Side 1/20
A6767 / Rev.2 www.entes.com.tr
MCB-120/121 MULTIFUNCTION DIGITAL TIME RELAY
With 1 CO Contact
Operating Manual
Dudullu OSB; 1. Cadde; No: 23 34776 Umraniye - ISTANBUL / TURKEY
Tel : Fax : +90 216 313 01 10 +90 216 314 16 15
12
Precautions for Installation and Safe Use
If below precautions are not properly observed and carried out, it may result in cases with injury or
death.
· Disconnect power before working on the device.
· When device is connected to the network, do not remove the front panel.
· Do not clean the device with solvent or similar items. Only clean with dry cloth.
· Verify correct terminal connections before energizing the device.
· Install the device on the electrical panel.
· Contact your authorized reseller in case problems occur with your device.
·No responsibility is assured by the manufacturer or any of its subsidiaries for any
consequences rising out of not following above precautions.
1. INTRODUCTION
MCB-120/121 is a multifunction digital timer with 1 CO contact. It offers wide time adjustment range
between 0.1-9999 seconds/minutes.
1.1 Application
MCB-120/121 has 17 different functions with wide adjustable time ranges. The main application area
is the industrial and automation control systems.
The device has two dry contacts for START and STOP inputs.
1.2 Product Features
MCB-125/126 has the following features:
· 85-315 VAC/DC - MCB-125
10-30 VAC/DC - MCB-126
· 17 different functions
· 0.1-9999 seconds/minutes time range
· 1 relay output
· Start-Stop dry contact inputs
· Memorizing remaining time of function in case of a power outage
· Custom design LCD with green backlight
· SET, ESC, UP, DOWN buttons are located on front panel for easy programming
· PK25 DIN Rail mounting
1.3 Hardware Features
To operate functions with external triggering, the device has the necessary START and STOP dry contacts.
LCD
UP BUTTON
SET BUTTON
ESC BUTTON
DOWN BUTTON
Stop
Start
L N 4 5 6
C NCNO
R1
U
