TC-6MX

MICROPHONE TO AUX PREAMPLIFIER

CONTROLS AND FUNCTIONS

1.- : mixed output selector (L+R) or individual (L/R).FUNCTION

2.- : aux outputs, RCA connectors.OUTPUT

3.- Power supply input for mains adapter provided.

4.- Mic.1 input volume control.

5.- : mic.1 input, 6.3 mm jack connector.MIC 1 (L)

6.- : LED power indicator.POWER

7.- : mic. 2 input, 6.3 mm jack connector.MIC 2 (R)

8.- Mic. 2 input volume control.

CONNECTION

- Connect the dynamic microphones to the mic. inputs.

- Connect the line level devices to the RCA outputs.

- Select the output function (individual or mixed).

- Power the preamplifier with the mains adapter provided.

- Select the required level in the inputs with the corresponding volume

controls.

TECHNICAL SPECIFICATIONS

TC-6MX

CHARACTERISTICS Microphone to aux preampliﬁer.

Individual volume control in each channel.

Individual or mixed output selection.

INPUTS 2 mics., 6.3 mm mono jack, 600 Ω 7 mV maximum

OUTPUTS 2 aux, RCA 47,000 Ω 1.6 V

RESPONSE 20-20,000 Hz

S/N RATIO > 80 dB

GAIN 50 dB

POWER SUPPLY 12 V DC, 0.2 A with adapter included

DIMENSIONS 133 x 31 x 85 mm depth

DECLARATION OF CONFORMITY

FONESTAR SISTEMAS S.A.

Polígono de Trascueto s/n

39600 Revilla de Camargo, Cantabria (Spain)

Declares, under its responsibility, that the following

equipment:

Description: Microphone to aux preampliﬁer

Brand: FONESTAR

Model: TC-6MX

complies with the European Community directives

2004/108/EC on Electromagnetic Compatibility,

2006/95/EC on Low Voltage and 2011/65/EU on the

restriction on the use of certain dangerous substances in

electrical and electronic appliances (RoHS).

Revilla de Camargo, 28th April 2016

Juan Vallejo

Technical Engineer, Sales Department

WARRANTY

This product has been tested and has passed the corresponding quality control prior to being put on the market.

FONESTAR guarantees the suitability of the product for its speciﬁed use during a period of 2 years from the delivery

date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la

Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.

The lack of conformity in the ﬁrst six months after purchase, due to a manufacturing defect, will be rectiﬁed with no

more than showing the proof of purchase. After six months reserves the right to demand proof of theFONESTAR

product being sold with that problem.

This warranty does not include damage produced by: inappropriate use or negligence, accidents, worn out parts due

to use, breakages, burns, spilt liquids or other substances, excessive humidity, battery deterioration and internal

manipulation of the device, the software or its components by unauthorized persons, and in general any use that is

unrelated to the nature and purpose of the product.

If any service is needed during the warranty period because of lack of conformity, please contact the business or

distributor where the product was purchased in no more than 2 months after being conscious of the problem. It is

only necessary to contact if it is impossible or imposes an undue burden for them to solve it.FONESTAR

To beneﬁt from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no

corrections or crossing out.

This document adds information, and never decreases the consumers’ rights, which in all cases are protected by the

Spanish law ‘La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16

Noviembre.

FONESTAR is a member of ECOEMBALAJES ESPAÑA, S.A. “ECOEMBES”, with number 03497 and all our products carry the symbol, backed by our membership and subscription to the above

mentioned organization with the recycling and subsequent management of our packaging.

FONESTAR is registered in the RAEE (Registro de Aparatos Eléctricos y Electrónicos) in a special section REI (Registro de establecimientos Industriales), with the entry number 001851.

FONESTAR S.A. - NIF A28780443 - Poligono Trascueto - 39600 - Revilla de Camargo, Cantabria (Spain)

www.fonestar.com

Produkt Specifikationer

Mærke:	FoneStar
Kategori:	Højttaler
Model:	TC-6MX
Bredde:	133 mm
Dybde:	85 mm
Højde:	31 mm
Vægt:	300 g
Produktfarve:	Sort
Frekvensområde:	20 - 20000 Hz
Mikrofonindgang:	Ja
DC udgangsspænding:	12 V
Signal/støjforhold:	80 dB
Audio RCA udgange:	2
Forstærkning:	50 dB
