Fast Wireless Charging
SmartSet
®
Clock Radio
with Bluetooth Stereo Speaker,
USB Charge Out and
1.2” Blue LED Display
OWNER’S MANUAL
ER100120
1
WARNING
TO PREVENT ELECTRIC SHOCK HAZARD, DO NOT CONNECT TO MAINS POWER SUPPLY WHILE
GRILLE IS REMOVED.TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE.
POUR ÉVITER TOUT DANGER DE CHOC ÉLECTRIQUE, NE PAS RACCORDER AU SECTEUR TANT QUE
LA GRILLE N'APAS ÉTÉ REMISE EN PLACE.POUR RÉDUIRE LE RISQUE D’INCENDIE OU DE CHOC
ÉLECTRIQUE, NE PAS EXPOSER CET APPAREIL SOUS LA PLUIE
ET L’HUMIDITÉ.
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions. Keep these instructions. Follow all instructions. Heed all warnings.
2) Do not use this apparatus near water.
3) Clean only with dry cloth.
4) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
5) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
6) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
7) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
8) Only use attachments / accessories specified by the manufacturer.
9) Unplug this apparatus during lightning storms or when unused for long periods of time.
10) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
11) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
12) The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such
as vases, shall be placed on apparatus.
l'appareil ne doit pas être exposé à des égouttements d'eau ou des éclaboussures et de plus
qu'aucun objet rempli de liquide tel que des vases ne doit être placé sur l'appareil.
13) Mains plug is used as disconnect device and it should remain readily operable during intended use. In order to disconnect
the apparatus from the mains completely, the mains plug should be disconnected from the mains socket outlet completely.
La prise secteur est utilisée comme dispositif de déconnexion et devrait rester facilement utilisable pendant l'utilisation
prévue. Afin de déconnecter l'appareil decomplètement le secteur, la prise secteur doit être déconnectée duprise de courant
complètement.
14) Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
les batteries (bloc de batteries ou batteries installées) ne doivent pas être exposées à une chaleur excessive telle que celle
du soleil, d'un feu ou d'origine similaire.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
ATTENTIN: Pour éviter tout danger de choc électrique, ne pas raccorder au secteur tant que la grille n'apas été remise en place.
* Les marquages sont inscrits en bas de l'appareil. Les précautions d'emploi sont inscrites en bas de l'appareil.
La prise du secteur ne doit pas ētre obstruée ou doit ētre facilement accessible pendant son utilisation.
Pour étre complètement déconnecté de l'alimentation d'entrée, la prise doit ētre débranchée du secteur.
Les piles ne doivent pas ētre exposées à de forte chaleur, tel qu'á la lumière du soleil, au feu ou autres choses de semblable.
La prise du secteur est utilisé pour déconnecter le système.
La prise du secteur ne doit pas être obstruée ou doit être facilement accessible pendant son utilisation.
Pour être complètement déconnecté de l’alimentation d’entrée, la prise doit être débranchée du secteur.
L’adaptateur AC/AC de l’appareil est utilisé pour déconnecter le système.
L’adaptateur AC/AC de l’appareil ne doit pas être obstrué ou doit être facilement accessible pendant son utilisation.
Pour être complètement déconnecté de l’alimentation d’entrée, l’adaptateur AC/AC de l’appareil doit être déconnecté du secteur.
2
Important Notes
FCC Information
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help. This device complies
with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)
This device may not cause harmful interference, and
(2)
This device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
Thank you for purchasing this Emerson SmartSet
®
Dual Alarm Clock Radio. This clock radio
uses Emerson's patented SmartSet
®
Automatic Time Setting System. The first time you
connect this clock radio to your AC outlet, and after every power interruption, within
seconds the clock will automatically set itself to the correct Year, Month, Date, Day, and
Time. In addition, all changes from Standard Time to Daylight Saving Time, and back to
Standard Time, are made automatically. There are dual alarms that can be set and used
independently, and both alarms can be programmed for everyday operation, weekdays only,
or weekends only. There is a longlife lithium battery installed in this clock radio when you buy it.
This battery can maintain the time and alarm settings for 2 years, or even longer. We have
taken every precaution to make sure this radio was in perfect working order when it left our
factory.
3
Preparation For Use
• Remove the radio from the carton and remove all packing material from the radio. Save the
packing material, if possible, in case the radio ever needs to be serviced or transported.
The original carton and packing material is the only safe way to pack your radio to
protect it from damage in transit.
• Remove any descriptive labels or stickers on the front or top of the cabinet. Do not remove any
labels or stickers from the back or bottom of the cabinet.
• Note the serial number on the bottom of your radio and write this number in the space provided
on the Limited Warranty page of this manual.
• Place your radio on a level surface such as a table, desk or shelf, convenient to an AC outlet,
out of direct sunlight, and away from sources of excess heat, dirt, dust, moisture, humidity, or
vibration.
• Unwind the Line cord connecting the AC adapter to an AC outlet. Extend the Antenna Wire fully
and orient it to provide the best FM reception.
If you encounter any problems with the set up or operation of this item, please call the Emerson Consumer
Products Corp., Customer Service Hotline, toll free, at 1-800-898-9020.
