Side 1/5

Foster spa

via M.S. Ottone, 18/20

42041 Brescello (RE) - Italy

tel. +39.0522.687425 - tel. Servizio Assistenza +39.0522.684450

fax +39.0522.686019 - fax Servizio Ricambi +39.0522.962166

e-mail: service@fosterspa.com

www.fosterspa.com

INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE

Stainless steel sinks

cod. 9606801

Istructions for the installation,

use and maintenance of

kitchen stainless steel sinks

Sinks’ material: austenitic stainless steel AISI 304 - 18/10

UNI EN 13310:2004

(kitchen sinks for domestic use, functional features and tests’ methods)

INSTALLATION

Standard and at (3 mm bended) edge

Before making any cut-out on the worktop, we suggest to verify and lay the sink on the

worktop itself and/or on the cabinets in order to verify that the external dimensions of the

bowls are compatible with the cabinets themselves, in order to avoid making cut-outs for

sinks that cannot be installed.

We also recommend to verify the possibility to install taps and other accessories, by

checking the place they need and the place that remains. Also verify the possibility to

accede to the water main tap under the sink, and that the positioning of the siphon is

feasible. To install the sink, one must make a cut-out on the worktop according to the

template included in the packing.

Once the cut-out is made, one must position the gasket around the perimeter of the

hole. Before installing the sink, please position the waste-fitting and overflow pipe (when

present); when available, also the command of the autiomatic waste-fitting must be

installed at this stage. Make

sure that the external edge

of the sink is positioned

upon the gasket, so as to

create a barrier preventing

the infiltration of water

and dirt between sink and

worktop.

'PTUFS

Produkt Specifikationer

Mærke:	Foster
Kategori:	Køkkenvask
Model:	Angolare 3306.STD
Brugervejledning:	Ja
Produktfarve:	Rustfrit stål
Pakkevægt:	9500 g
Pakkedybde:	890 mm
Pakkebredde:	890 mm
Pakkehøjde:	240 mm
Første skål, dybde:	215 mm
Anden skål, dybde:	175 mm
Første skål, dimensioner (BxL):	400 x 400 mm
Anden skål, dimensioner (BxL):	180 x 340 mm
Afløb, størrelse:	3.5 "
Antal vaskeskåle:	2 skåle
Vask, type:	Top-monteret vask
Vask form:	Hjørne
Vask materiale:	Rustfrit stål
Facon på første vask:	Firkant
Facon på anden vask:	Rektangulær
Vandhane, hul:	Ja
Drænebræt:	Ja
Drænebræt, position:	Højre
Vandhane inkluderet:	Ingen
Antal huller til haner:	1
