ENGLISH
1
CONTENTS
CONTENTS ........................................................................................................... 1
IMPORTANT SAFETY INSTRUCTIONS........................................................... 1
INTRODUCTION................................................................................................. 2
REAR PANEL CONNECTIONS.......................................................................... 2
GETTING STARTED – A QUICK GUIDE .......................................................... 3
FACILITIES AND CONTROLS............................................................................ 3
DIGITAL CONVERTER OPTIONS..................................................................... 4
OPTIONAL DIGITAL CONVERTER FRONT PANEL CONTROLS............... 5
OPTIONAL DIGITAL CONVERTER REAR PANEL CONNECTIONS AND
SWITCHES............................................................................................................. 5
FREQUENTLY ASKED QUESTIONS ................................................................. 6
TROUBLESHOOTING ......................................................................................... 6
CONTACTING US ................................................................................................ 6
IMPORTANT SAFETY INSTRUCTIONS
Please read all of these instructions and save them for future reference. Follow all
warnings and instructions marked on the unit.
• Do not obstruct air vents in the rear panel. Do not insert objects through any
apertures.
• Do not use a damaged or frayed power cord.
• Unplug the unit before cleaning. Clean with a damp cloth only. Do not spill liquid
on the unit.
• Ensure adequate airflow around the unit to prevent overheating. We recommend
leaving a blank 1U panel above the unit to aid ventilation.
• Unplug the unit and refer servicing to qualified service personnel under the
following conditions: If the power cord or plug is damaged; if liquid has entered
the unit; if the unit has been dropped or the case damaged; if the unit does not
operate normally or exhibits a distinct change in performance. Adjust only those
controls that are covered by the operating instructions.
• Do not defeat the safety purpose of the polarised or grounding-type plug. A
polarised plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wider blade or the third
prong is provided for your safety. When the plug provided does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
WARNING: THIS UNIT MUST BE EARTHED BY THE POWER CORD.
UNDER NO CIRCUMSTANCES SHOULD THE MAINS EARTH BE
DISCONNECTED FROM THE MAINS LEAD.
This unit is supplied with an external power supply dependant on the region in which
the OctoPre LE is purchased. To avoid the risk of fire, replace the mains fuse only
with the correct value fuse, as marked on the plug. The external power supply unit
contains no user serviceable parts. Refer all servicing to a qualified service engineer,
through the appropriate Focusrite dealer.
RACK VENTILATION: PLEASE ENSURE THE OCTOPRE LE IS PLACED
TOWARDS THE BOTTOM OF YOUR EQUIPMENT RACK, WITH
SUFFICIENT SPACE ABOVE AND BELOW FOR VENTILATION.
ENGLISH
2
INTRODUCTION
The OctoPre LE features eight channels of classic Focusrite preamplification based on
the popular Green Range. As well as eight analogue outputs, there is the option of a
digital converter card (CODEC), which both accepts and transmits digital audio in
either 44.1 or 48kHz 24-bit ADAT optical ‘lightpipe’ format. The optional
CODEC means that the OctoPre LE can also be used as a monitoring control between
the DAW and speaker system, for up to 7.1 surround monitoring.
The mic pres featured in the OctoPre LE have a circuit design based around the classic
Focusrite Green range and feature an extremely transparent sonic character with very
low distortion. They utilise the same full bandwidth philosophy of all Focusrite
products, ensuring detail and clarity without obvious colouration.
Eight balanced (although unbalanced can be used) 1/4” jack inputs are located on the
front panel for quick and easy access, the first two channels of which can be used for
DI-free plug-in of guitars and basses. Channels 1 and 2 also allow a microphone signal
(input using the rear panel XLR connections) the option of a lower impedance input,
should the microphone in use have a low output impedance (around 50 for example).
With classic Focusrite analogue circuit design and comprehensive A/D and D/A
interface options, OctoPre LE is the perfect partner for a digital audio workstation,
making high quality, multi-channel recording easy. Equally, it could be utilised as part
of a compact multi-channel location recording solution (with a laptop or ADAT, for
example), or as an additional set of professional-quality mic pres for any analogue or
digital console or hard disk recorder.
REAR PANEL CONNECTIONS
The OctoPre LE features eight microphone inputs on XLR connectors and eight balanced line outputs on 1/4” (TRS) jack connectors.
