TRIO PAR LED
SPECIFICATIONS:
Model: Trio Par LED
Voltage: 100V-240V 50/60Hz
LEDs: 9 x 4W RGBW LEDs
1 x 15W RGBW LED
24 SMD White LEDs
Fuse: 5A
Weight: 2lbs./ 0.9kgs.
Working Position: Any Safe position
Duty Cycle: None
DMX Channels: 4 DMX Channel Modes:
9/13/22/26 Channels
Colors: RGBW
Warranty: 1 Year
CAUTION! Please read and under-
stand these instructions before
installing or operating this unit.
Operating Instructions:
The Trio Par LED has been tested at the factory, there is no assembly required. The unit is ready to
be plugged into a power outlet. This unit has 4 DMX channel modes; 9/13/22/26 channels. It has
6 operating modes; RGBW dimmer mode (outside ring, center LEDs, and SMD LEDs), color jump
change mode, pulse change mode, fade mode, sound active mode, or DMX control.
Fuse Replacement: Disconnect the unit from its power source. Remove the power cord from the
unit. Once the cord has been removed, you will find that the fuse holder is located inside the power
socket. Insert a flat-head screw driver into the power socket and gently pry out the fuse holder.
Remove the bad fuse and replace with a new one. The fuse holder also has a holder for a spare fuse.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Caution! Never open unit when in use. Always
disconnect main power before replacing fuse.
Remember to always replace with the exact same
type fuse.
1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
DMX Mode:
Operating through a DMX controller give the user the freedom to create own programs tailored s their
to their own individual needs. The Trio Par has 4 DMX channel modes; 9/13/22/26 channels. See the
chart below for the DMX traits and values.
1. This function will allow you to control each individual fixture’s traits with a standard DMX 512
controller.
2. To run your fixture in DMX mode plug the fixture in and press the MENU or UP and DOWN
buttons until “Addr” is displayed. “A.XXX” will now be displayed. “XXX” represents the current
displayed address. Use the UP or DOWN buttons to select your desired DMX address.
3. Press ENTER again to select your desired DMX channel mode. Use the UP and DOWN buttons
to find your desired DMX channel mode.
4. After you have chosen your desired DMX address and DMX channel mode, press ENTER and
plug in the fixture via the XLR connections to any standard DMX controller.
Jump Change Mode:
1. Plug the fixture in and press the MENU or UP and DOWN buttons until “ASC -” is displayed.
2. Press the ENTER button to adjust the Jump speed. Use the UP and DOWN buttons to adjust the
speed. The speed can be adjusted between “AS.00” (slowest) to “AS.12” (fastest).
3. After you have adjusted the program speed you can activate strobing by pressing the MENU
button until “FLAS” is displayed and press ENTER. The Flash can be adjusted between “FL.00”
(flash off) to “FL.12” (fastest flash).
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Menu Submenu Channnels Operating Mode
A r A.001-512 9/13/22/26-Ch DMX a ress/cha el dd dd nn
mode
ASC- AS.00-12 Jump change
mode/speed
ACC- AC.00-12 Pulse change
mode/speed
FAde FA.00-12
Fade
change/speed
SOUF SF.00-12 Pulse change o s und
control/sensitiveness
r1-- r1.00-12 Central red adjusts
brightness
g1-- g1.00-12 Center green adjust
brightness
b1-- b1.00-12 Center blue adjust
brightness
u1-- u1.00-12 Center white adjust
brightness
r2-- r2.00-12 Red intensity
g2-- g2.00-12 green intensity
b2-- b2.00-12 blue intensity
u2-- u2.00-12 white intensity
u3-- u3.00-12 SMD white intensity
FLAS FL.00-12 Strobe peed s