4
Package Contents
● ER100120 ● Power Adapter ● Owner’s Manual ● Read This Insert (Quick Start Guide)
5
Location of Controls and Indicators
FRONT PANEL
TOP PANEL
BACK PANEL
1. ALARM 1 RADIO / BUZZER Indicators 15. EQ Equalizer / YEAR Button
2. AM Indicator ('On'=AM, 'Off'=PM) 16. STORE / DATE Button
3. AUX IN Indicator 17. TUNE DOWN Button
4. Qi Wireless Charging Indicator 18. TUNE UP Button
5. Day of Week Indicator 19. NEXT / TIME ZONE Button
6. ALARM 2 RADIO / BUZZER Indicators 20. PREVIOUS / WEEK Button
7. BT Indicator ('Solid'=Bluetooth connected) 21. VOLUME + / ALARM 1 Button
8. MHz Indicator (FM Radio Mode / Frequency) 22. VOLUME - / ALARM 2 Button
9. LOW BATTERY Indicator 23. Backup Battery Compartment
10. SLEEP Button 24. USB CHARGE OUT Port
11. SNOOZE / DIMMER (4-Level and Off) Button 25. DC Power IN Jack
12. POWER ('ON'/Standby) Button 26. Earphone Jack
13. PLAY / PAUSE / TIME / AMS Button 27. AUX-IN Jack
14. SOURCE Button 28. FM Antenna Wire
6
Setting the Time Zone
Initial Default Setting at Clock Mode
IMPORTANT: The first time you connect your new SmartSet
®
clock radio to the AC outlet the internal
computer will automatically set the time correctly for the Eastern Time Zone, which is the initial default setting.
The display will scan for a few seconds and then show the correct Day and Time in the Eastern zone. If you
live in the Eastern Time zone, there's nothing else to do. Your clock is set correctly and running. If you do not
live in the Eastern Time zone you must change the default zone display to your own zone. You only do this
one time and the SmartSet
®
will remember the new default zone setting and will always return to that setting
after power interruption.
There are 7 time zones programmed into your SmartSet
®
clock radio as follows:
ZONE 01 — Atlantic Time ZONE 02 — Eastern Time (Default Setting)
ZONE 03 — Central Time ZONE 04 — Mountain Time
ZONE 05 — Pacific Time ZONE 06 — Yukon Time
ZONE 07 — Hawaiian Time
1. Press and hold TIME ZONE 2. Press UP or DOWN
Note: Time Zone and Clock Setting can only be adjusted in Standby Mode, where the function of Radio,
Bluetooth and AUX are disabled (Indicator of MHz, BT and AUX are Off).
7
Setting the Clock Manually
Date Display and Adjustments
To see the current date at any time, press the DATE button. The
display changes from time to Month and Date (MM.DD).
For example, Apr 16th will appear as ‘4.16’. When you release the
DATE button the display returns to the current time.
To adjust the Date manually, keep holding the DATE button and press the UP or DOWN button.
Year Display and Adjustments
To see the current year, depress the YEAR button, the display
changes from time to year. When you release the YEAR button, the
display returns to the current time.
To adjust the Year manually, keep holding the YEAR button and
press the UP or DOWN button.
Manual Time Adjustments
Some people like to set their clock 5 to 10 minutes faster to make
sure that they will always be on time. Even though the SmartSet
®
sets the time by itself, you still have the option of adjusting the time
manually if you wish.
To manually adjust the time display press and hold the TIME button,
and press either the UP or DOWN button to advance or reverse the time as desired.
Each press of the UP or DOWN button will change the display by one minute. If you hold the UP or DOWN
button the display will continue to change. The display will change slowly at first, one minute at a time. But if
you continue holding the UP or DOWN button, the display will change rapidly.
Note: If you manually adjust the time, your new setting is entered into the SmartSet
®
memory. If the power is
interrupted, the display will return to your new setting, not the original setting, when the power is restored.
Daylight Saving and Leap Year Adjustments
All Daylight Saving and Leap Year adjustments are made automatically by
the SmartSet
®
internal computer as follows:
Start of Daylight Saving Time:
At 2:00 AM on the 2nd Sunday in March, the clock will automatically advance to 3:00 AM.
End of Daylight Saving Time:
At 3:00 AM on the 1st Sunday in November, the clock will automatically reset to 2:00 AM.
Note: If you do not want the clock to adjust itself according to Daylight Saving time automatically, you can
disable it by pressing and holding the TIME and WEEK buttons for 1 second, then the display will show ‘dSt’ –
‘OFF’, which means the auto Daylight Saving time is disabled; by doing so again, the display will show ‘dSt’ –
‘ON’, which means the auto Daylight Saving time is enabled.
Leap Year:
At 12:00 Midnight on February 28th, the calendar display will change to ‘2.29’.
8
Setting the Alarm
Note: Alarm settings can only be checked and adjusted in Standby Mode, where the function of Radio,
Bluetooth and AUX are disabled (Indicator of MHz, BT and AUX are Off).
Your SmartSet
®
clock radio has two separate alarms that can be set and used independently. You may use
the alarms to wake two people at different times, or you may use one alarm for weekdays and the other for
weekend wake up time.
Adjust the Wake Up Time
The procedure for adjusting the wake up time is the same for both Alarm 1 and Alarm 2.
⚫ Press and hold either the ALARM 1 or ALARM 2
button. The display will change from the current
time to the Alarm 1 or Alarm 2 wake up time.
⚫ While holding the ALARM 1 or ALARM 2 button,
press either the UP or DOWN button to advance
or reverse your desired wake up time.
⚫ When the desired wake up time appears on the
display, release the UP or DOWN button to store
the setting.
Note: Be sure that you have set the wake up time
correctly by observing the AM indicator. If the AM
indicator is 'On' the wake up time is 'AM’. If the AM
indicator is 'Off'. the wake up time is ‘PM’.
⚫ When the desired wake up time (AM or PM)
appears on the display, release the ALARM 1 or ALARM 2 button.
