STEALTH WASH
ZOOM
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Introduction:
The Stealth Wash Zoom is a unique DMX intelligent moving head unit. The Stealth Wash Zoom has
3 operating modes; sound active mode, show mode, or controlled via DMX controller. The Stealth
Wash Zoom has 2 DMX Channel modes; 5 or 16 channels. The unit can be run as a stand alone unit
or in a Master/Slave set up. This unit has been tested and there is no assembly required. Follow the
instructions on the following pages to operate your fixture. To enhance the beams effects you can
use a fog machine.
CAUTION! Please read and understand these instructions before installing or operating this unit.
SPECIFICATIONS:
Model: Stealth Wash Zoom
Supply Voltage: 100V-240V 50/60Hz
LED: 7 x 12W RGBW LED’s
Weight: 10lbs./ 4.5 kgs.
Size: 6.22” (L) x 9.4” (W) x 12.63” (H)
Fuse: 2 Amp
Power Consumption: 95W
Working Position: Any Safe position
Duty Cycle: None
DMX Channels: 2 DMX Channel Modes:
5 Channel Mode &
16 Channel Mode
Colors: RGBW
Warranty: 1 Year
CAUTION! Please read and
understand these instructions
before installing or operating
this unit.
Fuse Replacement: Locate and remove
the unit’s power cord. Once the cord
has been removed, the fuse holder is
located inside the power socket. Insert
a flat-head screw driver into the fuse
holder and gently pry out the holder.
Remove the bad fuse and replace with
a new one. The fuse holder has a built-in
second holder for a spare fuse.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
AXXX: In this menu you can set the DMX address. Press the Up or Down buttons until “AXXX” is dis-
played. “XXX” is the current displayed DMX address. Press Enter and use the UP or Down buttons to
nd your desired address. When you have found your desired address press the Enter button to set
it.
CHNd: The Stealth Wash Zoom has 2 DMX channel modes; 5 channel mode and 16 channel mode.
In this menu you can select your desired channel mode. Press the Up or Down buttons until “CHNd” is dis-
played and press ENTER. Either “16CH” or “5CH” will be displayed. Use the Up and Down buttons
to toggle between the two modes and press Enter to make your selection and press Menu to exit.
SPNd (Sound Active Speed): In this menu you can adjust the sound active moving speed. Press
the Up or Down buttons until “SPNd” is displayed and press ENTER. Either “Low” (Low Speed) or
“High” (High Speed) will be displayed. Use the Up and Down buttons to toggle between the two
speeds and press Enter to make your selection. Press the Menu button to exit.
SLNd (Master/Slave): In this menu you can designate the xture as either a Master or Slave in a
master-slave set up. Press the Up or Down buttons until “SLNd” is displayed and press Enter. Either
“Mast” or “SL 1 will be displayed. Use the Up and Down buttons to nd your desired setting and
press Enter to make your selection. Press the Menu button to exit
SHNd (Show Mode): In this menu you can activate 1 of the 8 show mode’s. Press the Up or Down
buttons until “SHNd” is displayed and press Enter. 1 of 8 shows will be displayed. Use the Up and
Down buttons nd your desired show and press Enter to make your selection. Press the Menu button
to exit
Soun (Sound Active): In this menu you can activate Sound Active mode. Press the Up or Down buttons
until “Soun” is displayed and press Enter. Either “On” or “O” will be displayed. Use the Up and
Down buttons toggle between the choices and press Enter to make your selection. Press the Menu
button to exit.
PAn (Reverse Pan): In this menu you can reverse the Pan function. Press the Up or Down buttons
until “PAn” is displayed and press Enter. Press the Up or Downs buttons until “On” is displayed, and
press Enter. Press the Menu button to exit. This function works better when you have two units con-
nected in a Master/Slave setup. Have one unit set to reverse Pan and the other unit in normal Pan.
tIL ( Reverse Tilt): In this menu you can reverse the Tilt function. Press the Up or Down buttons until
“tIL” is displayed and press Enter. Press the Up or Downs buttons until “On” is displayed, and press
Enter. Press the Menu button to exit. This function works better when you have two units connected
in a Master/Slave setup. Have one unit set to reverse Tilt and the other unit in normal Tilt.
dISP (Display): In this menu you can “ip” the display 180°. Press the Up or Down buttons until
“dISP” is displayed and press Enter. Either “ON” or “OFF” will now be displayed. If you want to “ip”
the display press the Up button so that “ON” is displayed, and press Enter. Press the Menu button to
exit.
rFAC (Default Setting): In this menu you can reset the unit to it default settings. Press the Up or
Down buttons until “rFAC” is displayed and press Enter. Select “On” and press Enter to revert to
default settings. Press the Menu button to exit without any changes.
rSt (Reset): In this menu you can activate reset function. Press the Press the Up of Down buttons
until “rSt” is displayed and press Enter. The unit will now begin to reset. Press the Menu button to
exit.
