Electro Strip
SPECIFICATIONS:
Model: Electro Strip
LEDs: 192 - 64 Red, 64 Green,
& 64 Blue
Weight: 3.3lbs./ 1.5kgs.
Size: 19” (L) x 3.8” (W) x
5.1” (H)
Fuse: 2 Amp
Power Cord Daisy Chain: 33 Fixtures Max.
Working Position: Any Safe position
Duty Cycle: None
DMX Channels: 4
Colors: RGB
Warranty: 1 Year
CAUTION! Please read and
understand these instructions
before installing or operating
this unit.
Operating Instructions:
The Electro Strip has been tested at the factory, there is no assembly required. The unit is ready to
be plugged into a power outlet. This unit is a 4 channel DMX intelligent LED bar. This unit has 4 dif-
ferent operating modes; static color mode, chase mode, color change mode, and DMX controlled.
This unit can be run as a Stand Alone unit or in a Master/Slave configuration. For stand-alone mode,
and Master/Slave configuration settings, see other side.
Power Cord Daisy Chaining: With this feature you can connect the xtures to one another using the
IEC input and output sockets. The quantity that can be connected is 33 xtures maximum. After 33 x-
tures you will need to use a new power outlet. They must be the same xtures. DO NOT mix xtures.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Caution! Never open unit when in use. Always disconnect main power before replacing fuse.
Remember to always replace with the exact same type fuse.
1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
SdAd - Universal DMX Control - DMX Address Setting. This unit allows you to use any univer-
sal DMX-512 controller to LED color and the shutter (strobe). A DMX controller allows you to create unique
programs tailored to your individual needs. Follow the set-up specifications that are included with your DMX
controller.
1. When “SYS” is displayed, press the ENTER button so that “SdAd” is displayed, then press ENTER again.
2. The current address should be displayed. Use the UP or DOWN buttons to nd your desired address. Press
ENTER to set your desired DMX address. Now connect your DMX Controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. For longer cable runs (more than a 100 feet) use a terminator on the last fixture.
5. For help operating in DMX mode consult the manual included with your DMX controller.
A000 - in this mode you can choose one of 23 working modes; 7 static colors with ash, 6
color change modes with adjustable change speed, 7 chase sequences with adjustable chase
speed, adjust able RGB mode, color fade mode with adjustable fade speed, and sound active
mode. The next few sections will detail the working modes.
1. Press the MENU button until you are at the beginning of the system menu. You will know you are at the
beginning when “SYS” is displayed. If “SYS” is displayed press either the UP or DOWN button so that “ACt”
is displayed. When “ACt” is displayed press ENTER. “AXXX” will be displayed, “XXX” represents the displayed
mode.
2. Now using the UP and DOWN buttons scroll through the various programs. See the next four sections for
detailed descriptions of the various working modes. To exit from a mode press the MODE button.
A001 - A007 - there are 7 static colors that can be projected. Flash (strobe) can be added to
your desired color.
1. Once you have followed the directions listed under section “A000” you can now select and run dierent
programs.
2. A001 - A007 are your static color modes. Each number 1-7 represents a dierent color.
3. Press the UP and DOWN buttons to scroll through the dierent colors. Once you have found your desired
color just leave the setting as is. If you would like to add strobing to the color press ENTER, “F.000” will be
displayed. Press the UP or DOWN buttons to adjust the strobing speed. Once you have found your desired
speed press the MODE button once to go back to your color mode. To exit the running modes completely
press the MODE button twice.
A008 - A013 - there are 6 color changing programs to choose from. The speed of the color
change is adjustable in all 6 programs. Flash (strobe) can be added to programs A008 - A011.
1. Once you have followed the directions listed under section “A000” you can now select and run dierent
color changing programs.
2. A008 - A013 are your color changing programs. Each number 8-13 represents a dierent color changing
program.
3. Press the UP and DOWN buttons to scroll through the dierent programs. Once you have found your
desired program press ENTER. “P.XXX” will be displayed, this is program speed adjustment. Use the UP or
DOWN buttons to adjust the speed of the color change. Once you have found your desired color change
speed you can leave the unit as is or press MODE so that your selected program number is displayed. This
mode can also be run by sound activity, adjust the sensitivity knob located on the rear to make the unit more
senstive or less sensitive to sound. Turning the knob clockwise makes it the more sensitive, counter-clockwis
makes it less sensitive.
