INSTALLATION MANUAL

STAINLESS STEEL AND GRANITE SINKS

For best results, Franke recommends this unit be mounted by a professional installer. This sink is

specically designed to be under mounted in a solid surface countertop only. Do not install a damaged

sink. Inspect carefully.

NOTE: The template included (or. dxf le downloaded from website) is only a guide. The actual sink and

accessories should ALWAYS be present to ensure a perfect cut. FRANKE IS NOT RESPONSIBLE FOR AN

IMPROPERLY CUT COUNTERTOP OR IMPROPER INSTALLATION

1. Create the cut-out in the desired locaon of the mounng surface using this template (or the .dxf le

downloaded from our website). Make sure to compare the actual sink with the template being used to

ensure a perfect t. The size of the cut-out should be exact as this sink uses coordinang accessories

which t precisely with the cut out. Also be aware of the spacing requirements of any other products

that will be mounted to the countertop next to the sink such as faucets or soap dispensers.

2. It will be the responsibility of the countertop supplier/installer to decide the ideal anchoring method

based on the applicaon and countertop material being used. Determine best placement of the clip

brackets provided, ideally they should be evenly spaced around the sink ledge on all sides. Pre-drill

holes and install anchors. Mounng screws and/or other hardware associated with anchoring not

included. Aach clip brackets loosely to the countertop using selected anchor.

3. Apply a bead of silicone evenly along the bowl rim and/or along the underside of countertop.

4. Posion and align sink evenly over the opening of the cut out. Press sink into silicone seal and parally

ghten the clip brackets against the sink so it stays in place.

5. Check alignment one nal me to ensure the sink opening is evenly aligned with the countertop cut

out as outlined in the image below. Make adjustments as necessary to obtain perfect alignment.

6. Once sasfactory alignment is achieved, fully ghten clip brackets against the rim of the sink and

remove excess silicone.

HINT: Aer silicone cures, wipe inside edge with denatured alcohol. This will smooth out any rough

areas.

Produkt Specifikationer

Mærke:	Franke
Kategori:	Køkkenvask
Model:	GDX11018
Bredde:	546.1 mm
Produktfarve:	Rustfrit stål
Længde:	501.65 mm
Monteringssæt:	Ja
Første skål, dybde:	228.6 mm
Antal vaskeskåle:	1 skåle
Vask form:	Rektangulær
Vask materiale:	Rustfrit stål
