ELECTRIC OPERATED, PISTON COMPRESSORS
EMAX designs and manufactures products for safe operaon. However, operators and maintenance persons are
responsibile for maintaining safety. safety precauons are included provide a guideline for minimizing the All to
possibility accidents property while equipment operaon. of and damage is in Keep these instrucons for reference.
EMNP000001 0810
Oper
ang
Instrucons
EMAX
Electric
Oper
ated,
Pist
on
Compr
essors
2
Contents
Page No.
Page No.
Model Specificaon Charts
............................... 2-3
Descripon
............................................................ 3
Safety Informaon
................................................ 4
Tag Denions ................................................ 4
Basic Guidelines .............................................. 4
Breathable Air ................................................. 4
Pressurized Components .................................... 4
Personal Protecve Equipment .......................... 4
Inspecon
.............................................................. 4
Forkli Safety .................................................. 5
Liing Safety ................................................... 5
Installaon
......................................................... 5
Area ..................................................................... 5
Piping Safety 5...................................................
Piping / Tank Installaon ............................. 6
Electronic Auto Drain (if equipped) ............. 6
Electrical Safety 7...............................................
Wiring Installaon 7..........................................
Operaon
............................................................... 8
Safety Rules ..................................................... 8
Start Up ............................................................... 9
Connuous Run Feature ..................................... 9
Maintenance
.......................................................... 9
Safety Steps ..................................................... 9
Belt Adjustment .............................................10
Changing Oil ...................................................10
Safety Valve ...................................................10
Tank .......................................................................... 10
Maintenance Schedule
........................................ 11
Troubleshoong
................................................... 11
Warranty
................................................................ 12
EMAX Electric Operated, Two-Stage, 5-10 Hp Piston Air Compressors
Model
EP05H080I1
EP07H080V1
EP10H120Y1
EP10H120Y3
Tank Type
Dimensions
L•W•H
(inches)
Horizontal
76 x 30 x 56
Horizontal
76 x 30 x 56
Horizontal
78 x 32 x 50
Horizontal
78 x 32 x 50
Model
EP05V080I1
EP07V080V1
EP10V120Y1
EP10V120Y3
Tank Type
L•W•H
Dimensions
(inches)
Vercal
34 x 24 x 72
Vercal
34 x 24 x 72
Vercal
50 x 32 x 78
Vercal
50 x 32 x 78
Tank Size
80 Gallon
80 Gallon
120 Gallon
120 Gallon
Description
5HP
Single Phase
7.5HP
Single Phase
10HP
Single Phase
10HP
Three Phase
SCFM @ 175 psi
17.0
26.0
35.0
35.0
Max PSI
175
175
175
175
Motor HP
5HP
7.5HP
10HP
10HP
Motor RPM
1750
1750
1750
1750
Voltage
208V/230V
208V/230V
208V/230V
208/230/460/575
Pump Model
APP2I0524T
APP4V1043T
APP3Y1544T
APP3Y1544T
Pump RPM
650
640
600
600
Noise DB(A)
73
73
76
76
Outlet Connecon
NPT 3/4”
NPT 3/4”
NPT 1”
NPT 1”
Weight
(
±5 lbs.)
715
958
1095
1095
Shipping Weight
800
1043
1242
1242
