GYRO LED

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Introduction:

The Gyro LED is a 7 channel DMX intelligent scanner unit. The Gyro LED has 3 operating modes; sound

active mode, auto program mode, or it can be controlled by a DMX controller. The unit can be run as a stand

alone unit or in a Master/Slave configuration. This unit has been tested at the factory, there is no assembly

required. The unit is ready to be plugged in to a power outlet. To enhance the beams effects you can use a

fog machine. This unit looks good in pairs.

CAUTION! Please read and understand these instructions before installing or operating this unit.

SPECIFICATIONS:

Model: Gyro LED

LED: 1 x 25W LED

Weight: 9.4lbs./ 4.3kgs.

Size: 12.75” (H) x 6” (W) x

5” (L)

Fuse: 2 Amp

Power Consumption: 50W

Supply Voltage: 110V-240V 50/60Hz

Working Position: Any Safe position

Duty Cycle: None

DMX Channels: 7 DMX Channels

Gobos: 11 plus Spot

Colors: 8 Colors + White

Warranty: 1 Year

CAUTION! Please read and

understand these instructions

before installing or operating

this unit.

Fuse Replacement: Locate and remove

the unit’s power cord. Once the cord has

been removed located the fuse holder

located inside the power socket. Insert

a flat-head screw driver into the power

socket and gently pry out the fuse holder.

Remove the bad fuse and replace with a

new one. The fuse holder has a built-in

socket for a spare fuse be sure not to

confuse the spare fuse with active fuse.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

MENUS: To access these menus you must press the ESC button twice and then press the UP or

DOWN buttons until you nd the specic menu you are looking for.

ADDR: At this menu you can set the DMX address. Press the Enter button, and the “A” will start

ashing. Press the UP or Down buttons to nd your desired address. When you have found your

desired address press the Enter button to set it.

SOUN (Sound Active): In this menu you can activate Sound Active mode. Using the Up button

scroll to “SOUN” and press Enter. Either “MAST” (Master in sound mode) or “ALON” (Stand Alone

unit in sound mode) will be displayed. Use the Up and Down buttons toggle between the two modes

and press Enter to make your selection.

AUTO (Auto Program): In this menu you can activate the auto program mode. Using the Up or

Down buttons scroll to “AUTO” and press Enter. Either “MAST” (Master in Auto mode) or “ALON”

(Stand Alone unit in Auto mode) will be displayed. Use the Up and Down buttons toggle between the

two modes and press Enter to make your selection.

RPAN (Reverse Pan): In this menu you can reverse the Pan function. Using the Up button scroll to

“RPAN” and press Enter. Press the Up button until “On” is displayed, and press Enter. This func-

tion works better when you have two units connected in a Master/Slave setup. Have one unit set to

reverse Pan and the other unit left in normal Pan.

RTIL ( Reverse Tilt): In this menu you can reverse the Tilt function. Using the Up button scroll to

“RTIL” and press Enter. Press the Up button until “On” is displayed, and press Enter. This function

works better when you have two units connected in a Master/Slave setup. Have one unit set to re-

verse Tilt and the other unit left in normal Tilt.

RDIS (Display): In this menu you can “ip” the display 180°. Using the Up button scroll to “RDIS”

and press Enter. Either “ON” or “OFF” will now be displayed. If you want to “ip” the display press

the Up button so that “ON” is displayed, and press Enter.

REST (Reset): In this menu you can activate reset function. Using the Up button scroll to “REST”

and press Enter. The unit will now begin to reset.

LOAD: In this menu you can activate reset function. Using the Up button scroll to “LOAD” and press

Enter. The unit will now begin to reset.

UNIVERSAL DMX CONTROL: This unit allows you to use any universal DMX- controller to control head 512

movement, the color wheel, the gobo wheel, and the shutter (strobe). A DMX controller allows you to create

unique programs tailored to your individual needs. Follow the set-up specifications that are included with

your DMX controller.

1. The Gyro LED is a 7 Channel DMX unit.

2. Press the Up or Down buttons until “ADDR” is displayed, an press Enter.

4. Use the Up and Down buttons to find your desired address and press Enter. Connect your DMX Controller.

5. Use the controller’s faders to control the various DMX fixture traits.

6. For longer cable runs (more than a 100 feet) use a terminator on the last fixture.

7. For help operating in DMX mode consult the manual included with your DMX controller.
