Door View with Display
Art.nr. 36-5399-01 Model JY8028-Black
36-5399-02 JY8028-Gold
Please read theentire instruction manual before using theproduct and save it
for future reference. We reserve theright for any errors in text or images and any
technical problems please contact our Customer Services.
Safety
• Read theentire instruction manual before mounting.
• The product must not be disassembled.
• The batteries must never be disposed of by throwing them into open flames.
• This product is not suited for use in temperatures below 0 °C.
3. Thread thecamera’s cable through thehole from theoutside of thedoor.
Hold thecamera in place against thedoor. The camera should not be Note:
twisted during installation as this might damage its cable. Make sure Note:
thearrow on thecamera unit is facing upwards. Otherwise theimage will be
displayed upside down. The camera gasket should be mounted between
thecamera unit and thedoor.
4. Peel thebacking paper off thedisplay mount’s self-adhesive strip.
Thread thecamera cable through thedisplay mount and theselected tube.
Press thedoor mount onto theinside of thedoor with thescrew hole facing
downwards.
5. Use thetool to tighten thetube into place so that it holds thecamera in
place on theoutside of thedoor.
Inserting batteries
Parts:
1. Display unit
2. Display mount
3. Screw
4. Tubes (3 pcs)
5. Camera
6. Gasket
7. Mounting tool
Installation
1. Measure thethickness of thedoor and select thecorrect length tube for
spanning thedoor width.
- Use theshort tube for door thicknesses spanning 38–62 mm.
- Use themedium tube for door thicknesses spanning 62–86mm.
- Use thelong tube for door thickness spanning 86–110 mm.
2. Select adesired location in thedoor for mounting thecamera and drill ahole
at this location. The door viewer is designed to fit 14–22 mm diameter holes.
6. Press thecamera cable’s
terminal lead securely onto
theterminal connector on
theback side of theviewer.
The camera will only work if its
cable is connected as shown
in thepicture with thearrow
facing upwards.
7. Make sure thecable flows smoothly without any sharp kinks.
Note: Make sure that thecable is not damaged during mounting it to
thedisplay mount. The cable must not protrude outside therectangular
space at theback of thedisplay. Any protrusion may cause arisk of
damaging thecable by pinching it against thedisplay mount during mounting.
8. Mounting thedisplay onto thedisplay mount.
- Remove thescrew from thedisplay mount’s underside.
- The display has one insertion slot that fits the display mount’s upper
portion. Tilt thedisplay’s lower portion outwards abit and press it
securely into place.
- Press in thedisplay’s lower portion against thedoor and screw it
securely into place from theunderside.
• Press down on thebattery cover and slide outwards to release it.
• Insert two AAA/LR03 batteries (sold separately) according to themarkings
on theinside of thebattery cover. The markings show which poles should
be facing upwards, making contact against thebattery cover.
Operating instructions
Press [ ] to view thecamera’s image on thedisplay. The image automatically
turns off after 10 seconds to save battery power.
Troubleshooting
The image is displayed
at thewrong angle.
Make sure that thearrow on thecamera is
pointing directly upwards.
The display only turns
on briefly.
Check/change thebatteries.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local authority.
Specifications
Camera 0.3 MP, field of view 105°
Display LCD 2.8 TFT, 320×240 ″
Mounting hole diam 14–22 mm
For door thickness 38–110 mm
Power supply 2 x AAA/LR03 batteries (sold separately)
Display unit 125×68×15 mm
Operating temperature 0 – +40 °C
