Side 1/51

www.furuno.co.jp

All brand and product names are trademarks, registered trademarks or service marks of their respective holders.

MARINE RADAR

FAR-2107/FAR-2807 SERIES

Operator’s Manual:

Fishing Vessel Specifications

The purpose of this manual is to provide the operating procedures for the functions available with

the fishing vessel specifications models (50 kW and 60 kW models) of the FAR-2107/FAR-2807

series radar. This manual is provided in addition to the Operator's Manual, which covers features

common to all radars in this radar series.

Specification type is set during installation. For details, contact a FURUNO agent or dealer.

Operation from the menu involves spinning the scrollwheel to select menu item or option then

pushing the scrollwheel or left button to confirm selection. For sake of brevity, we write "Select

XXX" (XXX=name of menu item) when you would spin the scrollwheel to make a selection and

"push the left button" when you confirm selection.

Contents

1. TARGET TRAIL FUNCTIONS................... 2

1.1 Long Trails....................................................2

1.2 Trail Color.....................................................3

1.3 Trail Color Shift.............................................4

1.4 Hiding Trails .................................................5

1.5 Trail Eraser...................................................6

1.6 Narrow Trails................................................7

1.7 Preventing True Sea Clutter Trails ...............7

2. CURSORS ................................................. 8

2.1 Crosshairs Cursor Size ................................8

2.2 Net Cursor....................................................9

2.3 Cursor Data Display ...................................11

2.4 Bearing Scale Format.................................12

3. OTHER FUNCTIONS............................... 13

3.1 Echo Display Area......................................13

3.2 Turning On-screen Boxes On/Of................14

3.3 Radar Picture Color....................................15

3.4 Bearing Reference .....................................16

3.5 VRM, Cursor Unit .......................................17

3.6 Pop-up Guidance .......................................17

4. FUNCTION KEYS (F1 - F4) .....................18

4.1 F1, F2 and F3 Keys.................................... 18

4.2 Operating the F4 Key................................. 27

5. ANCHOR WATCH ALARM......................31

6. VIDEO PLOTTER FUNCTIONS...............32

6.1 Depth Contour with Depth Indication ......... 32

6.2 Mark Settings ............................................. 33

6.3 Track Settings ............................................ 36

6.4 GPS Buoy .................................................. 41

7. ARP SYMBOLS .......................................42

8. DISPLAYING PICTURE FROM

EXTERNAL RADAR ................................43

9. MENU TREE.............................................44

1. TARGET TRAIL FUNCTIONS

1.1 Long Trails

The fishing vessel specifications radar provides trail lengths of 12 h, 24 h and 48 h, in

addition to the “standard” trail lengths of 15 s, 30 s, 1 min, 3 min, 6 min, 15 min, 30 min

and continuous. To select a trail length, do the following:

1. Place the cursor on the TRAIL MODE box at the bottom right-hand corner on the

screen.

2. Right-click the box to open the TRAIL

menu.

3. Select 8 TRAIL LENGTH then push the left

button.

4. Select NORMAL, 12H, 24H, or 48H as

appropriate then push the left button.

NORMAL: Trail lengths of 15 s, 30 s, 1 min,

3 min, 6 min, 15 min, 30 min and contin-

uous, selectable from the TRAIL MODE

box.

12H: Max. 12-hour trails

24H: Max. 24-hour trails

48H: Max. 48-hour trails

Note: Trail data is erased and the TRAIL

MODE box setting shows "OFF" whenever

a trail length is chosen from the menu.

5. Push the right button to close the menu.

6. If you chose the 12H, 24H or 48H trail

length, select how many minutes of trails to

show in the chosen time period, from the

TRAIL MODE box. Settings and corre-

sponding trail times are

12H: 30 minute increments

24H: 1 hour increments

48H: 2 hour increments

For example, you have selected 12H from the TRAIL menu and 30 minutes from

the TRAIL MODE box. Then, 30 minutes worth of trails are displayed over the 12-

hour time period.

Note: When 2 TRAIL GRAD is set for SINGLE, long trails (12H/24H/48H) are painted

in various colors (see section 1.2) and standard trails are painted in single color. For

long trails, select SINGLE, since MULTI paints trails in a single color.

TRUE TRAIL OFF 

* Shown when 8 TRAIL LENGTH

is selected to other than "NORMAL".

[TRAIL

MENU]

1 TRAIL MODE

REL/TRUE

2 TRAIL GRAD

SINGLE/MULTI

3 NARROW TRAIL

OFF/1/2

4 TRAIL LEVEL

1/2/3/4

5 TRAIL RESTART

OFF/ON

6 TRAIL COPY

OFF/ON

7 OS TRAIL

OFF/ON

8 TRAIL LENGTH

NORMAL/12H/24H/48H

9 TRAIL HIDE*

START 00:00

END 00:00

0 [TRAIL COLOR]*
