3) from one place;
- switches the elements stepwise (at 1 s), thus preventing current surges in the network;
- suitable for controlling electric heaters in one room;
- for control by means of a mobile phone, you just need to connect the GST1 / GST2 module
(page 9, 12, 13);
- can be integrated in the PocketHome
®
system, in which in becomes a subordinate element of
the central unit PH-CJ37/ PH-CJ37 Plus and meets its requirements.
PH-SP1 Wireless switch – under the switch
- switches the heating device on the basis of information received;
- sends back confirmation of the change made;
- simple installation into the installation box;
- receiver states are indicated by LEDs on the front panel;
- after short-time voltage failure, it activates automatically into the system (E-EPROM memory)
2
SYSTEM COMPONENTS
PH-SP2 Wireless switch – wall-mounted
- switches the heating device on the basis of information received;
- sends back confirmation of the change made;
- simple installation on the installation box;
- receiver states are indicated by LEDs on the front panel;
- after short-time voltage failure, it activates automatically into the system (E-EPROM memory).
PH-SP3 Wireless switch – socket-mounted
- switches the heating device on the basis of information received;
- sends back confirmation of the change made;
- simple installation in the socket directly;
- device connected by simply inserting it into the socket (suitable for heaters with plug outlet);
- receiver states are indicated by LEDs on the front panel;
- after short-time voltage failure, it activates automatically into the system (E-EPROM memory).
This wireless two-way system is primarily designed for the regulation of electric heating in a single room. Here, the control unit fulfils the
of a wireless room thermostat. According to the temperature in the reference room, in which it is located, it controls the heat source (for
example, a heating panel) and regulates the whole heating system according to the preset program. It enables control of up to 255
RECEIVERS (switching elements) from one place. The control unit sends information on the required temperature to individual components;
on the basis of this information, each component controls the heating appliance to which it is connected. PH-BSP switches the elements
stepwise (at approx. 1s) to prevent current surges in the network!
In order to prevent interference and affecting of the systems, each of them is protected by its own unique code which is stored in the
control unit PH-BSP by the manufacturer!
Correct communication of all system components with the control unit PH-BSP requires code learning - ACTIVATION of each component
added to the system!
!
!
As the whole system works at bidirectional radio frequency of 433.92 MHz, observe the instructions for installation and location of each
system component according to the given manual!
!
PERMEABILITY OF VARIOUS MATERIALS FOR RF SIGNAL 433.92 MHz
wall
plasterboard
glass reinforced concrete
iron
Note: The above mentioned values are only approximate; they may vary because of specific conditions
at the location of signal transmission and reception!
