Electro

Panel 192

SPECIFICATIONS:

Model: Electro Panel 192

LEDs

: 192 - 64 Red, 64 Green,

& 64 Blue

Weight: 4.6lbs./ 2.1kgs.

Size: 7.12” (H) x 12.41” (W) x

4.5” (D)

Fuse: 7 Amp

Supply Voltage: 120V

Power Cord Daisy Chain: 33 Fixtures Max.

Working Position:

Any Safe position

Duty Cycle: None

DMX Channels: 6 DMX Channel Modes:

1, 2, 3, 4, 6, or 7 DMX

Channels

Colors: Multiple Colors

Warranty: 1 Year

CAUTION! Please read and

understand these instructions

before installing or operating

this unit.

Operating Instructions:

The Electro Panel 192 has been tested at the factory, there is no assembly required. The unit is

ready to be plugged into a power outlet. This unit is a 7 channel DMX intelligent LED par can. It can

be run as a stand-alone, static unit DMX controlled unit, or in a Master/Slave configuration. While

in Stand Alone or a Master/Slave configuration, you can run the auto mode. For stand-alone mode,

and Master/Slave configuration settings, see other side.

Power Cord Daisy Chaining: With this feature you can connect the xtures to one another using the

IEC input and output sockets. The quantity that can be connected is 33 xtures maximum. After 33 x-

tures you will need to use a new power outlet. They must be the same xtures. DO NOT mix xtures.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Caution! Never open unit when in use.

Always disconnect main power before

replacing fuse. Remember to always

replace with the exact same type fuse.

1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our

1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with

dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover

items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty

is only valid with-in the United States.

ADDR - DMX Address Setting.

1. Tap the either the MENU, UP, or DOWN buttons until “ ” is displayed, press ENTER.ADDR

2. “1” will now be displayed and ashing. Press the UP or DOWN buttons to nd your desired

address. Press ENTER to set your desired DMX address.

CHND - There are 6 DMX Channel modes to choose from, this will let you switch and select

your DMX Channel mode. You can choose from either 1, 2, 3, 4, 6, or 7 DMX Channels. Please

see the last page of the DMX values and traits for each DMX Channel Mode.

1. Tap the either the MENU button until “ ” is displayed, press ENTER. CHND

2. Tap the UP or DOWN buttons to scroll through the different DMX Channel modes. Once you have

found your desired DMX Channel mode press ENTER to conm and exit.

SLND - This will let you set unit as a master or slave in a master/slave conguration.

1. Tap the either the MENU button until “ ” is displayed, press ENTER. “ ”, “ ” or “ ” will SLND MSTR SL 1 SL 2

be displayed.

2. Tap the UP or DOWN buttons until your desired setting is displayed, press ENTER to conm and

exit.

SHND - in this mode you can choose and run one of 11 preprogrammed shows.

1. Tap the either the MENU button until “ ” is displayed, press ENTER.SHND

2. Tap the UP or DOWN buttons to scroll through 11 preprogrammed shows.

3. Select your desired show by pressing the ENTER button to conrm and exit.

DIMM - in this mode you can set the brightness/intensity of the xture.

1. Tap the either the MENU button until “ ” is displayed, press ENTER.DIMM

2. Tap the UP or DOWN buttons to adjust the brightness (0-255). A setting of 0 will not produce any

light output

3. Select your desired intensity by pressing the ENTER button to conrm and exit.

STRO - in this mode you can activate and set the strobe rate.

1. Tap the either the MENU button until “ ” is displayed, press ENTER.STRO

2. Tap the UP or DOWN buttons to adjust the stobe rate (0-255). A setting of 0 will deactivate the

strobe feature.

3. Select your desired strobe rate by pressing the ENTER button to conrm and exit.

BLND - Blackout or Stand by mode.

1. Tap the either the MENU button until “ ” is displayed, press ENTER. Either Yes or No will be BLND

displayed.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
