Side 1/3

Product Sheet

Fractal Design brings you Scandinavian design and quality

www.fractal-design.com

CORE 1100

Despite its extremely small outer dimensions, the Core 1100 mATX case provides everything you need. The

stylish, Scandinavian exterior design is matched by the fully painted interior, complete with the signature white

details of Fractal Design.

The case is optimized for airow with a straight cooling path, and comes equipped with a pre-installed 120mm

fan. The front panel is equipped with dust lters.

An innovative vertical hard drive bracket can t either two 3.5” drives, three 2.5” drives, or one drive of each

size. Both the 3.5” drive slots come with silicone vibration

dampening grommets.

Key features

• An extremely compact micro ATX case, designed for

exceptional airow and cooling

• Brushed aluminum-look front panel with a sleek, three-

dimensional textured nish

• One Fractal Design 120mm fan included

• Easy access I/O on front panel, with audio and both USB

3.0 and USB 2.0 ports

• Front panel dust lters and closed top and bottom panels

help maintaining a dust free interior

• Innovative vertical HDD bracket, which can hold two 3.5”

drives or three 2.5” drives, or one drive of each size

• Vibration-dampened mounting for both 3.5” drive slots

• Fully painted interior, with Fractal Design signature white

details

Model Model SKU EAN UPC

Fractal Design Core 1100 FD-CA-CORE-1100-BL 7350041081913 817301011914

Product Sheet

Fractal Design brings you Scandinavian design and quality

www.fractal-design.com

General Specifications

Core p2-x3 Series

The Core family of cases have always been centered around providing the core features and performance of

Fractal Design’s case lineage at an aggressive price point. Core has undergone an evolution thanks in part

to the valuable feedback from our customers.

The new p2-x3 Series of the Core Family of cases are liquid cooling ready, featuring superb airow and an inno-

vative vertical drive mounting system. Able to support up to six drives, the unique design of the vertical hard

drive bracket ensures that it will not restrict optimum airow. For added versatility the drive bracket is fully re-

movable, allowing the end user incredible exibility for mounting liquid cooling radiators up to 280mm in size.

Drive bay capacity

• 2 - 5.25" bays

• 2 - 3.5” HDD positions

• 3 - 2.5” drive positions

• 1 - 2.5” drive position

• 1 - 3.5” drive position

Expansion slots • 4

Motherboard compatibility

• Micro ATX

• Mini ITX

Cooling / Ventilation

• 3 - Fan positions (1 fan included)

• Filtered fan slots in front

• CPU coolers up to 148 mm in height

Front interface

• 1 USB 3.0 + 1 USB 2.0

• Audio in/out

• Power button with LED (white)

• HDD activity LED (white)

Power supply compatibility • ATX PSUs, up to 185mm if a typical-length optical drive is mounted

Graphics card compatibility

• Graphics cards up to 350mm in length may be installed. One or more

3.5" hard drives may interfere with side-mounted power connectors on

graphics cards longer than 170 mm

Colors Available • Black

Case dimensions - W x H x D (mm) • 175 x 358 x 410

Case dimensions -

with feet/protrusions/screws

• 175 x 368 x 420

Net weight (kg) • 3.8 kg

Package dimensions - W x H x D (mm) • 235*485*420

Package weight – (Kg) • 4.6 kg

Produkt Specifikationer

Mærke:	Fractal Design
Kategori:	Computerbehuizing
Model:	Core 1100
Type:	PC
Bredde:	175 mm
Dybde:	410 mm
Højde:	358 mm
Vægt:	3800 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	4600 g
Pakkedybde:	485 mm
Pakkebredde:	235 mm
Pakkehøjde:	420 mm
Formfaktor:	Mini Tower
Indbyggede højttaler(e):	Ingen
Antal USB 2.0-porte:	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	1
LED-indikatorer:	HDD, Power
Harmoniseret systemkode (HS):	84733080
Lydindgang:	Ja
Lydudgang:	Ja
Ventilatorhastighed:	1200 rpm
Strømforsyning inkluderet:	Ingen
Antal 5.25" bays:	2
Antal 3.5" bays:	2
Understøttet motherboard, formfaktorer:	Micro ATX, Mini-ITX
Siderude:	Ingen
Antal udvidelsesporte:	4
Maksimal højde på CPU-køler:	148 mm
Maksimal længde på grafikkort:	350 mm
Understøttede HDD-størrelser:	2.5, 3.5 "
Placering af strømforsyning:	Bund
Frontventiler installeret:	1x 120 mm
Antal understøttede frontventilatorer (maks.):	1
Understøttede diametre for frontventilatorer:	120 mm
Antal understøttede bagerste ventilatorer (maks.):	1
Understøttede diametre for bagerste ventilatorer:	92 mm
Understøttede diametre for sideventilatorer:	120 mm
Understøttede strømforsyning formfaktorer:	ATX
Antal understøttede sideventilatorer (maks.):	1
