Side 1/90
ENGLISH
1
CONTENTS
CONTENTS ......................................................................................................................1
IMPORTANT SAFETY INSTRUCTIONS...................................................................1
INTRODUCTION ...........................................................................................................2
GETTING TO KNOW THE UNIT ...............................................................................2
REAR PANEL CONNECTIONS...................................................................................3
GETTING STARTED ......................................................................................................3
FACILITIES AND CONTROLS.....................................................................................4
DISCRETE CLASS A PRE-AMP ...............................................................................4
MID SCOOP EQ ..........................................................................................................5
OPTICAL COMPRESSOR.........................................................................................6
OUTPUT LEVEL .........................................................................................................6
LATENCY FREE MONITORING ...........................................................................7
MONITOR LEVELS....................................................................................................7
LATENCY FREE MONITORING CONNECTIONS...........................................8
DIGITAL........................................................................................................................8
DIGITAL CONNECTIONS .......................................................................................8
DIGITAL OUTPUT OPTION ........................................................................................9
MIC PRE-AMP INPUT IMPEDANCE ..........................................................................9
VARIABLE IMPEDANCE: IN DEPTH EXPLANATION......................................9
IMPEDANCE SETTING QUICK GUIDE..............................................................10
WORDCLOCK ...............................................................................................................10
WORKING WITH STEREO SIGNALS ......................................................................10
A BEGINNER'S GUIDE TO COMPRESSION..........................................................12
FREQUENTLY ASKED QUESTIONS........................................................................14
TROUBLESHOOTING .................................................................................................16
CONTACTING US ........................................................................................................16
TWINTRAK PRO AND YOUR STUDIO.................................................................81
SPECIFICATIONS ..........................................................................................................89
FOCUSRITE DISTRIBUTOR LIST............................................................................91
IMPORTANT SAFETY INSTRUCTIONS
Please read all of these instructions and save them for future reference. Follow all
warnings and instructions marked on the unit.
• Do not obstruct air vents in the rear panel. Do not insert objects through any
apertures.
• Do not use a damaged or frayed power cord.
• Unplug the unit before cleaning. Clean with a damp cloth only. Do not spill
liquid on the unit.
• Ensure adequate airflow around the unit to prevent overheating. As this is a Class
A unit, we recommend leaving a blank 1U panel above the unit to aid ventilation.
• Unplug the unit and refer servicing to qualified service personnel under the
following conditions: If the power cord or plug is damaged; if liquid has entered
the unit; if the unit has been dropped or the case damaged; if the unit does not
operate normally or exhibits a distinct change in performance. Adjust only those
controls that are covered by the operating instructions.
• Do not defeat the safety purpose of the polarised or grounding-type plug. A
polarised plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wider blade or the third
prong is provided for your safety. When the plug provided does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
WARNING: THIS UNIT MUST BE EARTHED BY THE POWER CORD.
UNDER NO CIRCUMSTANCES SHOULD THE MAINS EARTH BE
DISCONNECTED FROM THE MAINS LEAD.
This unit is supplied pre-configured to operate only at the voltage indicated on the
rear panel. Ensure correct mains voltage is available and the correct fuse value is fitted
before connecting to the mains supply. To avoid the risk of fire, replace the mains fuse
only with the correct value fuse, as marked on the rear panel. The internal power
supply unit contains no user serviceable parts. Refer all servicing to a qualified service
engineer, through the appropriate Focusrite dealer.
RACK VENTILATION: AS THE TWINTRAK PRO IS A CLASS A
DEVICE, PLEASE ENSURE IT IS PLACED TOWARDS THE BOTTOM
OF YOUR EQUIPMENT RACK, WITH SUFFICIENT SPACE ABOVE
AND BELOW FOR VENTILATION.
ENGLISH
2
INTRODUCTION
TwinTrak Pro is an extremely focused and cost-effective stereo processor; the perfect
‘analogue plug-in’ for any modern audio recording studio. It provides all the necessary
tools to:
• Track stereo or dual mono signals
• Process stereo or dual mono signals
• Monitor signals within the mix via a simple hands-on control surface
• Carry out essential processing for mixdown purposes
See TWINTRAK PRO AND YOUR STUDIO on page 17 for further information
on how TwinTrak Pro can enhance your current studio setup.
TwinTrak Pro combines two facility-enhanced Class A pre-amps with a custom
optical dual mono/stereo compressor. In addition, TwinTrak Pro boasts a number of
unique features above and beyond its pre-amps and compressors, including variable
input impedance, instant ‘air’, mid-scoop EQ and a latency free monitoring section
that boasts enhanced routing and control options, featuring a DAC as standard, as well
as an optional ADC.
When recording, do not assume you must route your signal through a mixing desk:
simply connect your sources to TwinTrak Pro and connect the outputs of TwinTrak
Pro directly into your sound card or recording device. This form of direct recording
will ensure you record the cleanest signal at the highest quality, since it removes the
possibility of noise being added to the signal when routing through a mixer.
Indeed, with many engineers now mixing within the DAW, and with TwinTrak Pro
providing you with two comprehensive record channels and latency-free monitoring,
you may no longer need your mixing desk, saving precious studio space.
There are 3 separate signal processing sections within each of TwinTrak Pro's two
record paths:
• Discrete Class A Pre-amp
• Mid Scoop EQ
• Optical Compressor
To ensure the cleanest signal path to your recording medium both the MID SCOOP
EQ and the OPTICAL COMPRESSOR can be individually switched out of the
audio path (‘hard bypassed’) when not in use.
GETTING TO KNOW THE UNIT
Whilst you are getting to know the unit, use it with a sound source with which you
are familiar. For example, you could run a favourite CD through the unit, as working
with a familiar track makes interpretation of the results easier. Note, however, that
most tracks are already compressed for CD, so you may find it hard to hear the results
of using the Optical Compressor. If this is the case, try using ‘dry’ samples instead, or
record your own track uncompressed, then play it back through TwinTrak Pro.
