Go to fetco.com for the latest versions of all information Page 2 User Guide & Operator instructions MBS-1221 P202Re0August 2024
Specifications and Requirements
Electrical: Supplied with 120V cord & plug
Water inlet fitting Dual Water Inlet Connector Assembly is
included (page 16) terminates to a 1/4 inch male flare
User adjustable to 220-240 volt terminal block
Pressure: 20-75 psig, (138-517kPa) 1½gpm/(5.7lpm)
For Iced tea: brewer is factory calibrated to a non-fluctuating
stable water supply pressure at 45 psi.
Tank Temperature, as set by factory:
200°F (93°C) inside water tank (at sea level)
Iced Tea Batch Temperature-user adjustable
200°F-207°F-/ 93°-98°C
Water supply: (Optimal) 100-150TDS
All beverage equipment must use filtered water
Brew Volume-Coffee: Full Batch 2.20 liters
User adjustable to up to 0.85 gallon/3.25 liters per brew
Iced Tea Dilution Ratio: 1:4 factory set brew to water
Factory setting adds 2.4 gallons of cold water to 0.6
gallon brew for a 1:4 ratio Iced tea
(2.3liter brew/9.1 liter dilution)
Dilution volume is user adjustable from 0-4Gal;0-15.2L
Brew Volume-Iced Tea: Full Batch 11.40 liters/3 gallons
User adjustable to up to 4.9 gallon/18.7 liters per brew
Brew batch and dilution ratio user adjustable
Total Brew Cycle—Factory default setting (Batch 1): 5 minutes=[3:30 minute brew time + 1:30 minute drip delay]
Iced Tea-(Batch 3) 4:30 minutes=[3:00 minute brew time + 1:30 minute drip delay] Batch 2 may be set for either
Brew-Process parameters are user controllable for: Brew Volume, Brew Time, Prewet Percent and Delay,
Drip Delay, Tea Batch Temperature, Dilution Volume and Dilution Timing (with brew or after brewing)
Electrical Specifications for domestic-dual voltage Standard height with brew shelf
Brew Basket
Voltage KW
Brew Volume/Hour
M1221US-1A117-
NEMA 15-5P
Plastic tea “A”
Plastic coffee “B”
1 X 1.7 kW 120 1.7 14.7 4.4 gal/16.5 liters
M1221US-1A117-M
NEMA 15-5P
Plastic tea “A”
Metal coffee “C”
1 X 1.7 kW 120 1.7 14.7 4.4 gal/16.5 liters
M1221US-1X117-PM001
Domestic-Dual Voltage
NEMA 15-5P
Terminal Block
Plastic coffee “B”
4.4 gal/16.5 liters
6-7 gal/22-21 liters
M1221US-1X117-KM001
Domestic-Dual Voltage
NEMA 15-5P
Terminal Block
Plastic coffee “B”
4.4 gal/16.5 liters
6-7 gal/22-21 liters
M1221US-1X117-MM001
Domestic-Dual Voltage
NEMA 15-5P
Terminal Block
Metal coffee “C”
4.4 gal/16.5 liters
6-7 gal/22-21 liters
Electrical Specifications for domestic-dual voltage Short version - no brew shelf
Brew Basket
Voltage KW
Brew Volume/Hour
M122SUS-1X117-PM001
Domestic-Dual Voltage
NEMA 15-5P
Terminal Block
Metal coffee “F”
4.4 gal/16.5 liters
6-7 gal/22-21 liters
Factory supplied with 120 volt NEMA 5-15 cord and plug. Dual voltage brewers may be field converted to 200-240 volts-see pages 13 and 19
SKU
Brew Basket
Voltage KW
Brew Volume/Hour
M1221IN-1B130-PM005 CEE 7/7
Plastic tea “A”
Plastic coffee “B”
1 X 3.0 kW 200-240 2.1-3.0
10.9-13.0 4.4 gal/16.5 liters
M1221CE-1B130-PM005
CEE 7/7
Plastic tea “A”
Plastic coffee “B”
1 X 1.7 kW 230 2.8 12.5 4.4 gal/16.5 liters
M1221CE-1B130-PM006
UK1-13P
Plastic tea “A”
Plastic coffee “B”
1 X 1.7 kW 230 2.8 12.5 4.4 gal/16.5 liters
M1221NM-1X117-PM001
DUAL VOLTAGE
NEMA 15-5P
Terminal Block
Plastic coffee “B”
4.4 gal/16.5 liters
6-7 gal/22-21 liters
M1221KS-1B130-PM006
UK1-13P
Plastic tea “A”
Plastic coffee “B”
1 X 1.7 kW 230 2.8 12.5 4.4 gal/16.5 liters
M1221BR-1B130-PN008
Type N
Plastic tea “A”
Plastic coffee “B”
1 X 1.7 kW 230 2.8 12.5 4.4 gal/16.5 liters
Advanced electronics enable this equipment to operate with a 50-60 Hz frequency range without affecting the circuit or requiring user adjustments.
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
The "KS" in the SKU suffix indicates GCC equipment with CB Scheme certification, labeling for KSA, and Arabic language user guide.
The "BR" in the SKU suffix indicates Brazil equipment with CB Scheme certification, Type N plug, labeling and Portuguese for Brazil language user guide.
-The “CE” in the suffix (above) indicates equipment with a current CB scheme supporting CE marking. This equipment is not cUL/UL certified
