Electro MH25R

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Introduction:

This unit can be either an 8 or 12 channel DMX intelligent moving head unit. The Electro MH25R has 3 operat-

ing modes; sound active mode, auto program mode (test mode), or it can be controlled by a DMX controller.

The unit can be run as a stand alone unit or in a Master/Slave configuration. This unit has been tested and

the lamp has been installed at the factory, there is no assembly required. The unit is ready to be plugged in to

a power outlet. There are no dipswitch settings for Master/Slave mode, just simply link the units together. To

enhance the beams effects you can use a fog machine. This unit looks good in pairs.

CAUTION! Please read and understand these instructions before installing or operating this unit.

SPECIFICATIONS:

Model: Electro MH25R

LED: 1 x 25W LED

Weight: 19lbs./ 18.6kgs.

Size: 12” (H) x 10.5” (W) x

10” (L)

Fuse: 2 Amp

Supply Voltage: 110V-240V 50/60Hz

Working Position: Any Safe position

Duty Cycle: None

DMX Channels: 2 DMX Channel Modes

8 Channel Mode &

12 Channel Mode

Gobos: 7 plus Spot

Colors: 8 Colors + White

Warranty: 1 Year

CAUTION! Please read and

understand these instructions

before installing or operating

this unit.

1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our

1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with

dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover

items or parts prone to wear and tear: motors, fuses, brushes and belts. Eliminator Lighting warranty

is only valid with-in the United States.

Fuse Replacement: Locate and remove

the unit’s power cord. Once the cord has

been removed located the fuse holder

located inside the power socket. Insert

a flat-head screw driver into the power

socket and gently pry out the fuse holder.

Remove the bad fuse and replace with a

new one. The fuse holder has a built-in

socket for a spare fuse be sure not to

confuse the spare fuse with active fuse.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Stand-alone operation (Sound active or teSt Mode): This mode allows a single unit to run to the

beat of the music.

SOUND ACTIVE MODE:

1. To activate Sound Active mode, press the MODE button until the main menu is displayed. Press either the

UP or DOWN button until “A.Udl” is displayed.

2. Press either the UP or DOWN buttons until “ON” is displayed. If “ON” is already displayed then press

ENTER. The unit will now run to the beat of the music.

TEST MODE: When power is supplied to the unit this is the default setting.

1. To reactivate the Test mode, press the MODE button until main menu is displayed. Press either the UP or

DOWN buttons until the LCD will display “t.ESt”, press Enter. The LCD will now display “M.od.1”, press

ENTER. The unit will now run a automatic show.

OPERATION:

UNIVERSAl DMX CONTROl: This unit allows you to use any universal DMX-512 controller to control head

movement, the color wheel, the gobo wheel, and the shutter (strobe). A DMX controller allows you to create

unique programs tailored to your individual needs. Follow the set-up specifications that are included with your

DMX controller.

1. The Electro MH25R™ has an 8 channel mode and 12 channel mode.

2. To select your desired DMX mode please see the next page under “d.n.pr”. Press the UP button until

“d.n.pr” is displayed, then press ENTER. Select your desired DMX Channel Mode and press ENTER.

3. After you have selected your desired DMX Channel Mode, press the UP button until “ ” is displayed, A001

press ENTER.

4. Now press the UP button to set your desired address and press ENTER. Connect your DMX Controller.

5. Use the controller’s faders to control the various DMX fixture traits.

6. For longer cable runs (more than a 100 feet) use a terminator on the last fixture.

7. For help operating in DMX mode consult the manual included with your DMX controller.

MaSter-Slave operation (Sound active or teSt Mode): This function will allow you to link up to

16 units together and operate without a controller. The units can be sound activate or run in a test mode. In

Master-Slave operation one unit will act as the controlling unit and the others will react to the controlling units

programs. Any unit can act as a Master or as a Slave.

1. This is a very simple process. Using standard XLR microphone cables, daisy chain your units together via

the XLR connector on the rear of the units. Remember the Male XLR connector is the input and the Fe-

male XLR connector is the output. For longer cable runs we suggest a terminator at the last fixture. You do

not have to assign the units Master/Slave. They will automatically fall into Master/Slave mode when

connected.
