-3Digitdisplay
-NTCinputor
PTCinputor
2-wirePT-100Inputor
2-wirePT-1000Input(Itmustbedeterminedinorder)
-ON/OFFTemperatureControl
-Compressor,FanandDefrostoutputs
-EvaporatorandCabinetsensorinputs
-CompressorOKdigitalinput
- Adjustablehysteresisvalue
-Determinecompressorworkingperiodincaseof
Cabinetprobedefect
-Defrostoutputcontrollingparameters
-Fanoutputcontrollingparameters
-Passwordprotectionforprogrammingmode
IntroductionBrochure.ENGESM-3770-D01V0307/14
ESM-3770-D
Controller
P/N:ESM-3770-D
c
a
2
3
41
5 6 7 8 9 10 11 12
CATII
DEF. FAN
OUT
OUT OUT
(2x5 )A@250V V(10A@250V )V
Outputs
24 VW
(-%15,+%10)
50/60Hz
1.5VA
+
--
+
Comp.OK
8...32VZ
A BC D E FG HI /
/
U
V W Z/
/
0 1 0 0
SupplyVoltageA
12
09
PTC(Note-1)
InputType
BC
Scale(°C)
-50°C
150°C
-19.9°C 99.9°C
PT 100,IEC751(ITS90)
ESM-3770-D (77x35DIN)
24V (-%15,+%10)50/60HzW
2
-50°C
400°C
11
PT 100,IEC751(ITS90)
13
-19.9°C
99.9°C
PT 1000,IEC751(ITS90)
15
-50°C
400°C
14
PT 1000,IEC751(ITS90)
PTC(Note-1)
-19.9°C
99.9°C
2
18
NTC(Note-1)
-50°C
100°C
19
NTC(Note-1)
-19.9°C
99.9°C
COMP.
TemperatureSensor
Input (NTC,PTC,
PT-100orPT-1000)
Cabinet Evaparator
Sensor Sensor
DigitalON/OFFCoolingController
-Cooling Applications
-Economic
-EasytoUse
SPECIFICATIONS
INPUT
NTC:
PTC:
Thermoresistance(RTD):
MeasurementRange:
Accuracy:
ColdJunctionCompensation:
SensorBreakProtection:
SamplingCycle:
CONTROL
ControlForm:
ON/OFFhysteresis:
OUTPUTS
ControlOutput:
DISPLAY
ProcessDisplay:
LEDIndicators:
NTC(10k @25°C)
PTC(1000 @25°C)
2-wirePT 100,PT 1000
(IEC751)(ITS90)
Itisinorderinginformation
±1%ofscale
Automatically
±0.1°C/1°C
Upscale
3samplespersecond
ON/OFF
Itcanbeconfiguredbytheuser
CompressorOutRelay(10A@250V atresistiveload)
DefrostOutRelay(5A@250V atresistiveload)
FanOutRelay(5A@250V atresistiveload)
ESM-3770-D:14mmRed3digitsLEDDisplay
SV(Red),CompressorOutput Active(Red),Error(Red),
FanOutput Active(Red),DefrostOutput Active(Red),
W
W
V
V
V
ENVIRONMENTAL RATINGSandPHYSICAL
SPECIFICATIONS
OperatingTemperature:
Humidity:
ProtectionClass:
Weight:
Dimension:
PanelCut-Out:
0...50°C
0-90%RH(nonecondensing)
IP65atfront,IP20atrear
ESM-3770-D:150gr
ESM-3770-D:77x35mm,Depth:62.5mm
ESM-3770-D:71x29mm
ElectricalWiring
OrderingInformation
Note-1:IfinputtypeisselectedPTCorNTC(BC=12,15,18,19),
Temperaturesensorisgivenwiththedevice.Forthisreason,
IfinputtypeisselectedasPTC,sensortype(V=0,1or2)or
IfinputtypeisselectedasNTC,sensortype(V=0,3or4)mustbe
declaredinorderinginformation.
1
CompressorOutput
(10 A@250V atresistiveload,1NO)V
Outputs
E
01
FG
01
HI
DefrostOutput(5 A@250V atresistiveload,1NO)V
FanOutput(5 A@250V atresistiveload,1NO)V
TemperatureSensorthatisgivenwithESM-3770-D
V
0
None
1
PTC-M6L40.K1.5
(PTC AirProbewith1.5msiliconcable)
2
PTCS-M6L30.K1.5.1/8”
(PTCLiquidProbewith1.5msiliconcable)
3
NTC-M5L20.K1.5 (NTCProbe,thermoplasticmouldedwith
1.5mcableforcoolingapplication)
4
NTC-M6L50.K1.5 (NTCProbe,stainlesssteelhousingwith
1.5mcableforcoolingapplication)
9
Customer
POWERSUPPLY
SupplyVoltage:
24V (-%15,+%10)50/60Hz-1.5VAW
Cooling
In package ,
- One piece unit
- Two pieces mounting clamps
- One piece instruction manual
A visual inspection of this product for possible damage occured during shipment is
recommended before installation. It is your responsibility to ensure that qualified
mechanical and electrical technicians install this product.
If there is danger of serious accident resulting from a failure or defect in this unit, power
off the system and the electrical connection of the device from the system.
The unit is normally supplied without a power supply switch or a fuse. Use power switch
and fuse as required.
Be sure to use the rated power supply voltage to protect the unit against damage and to
prevent failure.
Keep the power off until all of the wiring is completed so that electric shock and trouble
with the unit can be prevented.
Never attempt to disassemble, modify or repair this unit. Tampering with the unit may
results in malfunction, electric shock or fire.
Do not use the unit in combustible or explosive gaseous atmospheres.
During the equipment is putted in hole on the metal panel while mechanical installation
some metal burrs can cause injury on hands, you must be careful.
Montage of the product on a system must be done with it’s fixing clamps. Do not do the
montage of the device with inappropriate fixing clamp. Be sure that device will not fall
while doing the montage.
It is your responsibility if this equipment is used in a manner not specified in this
instruction manual.
separate
Before beginning installation of this product, please read the instruction
manual and warnings below carefully.
Installation
c
Warranty
EMKO Elektronik warrants that the equipment delivered is free from defects in material and
workmanship. This warranty is provided for a period of two years. The warranty period starts from
the delivery date. This warranty is in force if duty and responsibilities which are determined in
warranty document and instruction manual performs by the customer completely.
Maintenance
Repairs should only be performed by trained and specialized personnel. Cut power to the device
before accessing internal parts.
Do not clean the case with hydrocarbon-based solvents (Petrol, Trichlorethylene etc.). Use of
these solvents can reduce the mechanical reliability of the device. Use a cloth dampened in ethyl
alcohol or water to clean the external plastic case.
