General ........................................................2-3
Specifications ................................................ 3
Installation ...................................................... 4
Setup ........................................................... 4-5
Operation ....................................................... 5
Cleaning & Maintenance .........................6-7
Parts Diagram ................................................ 8
Wiring Diagram (236ECEM1) ...................... 9
Wiring Diagram (236ECEM2) ....................10
Wiring Diagram (236ECEM3) 11 .....................
1. This manual specifies important operation, maintenance, and safety information. Please read carefully.
2. After unpacking, please check to ensure your machine has not been damaged during shipping.
Please notify a qualified technician regarding all questions or concerns before installing. Please note that
the machine's packaging material, including plastic bag and Styrofoam, can be dangerous and should be
kept out of reach of children.
3. There is an identification label on the unit. Before operating, please check to ensure the power source
corresponds to the rating shown on the identification label. The manufacturer is not responsible for issues
resulting from improper installation and usage.
4. Make sure to use a power source that corresponds with the unit's power rating.
5. Please use No Fuse Breaker (NFB) that conforms to the safety regulation separately. Do NOT use a socket.
The NFB should have a minimum contact space of 3 mm and provide electrical spike and drain protection.
The ampere must be sucient for providing the required electric current to this machine.
6. Be sure to use a grounded power source to prevent electric shock and ensure the safety of this machine
and its operators.
7. The machine must be used in accordance with its original design. Additional use is inappropriate and
dangerous.
8. The steam wand, hot water wand, and brewing group can reach very hot temperatures. Use caution while
operating.
9. Please follow all cleaning and maintenance instructions specified in this manual in order to ensure peak
operating eciency.
I N D E X
G E N E R A L
Note: Save these instructions for future reference.
