DESCRIPTION
- 6-channel stereo mixer with live streaming function, PC audio card and Bluetooth
®
/USB recorder/player.
- Live streaming function, you can connect your smartphone or tablet and stream your live performance on
your favourite platform, with no need for anything else. Connect the mixer to your PC as an audio card.
You can play audio content from the PC and record audio on the PC simultaneously.
- Bluetooth/USB recorder and player, plays music or records the performance without PC.
- It features a 24-bit digital effects processor (16 effects) with effects selection and level control, which will
give an extra touch to your performances. In addition, it features a 48 V phantom power on channels 1
and 2 for the use of condenser microphones.
CONTROLS
FRONT PANEL
AUX
BAL/UNBAL
LINE
MIC/LINE MIC/LINE MIC/LINE MIC/LINE
PHANTOM
+48 V
CH 1 CH 2 CH 3 CH 4
CH 1 CH 2 CH 3 CH 4
CH 5/6 FX(DSP)
FX(DSP)
MAIN MIX
MAIN MIX
MAIN MIX
CH 5/6
MIC
(5V DC)
FX (DSP) FX (DSP) FX (DSP) FX (DSP)
MIX-6LIVE 6 CH MIXER
R
R
L
L
RL
HIGH
GAIN
GAIN GAIN GAIN GAIN
HIGH HIGH
HIGH HIGH
MID MID MID
MID MID
CLIP
LINE-LS
PLAYER
CLIP CLIP CLIP CLIP
LOW
LOW LOW
LOW LOW
PAN PAN PAN
PAN BALANCE
VOL VOL VOL
VOL VOL
VOL
AUX
VOL
VOL
LIVE
STREAM
AUX IN
STEREO
RL
CLIP
SIG
MODE
VOL
+
VOL
-
REC
PARAMETER PROGRAM
(CH 1-2)
10
5
0
5
10
20
30
40
60
50
0
L R L R L R L R L R
+20
-6
+64
+38
+20
-6
+64
+38
+20
-6
+64
+38
+20
-6
+64
+38
0 0 0 0
FX(DSP)
01 - REVERB HALL 1
02 - REVERB HALL 2
03 - REVERB ROOM 1
04 - REVERB ROOM 2
05 - REVERB PLATE
06 - HALL ECHO
07 - KARAOKE ECHO
08 - VOCAL ECHO
09 - REVERB STAGE 1
10 - REVERB STAGE 2
11 - AMBIENCE FX
12 - PITCH FX
1
4
2
5
6
7
8
11
18
21
24
25
26
27
28
29
30
31
32
22/23
19
20
10
12
15 16 1714
9
3
13
1.- MIC/LINE: microphone or line inputs, use the channel GAIN control to change the input sensitivity,
balanced 6.3 mm combo jack and balanced XLR. It is possible to connect a condenser microphone
only on channel 1 and 2. To do this, you must you have to switch on the phantom power of these inputs
with the PHANTOM +48 V button.
2.- AUX: stereo line level output with independent volume control, 6.3 mm jack connectors.
3.- LINE: line level inputs of channels 5 and 6, 2 x 6.3 mm jack balanced connectors.
