This installation guide provides instructions on how to install the card into your ISA One, ISA 428 MkII or ISA 828
MkII mic preamp, and how to configure the card using the RedNet Control software application.
NOTE: Fitting should only be carried out by someone competent to do so; if in doubt, please refer to qualified
service personnel.
A video guide showing the card installation can be found here: pro.focusrite.com/help-centre
Should either User Guide not provide the information you need, be sure to consult:
https://pro.focusrite.com/technical-support, which contains a comprehensive collection of common technical
support queries.
Box Contents
• ISA ADN2(8) card
• 3 x M3 screws
• Safety information cut sheet
• Focusrite Pro Important Information Guide, which provides links to:
RedNet Control
RedNet PCIe drivers (included with RedNet Control download)
Audinate Dante Controller (installed with RedNet Control)
Dante Virtual Soundcard (DVS) Token and download instructions
Tools required
• Pozidrive No.1 (Standard ANSI Type IA) screwdriver
Safety Warning
The unit must be switched off AND the IEC power lead disconnected from the mains inlet on the rear
panel BEFORE carrying out the installation.
Caution
The unit should be removed from any rack enclosure and placed on a clear, flat surface.
Allow the unit to cool before removing the top cover.
Anti-static precautions should be taken when handling the card once removed from its anti-static
bag. Only handle the card by gripping its edges and avoid touching any component parts other than
the cable or connector.
Installation and User Guide
www.pro.focusrite.com
FFFA002302-01
2
Installation – ISA One Unit
CONFIRM THAT THE MAINS POWER LEAD IS REMOVED FROM THE REAR OF THE UNIT
Remove the Top Cover
Remove the 10 pozi screws fixing the top cover to the top and sides of the unit.
Remove the Blank on the Rear Panel
Undo the 3 crosshead screws (circled) and remove the blanking plate.
The blanking plate can be discarded.
Install the ADN2 Card
Position the card into the unit so that its ribbon cable points towards
the PCB plug J14A below the card.
Align the three mounting holes in the card (circled) with the holes in
the brackets below and loosely fit the screws supplied with the kit.
Refit the screws retained from the blanking plate into the rear of the card
and then fully tighten all screws.
Connect the Ribbon Cable
The PCB mounted ribbon plug is fitted with two mating latches. With the
latches fully apart, the A-D connector should be pressed firmly down in
place until the latches click closed.
Replace the Top Cover
Refit the 10 pozi screws taking care not to pinch the earth safety strap against the A-D card.
Initialise the ISA One Unit with A-D Installed
The ISA One will need to be initialised to recognise the addition of the A-D card.
Switch on power to the unit whilst holding down any of the front panel switches. Once the front panel illuminates,
the switch can be released – the digital card will now be active.
