Data Sheet FUJITSU Car/Truck Power Adapter 90 Accessories

Page 1 / 3 www.fujitsu.com/fts/accessories

Data Sheet

FUJITSU Car/Truck Power Adapter 90

Accessories

Charge your batteries everywhere and anytime

People who are often on business or private trips want to power up their handhelds, tablet

PCs and notebooks anywhere and anytime. The Fujitsu Car/Truck Power Adapter 90 will

charge your Tablet PC or notebook anywhere a 12 V or 24 V power supply is available.

NEW: The Car/Truck Power Adapter 90 now charges 19V and 12V devices.

Reliability

Guaranteed quality and stability

Constant current regulation ensures stable charging of batteries

Everything you need from one company

Mobility

Through a wide input voltage range which ensures that the Car/Truck Power Adapter 90

can be used not only with cars but also in lorries, boats, planes - anywhere where 12 V

or 24 V power supplies are available

Simply select the correct MCS Connector and use the charger for your handheld, Tablet

PC or notebook

USB charging port for mobile devices

Security

The adapter comes with short circuit protection and under-voltage protection:

The Car/Truck Power Adapter 90 will not enable charging if the voltage on the line is not

within the specied limits

Over voltage protection

Over temperature protection

Data Sheet FUJITSU Car/Truck Power Adapter 90 Accessories

Page 2 / 3 www.fujitsu.com/fts/accessories

Car/Truck Power Adapter 90

Charger

Color Black

Input characteristics Voltage range: 11 - 32VDC

Input fuse 12A (x)

Protection: Reverse polarity, Under voltage protection, over temperature protection

Convection cooled

Operating temperature: -20°C to 40°C at max 2000m above sea level

Non operating temperature: -40°C to 85°C at max. 15000m above sea level

Humidity: 5 to 95% r.H., non condensing

Output characteristics Output1: Voltge range 10 - 24VDC nominal / 85W max.

Constant current, 6A max. (current limitation)

Protection: Short circuit, over current protection, over voltage

protection, over temperature protection

Output USB:5VDC nominal / 1A max / 5W max

Protection: Short circuit, over current protection

Efciency: typical 96% at 100% load

Connector and Cable Specication Input Connector: Cigarette lighter adapter with multiple connector system

Input cable length: 100cm

Output Connector:

Typ C03 for 19V pin length: 14.2 + 0.5 mm; outer diameter: 5.5 mm

Typ CØ5 for 19V pin length: 9.6 +-0.3 mm; outer diameter: 3.4 mm

Typ C06 for 12V pin length: 10.0 +- 0.4 mm; outer diameter: 3.0 mm

Output cable length: 100cm

Output 2: USB receptacle, type A

Device Classication

Power consumption 85W + 5W (USB)

Power supply input 11 - 32V DC

Power supply output 12V and 19V

Devise Classication

Europe CE

USA/Canada FCC Class B

cULus

Australia/New Zealand C-Tick

Compliance link http://globalsp.ts.fujitsu.com/sites/certicates

Miscellaneous

Dimensions (W x D x H) 115 x 53.7 x 21.5 mm

Weight 250g w/o cables and connectors

Order code

S26391-F2613-L610 EAN: 4051554418304

Produkt Specifikationer

Mærke:	Fujitsu
Kategori:	Batterioplader
Model:	Car/Truck Power Adapter 90
Tænd-/slukkontakt:	Ingen
Bredde:	115 mm
Dybde:	53.7 mm
Højde:	21.5 mm
Vægt:	250 g
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-40 - 85 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Driftstemperatur (T-T):	-20 - 40 °C
Strømforsyningstype:	Automatisk
Udgangseffekt:	85 W
LED-indikatorer:	Ja
Udgangsstrøm:	6 A
Kabellængde:	1.00 m
USB version:	2.0
Antal USB-porte:	1
Indgangsspænding:	11-32 V
Formål:	Notebook
Indgangsfrekvens:	- Hz
Stærkstrøm typen:	DC1-to-DC2
Strømbeskyttelsesfunktioner:	Over current, Over voltage, Overheating, Short circuit
Effektivitet:	96 %
Udgangsspænding note:	DC 10 - 24V, 5V
Supplerende strømkontakter:	2
Aftagelige strømforbindelser:	Ja
