HYBRID

ALL-IN-ONE

WWW.FOX-ESS.COM

DATASHEET (FOR BELGIUM)

Single-Phase Hybrid/AC AIO

AIO-H1-3.0 / 3.7 / 4.6 / 5.0

AIO-AC1-3.0 / 3.7 / 4.6 / 5.0

BATTERY EXPANSION

EASY UPGRADE

A high-performance, high-

efﬁciency system with 10.4kWh of

storage capacity and up to 6kW

charge/discharge rate.

For more about the FOX range, vist:

FOX storage solutions are available with advanced and intuitive

app based remote control and monitoring functionality.

REFINED - POWERFUL - FLEXIBLE

TECHNICAL SPECIFICATIONS

Model

AIO-AC1-3.0 AIO-AC1-3.7 AIO-AC1-4.6-E1 AIO-AC1-5.0-E1

AIO-H1-3.0 AIO-H1-3.7 AIO-H1-4.6-E1 AIO-H1-5.0-E1

INPUT PV (FOR HYBRID ONLY)

Max.recommended DC power [W] 3900 4680 5980 6500

Max.DC voltage [V]

Nominal DC operag voltage [V]

Max. input current [A]

Max. short circuit current [A]

MPPT voltage range [V]

No. of MPP trackers 2 2 2 2

Strings per MPP tracker

Start-up voltage [V]

1 1 1 1

Nominal AC power [VA] 3000 3680 4600 5000

Max. apparent AC power [VA] 3300 4048 4600 5000

Rated grid voltage (AC voltage range) [V]

Rated grid Frequency [Hz]

Nominal AC cur

rent [A] 13 16 20 21.7

Max. AC current [A] 14.4 17.6 22 23.9

Displacement power factor

Total harmonic distoron (THDi, rated power)

INPUT AC

Nominal AC power [VA] 7000 7680 9600 10000

Nominal AC current [A] 31.8 34.9

43.7

45.5

Rated grid voltage (AC voltage range) [V]

Rated grid Frequency [Hz]

Power Factor

BATTERY (LFP)

Bry capacity [kWh]

Max.charge/discharge current [A]

Communican interfaces

Reverse connect protecn

EPS OUTPUT (WITH BATTERY)

EPS rated power [VA] 5000 5000 6000 6000

EPS rated voltage [V], Frequency [Hz]

EPS rated curre

nt [A] 21.7 21.7 26.1 26.1

EPS peak power [W]

Total harmonic distoron (THDv, linear Load)

 [ms]

EFFICIENCY

MPPT eciency 99.90% 99.90% 99.90% 99.90%

Euro-eciency 97.00% 97.00% 97.00% 97.00%

Max. eciency 97.80% 97.80% 97.80% 97.80%

Max. eciency (PV to BAT) @full load 98.50% 98.50% 98.50% 98.50%

Max. eciency (BAT to AC) @full load 97.00% 97.00% 97.00% 97.00%

POWER CONSUMPTION

Standby consumpn [W] (Idle)

Safety

EMC

Cecan

Ingress protecn

Operag temperature range [°C]

Humidity [%]

Altude [m]

Storage temperature [°C]

Noise

emission (typical) [dB]

Over voltage category

Dimensions (HxWxD) [mm]

Weight [kg]

Cooling concept

Topology

Communican

Buon

Ethernet, Meter, WIFI/GPRS/ LAN (opnal), DRM, USB, CT

CAN/RS485

YES

Up to 10.4

IP65

-25…... +60 (derag at +45)

STANDARD

IEC62109-1/-2 / IEC62040

III (AC), II (DC)

Natural

7200, 60s6000, 60s

230VAC, 50/60

0.8 leading to 0.8 lagging

<3%

220/230/240 (180 to 270)

50/60±5

0.8 leading to 0.8 lagging

<20

EN 61000-6-1 / EN 61000-6-2 / EN 61000-6-3

600

360

220/230/240 (180 to 270)

50/60±5

OUTPUT AC

13.5/13.5

15/15

80-550

Capaciv

e Touch Sense

78 (excluding bries)

GENERAL DATA

Transformerless

<2%

624*1662*375

C10/11 / G98 / VDE-AR-N 4105 / G99 / AS4777 / EN50438/ CEI 0-21 / VDE 2510 / NRS097-2-1

ENVIRONMENT LIMIT

0~100 (non-condensing)

<2000

-40…... +70

 85-450

V1.0 2022/2/17

FOR BELGIUM MARKET
