Side 1/4
®
Universal Swivel Bracket for 8.8 in. Waketower Can Speakers Installation Instructions................... 2
Instructions d'installation Support universel pivotant pour les haut-parleurs Waketower Can de
8,8 po ................................................................................................................................................. 4
Staffa girevole universale per gli altoparlanti Waketower Can da 8,8 poll. Istruzioni
di installazione................................................................................................................................... 6
Universalschwenkhalterung für 8,8-Zoll-Waketower Can-Lautsprecher
– Installationsanweisungen................................................................................................................ 8
Instrucciones de instalación del Soporte giratorio universal para altavoces Waketower Can de
8,8 in................................................................................................................................................ 10
Suporte giratório universal para alto-falantes Waketower Can de 8,8 pol. de NPS de 2 pol........... 12
Universele draaibeugel voor 8,8 in. Waketower Can luidsprekers installatie-instructies................. 14
Garmin®, the Garmin logo, FUSION®, and the Fusion logo, are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used without the express
permission of Garmin.
April 2019
190-02482-93_0B
Universal Swivel Bracket for 8.8 in.
Waketower Can Speakers Installation
Instructions
Important Safety Information
WARNING
See the guide in the Important Safety and Product Information
product box for product warnings and other important
information.
WARNING
This device must be installed according to these instructions.
Disconnect the vehicle's or vessel's power supply before
beginning to install this device.
CAUTION
Continuous exposure to sound pressure levels over 100 dBA
may cause permanent hearing loss. The volume is typically too
loud if you cannot hear people speaking around you. Limit the
amount of time you listen at high volume. If you experience
ringing in your ears or muffled speech, stop listening and have
your hearing checked.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite
side of the surface.
It is strongly recommended that you have your audio system
installed by a professional installer to ensure optimum
performance.
You must read all installation instructions before beginning the
installation. If you experience difficulty during the installation, go
to for product support.www.fusionentertainment.com
What's In the Box
• Two universal waketower brackets
• Two silicon grommets
• Plastic inserts to adjust for the waketower pole diameter
These inserts allow the brackets to attach securely to a
waketower with a pipe diameter from 33.4 mm (1.31 in.) to
63.5 mm (2.5 in.). See the specifications for a complete list of
compatible pipe diameters.
• Eight hex screws and washers for securing the brackets to
the speakers and the waketower
Tools Needed
• Drill and 12 mm (1/2 in.) drill bit
• 6 mm, 4 mm, and 2.5 mm hex drivers or hex keys
• Scissors
• Wire strippers
• Solder and heat-shrink tubing for wire connections
NOTE: For customized installations, additional tools and
materials may be needed.
Preparing the Bracket
The swivel bracket has a built-in rotation stop that prevents the
speaker from rotating completely around and twisting the
speaker cable. You may need to adjust the stop screw on the
bracket to provide the proper rotation angle for the mounting
location on your waketower.
There are four positions for the stop screw that determine where
the bracket stops the rotation in relation to the bow of the boat
:
1Hold the base of the bracket against the waketower at the
mounting location.
2Rotate the bracket to the right and left and observe the full
angle of rotation.
3Select an option:
• If the bracket rotates within your preferred angle, set the
bracket aside and repeat this procedure for each
additional bracket.
• If the bracket stops rotating before it reaches your
preferred angle, using a 2.5 mm hex driver or hex key,
remove the set screw on the bottom of the bracket.
4Rotate the bracket to the right and left to determine which set
screw hole allows the bracket to rotate within your preferred
angle.
5Using a 2.5 mm hex driver or hex key, install the set screw in
the hole that works best for the mounting location.
6Repeat this procedure for each additional bracket.
Mounting the Bracket
You can mount FUSION® Waketower Can speakers (sold
separately) to a waketower using the included brackets.
1If necessary, mark the locations on the waketower where you
plan to mount the speakers.
2If necessary, drill a 12 mm (1/2 in.) cable pass-through holes
in the bottom of the waketower pipe.
3If necessary, route the speaker and LED power wires (not
included) through the waketower to the mounting locations.
4If necessary, starting with one mounting location, place the
included silicon grommet onto the hole in the bottom of the
waketower pipe.
The grommet protects the speaker cable from sharp edges
on the waketower pipe.
5Select the appropriate plastic spacer to mount the bracket to
the waketower pipe.
6Push each half of the spacer into the base and top of the
bracket.
The spacer halves should fit securely into each half of the
bracket.
7Feed the speaker cable from the FUSION Waketower Can
speaker through the base of the bracket , and attach the
bracket to the speakers using the included screws with a
6 mm hex driver or hex key.
2 Installation Instructions
