Electro 86
SPECIFICATIONS:
Model: Electro 86
LEDs: 86 Pcs. (29 Red, 29 Green,
& 28 Blue)
Weight: 2.75lbs./ 1.258kgs.
Size: 6.5” (L) x 7.75” (W) x 6” (H)
Fuse: 1 Amp
Supply Voltage: 120V / 230V
Duty Cycle: None
DMX Channels: 4
Colors: Multiple Colors
Warranty: 1 Year
CAUTION! Please read and
understand these instructions
before installing or operating
this unit.
Operating Instructions:
The Electro 86 has been tested at the fac-
tory, there is no assembly required. The unit
is ready to be plugged into a power outlet.
This unit is a 4 channel DMX intelligent LED
pinspot. It can be run as a stand-alone, static
unit, DMX controlled unit, or in a Master/
Slave configuration. While in Stand Alone or a
Master/Slave configuration, you may choose
between sound active mode, auto run chase,
or static color. For stand-alone mode, Master/
Slave mode, and Master/Slave configuration
settings, see other side.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Caution! Never open unit when in use.
Always disconnect main power before
replacing fuse. Remember to always
replace with the exact same type fuse.
DMX TRAITS:
CHANNEL 1: RED
CHANNEL 2: GREEN
CHANNEL 3: BLUE
CHANNEL 4: INTENSITY & STROBE SPEED
0 - 189 = INTENSITY
0% - 100%
190 - 250 STROBE
SLOW - FAST
251 - 255 NO FUNCTION
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Universal DMX Control: This unit allows you to use any universal DMX-512 controller to control the
different DMX traits. A DMX controller allows you to create unique programs tailored to your individu-
al needs.
1. The Electro 86™ uses four DMX channels. Channel 1 controls red, channel 2 controls green,
channel 3 controls blue, and Channel 4 controls intensity level and strobe speed.
2. To control your fixture in DMX mode, follow the set-up specifications that are included with your
DMX controller.
3. Set your DMX address and put dipswitch #10 into the “ON” position.
4. Use the controller’s faders to control the various DMX fixture traits.
5. For longer cable runs (more than a 100 feet) use a terminator on the last fixture.
6. For help operating in DMX mode consult the manual included with your DMX controller.
Master-Slave Operation (Preprogrammed Chases): This function will allow you to link up to 16 units
together and operate without a controller. In Master-Slave operation one unit will act as the control-
ling unit and the others will react to the controlling units programs. Any unit can act as a Master or as
a Slave. See diagram below.
1. Using standard XLR microphone cables, daisy chain your units together via the XLR connector on
the rear of the units. Remember the Male XLR connector is the input and the Female XLR con-
nector is the output. For longer cable runs we suggest a terminator at the last fixture.
2. The dipswitch settings for Master/Slave mode is as follows. On the Master unit run you desired
mode using the dipswitches. On the Slave unit or units put dipswitches #1 and #10 in the “ON”
position.
Auto Run Mode, RGB Mode, Sound Active Mode, and Blackout: In Auto Run the color swill chage
and fade. In RGB mode choose a single color or colors to stay static. In Sound Active mode, the col-
ors will change following the beat of the music.
Auto Run Mode:
Plug the fixture in and put all dipswitches in the “OFF” postion. To adjust the speed of the auto
run use dipswitches #7 & #8. Putting these switches in the “ON” position will adjust the speed of
the auto run.
RGB Mode:
Plug the fixture in and put dipswitch #1 in the “ON” position for red, dipswitch #2 is green, and
dipswitch #3 is blue. To activate strobing and adjust the strobe speed use dipswitches 4-6.
Sound Active Mode:
Plug the fixture in and put dipswitch #9 in the “ON” position.
Blackout Mode:
When the fixture is on put dipswitch #10 in the “ON” position, to go into Blackout mode.
1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
