EM6053

Video over UTP 200m

ENGLISH

EM6053 Video over UTP 200m

Table of contents

1.0 Introduction ........................................................................................................... 2

1.1 Functions and features ...................................................................................... 2

1.2 Packing contents ............................................................................................... 2

2.0 What do you need in dierent scenarios ................................................................ 3

2.1 Before you get started ....................................................................................... 3

2.2 Connect one camera on a large distance ........................................................... 3

3.0 UTP Pin layout ...................................................................................................... 4

4.0 How to connect a Video Balun Set indifferent situations ........................................ 4

4.1 One camera and one Video Balun Set ............................................................... 5

4.2 Connect a EM6029 30x Optical Zoom camera with one Video Balun Set........... 5

4.3 Two camera’s and two Video Balun Sets ........................................................... 6

4.4 Three camera’s and three Video Balun Sets ...................................................... 6

4.5 Four camera’s and four Video Balun Sets .......................................................... 7

5.0 Frequently Asked Questions and other related information .................................... 8

6.0 Service and support ............................................................................................... 8

7.0 Warning and points of attention ............................................................................. 8

8.0 Warranty conditions ............................................................................................... 9

1.0 Introduction

Congratulations with the purchase of this high-quality Eminent product! This product

has undergone extensive testing by Eminent’s technical experts. Should you

experience any problems with this product, you are covered by a ve-year Eminent

warranty. Please keep this manual and the receipt in a safe place.

1.1 Functions and features

With the EM6053 Video Balun Set you are able to connect camera’s on a large

distance without using the limited BNC cable length of 20m. Using the EM6053 Video

Balun Set you can reach up to 200m distance, and connect several camera’s using

just one UTP cable.

The best and easiest way to use the EM6053 Video Balun Set is to use one Video

Balun Set on one camera with a prefabricated UTP cable (like EM6062).

1.2 Packing contents

The following parts need to be present in the packing:

• EM6053 Video Balun Set

Produkt Specifikationer

Mærke:	Eminent
Kategori:	Sikkerhed
Model:	EM6053
Produktfarve:	Grå
Maksimal opløsning:	- pixel
Maksimal overførselsafstand:	200 m
Understøttede kabeltyper:	Cat5
