FPO-11

Puls oximeter

Introduction:

The Fysic FPO-11 is a pulse Oximeter which

measures the percentage of the amount of oxy-

gen found in the blood.

Intended use:

The Pulse Oximeter is a non-invasive device

intended for spot checking of functional oxygen

saturation of arterial hemoglobin (SpO2) and

pulse rate (PR). This portable device is indicated

for use in adult patients in clinical institution and

home environments.

Measuring principle:

By shining an infra-red light through the skin, the

reected light will be compared with the emitted

light which will in turn analyze the color of the red

blood cells. This colour measured will reect the

amount of oxygen in the blood.

Do not use:

Do not use the FPO-11 with an irregular heart

beat (Atrial Fibrillation).

Installation:

The FPO-11 comes with two included batteries, a

wrist strap and a protective case.

Install batteries:

1. Slide the battery cover o󰀨 of the FPO-11

2. Insert the two

supplied batte-

ries, be sure to

take note of the positive and negative poles

(+ and -)

3. Place the battery cover back onto the FPO-11

Fastening the wristband:

1. Push the thin cord through the

hole on the FPO-11 and then

make a loop from the cord.

2. Put the thick part of the strap through the loop.

3. Pull the thick part of the cord all the way

through the loop tugging slightly to tighten it.

Use:

Preparations & tips:

• Make sure that you are familiar with the ope-

ration of the pulse Oximeter.

• Avoid bright lights.

• Remove articial nails and/or nail polish.

• Wash your hands before using.

• Make sure your hands are warm to ensure a

good blood circulation.

• Sit quietly before and during the taking of the

measurement.

Measurement:

1. Open the clip and place your nger on the

FPO-11 with the nail facing upwards, as

shown on the adjacent picture; use your mid-

dle nger preferably pushing it gently towards

the back of the Oximeter.

2. Turn on the FPO-11 by pressing the

on/o󰀨 button.

3. If necessary, the reading direction

of the display can be changed by

pressing the on/o󰀨 button repea-

tedly.

4. Do not move your nger during the measurement.

5. Readings in the display:

- The “% SpO2” shows the percentage of

oxygen in the blood.

- The “PRbpm” gives the pulse rate of the

pulse per minute.

- The PI (Perfusion Index) is the ratio of the

pulsatile blood ow to the non-pulsatile

blood ow. The PI’s values range from

0.02% for very weak pulses to 20% for

strong pulses.

- Depending on the selected reading di-

rection, a pulsating bar graph shows the

strength of the heartbeat or the heart rate

can be seen at the bottom of the display.

6. The FPO-11 will turn o󰀨 15 seconds after the

clip has been taken o󰀨 the nger.

Setting an alarm:

You can set alarm tones to give alert signals when

the level of the oxygen in your blood, or the pulse

rate exceeds the adjustable upper or lower values.

1. Turn on the FPO-11 by quickly pressing the

on/o󰀨 button.

2. Hold down the on/o󰀨 button for more than one

second to open the settings menu.

3. Now release the on/o󰀨 button. You will see

one of the following statements:

• The line with the star at the end is the active line.

• Press quickly on the on/o󰀨 button to move the

star to the next line.

• Press and hold the on/o󰀨 button to change

the setting of the current line.

Limit Setup *

SPO2 Hi 100

SPO2 Lo 94

PR Hi 130

PR Lo 50

+/- +

Exit

Remind Setup *

Sound Reminder on

Beep o󰀨

Demo o󰀨

Restore Ok

Brightness 4

Exit

Screen 1

- Limit Setup To go to the other menu

- SpO2 Hi Set hi levels of oxygen

percentage

- SpO2 Lo Set low levels of oxygen

percentage

- PR Hi Set high levels of pulse

rate

- PR Lo Set low levels of pulse rate

- +/- Switch between going

higher or lower

- Exit To exit the menu

Screen 2

- Remind Setup To go to the other menu

- Sound reminder To switch the alarm on or o󰀨

- Beep To switch the pulse rate

alarm on or o󰀨

- Demo to play a demo (power o󰀨 to

start again without the demo)

- Restore To restore back to factory

settings

- Brightness To set the display intensity

- Exit To exit the menu

Maintenance:

Cleaning and storage:

• The device is non-sterile and not intended to be

sterilized.

• Clean the black rubber nger sleeve before and

after using with medicinal alcohol (> 95%).

• The exterior part of the tester can be cleaned

using a damp cloth. The FPO-11 is not water-

proof, so DO NOT immerse in water.

• Keep the pulse Oximeter out of the reach of

children, and preferably inside the included

case in a dry place.

• See the technical specications regarding

storage conditions.

Batteries:

• The batteries can power the unit for over 20

hours continuously.

• If the device will not be used for a long period

(> 2 months), remove the batteries. Doing so

prevent any possible damage from leaking

batteries.

• Replace the batteries when the battery indi-

cator shows that the batteries are running low

(display: or ).

• Always place two identical batteries, type

alkaline, size AAA.

• Rechargeable batteries should not be used

due to their lower voltage.

Environment:

• Should the device need to be discarded,

hand it over to your supplier. They

will dispose of it in an environmen-

tally friendly manner.

• Empty batteries can be returned to the sup-

plier or disposed of in an environmentally-

friendly manner according to your local regu-

lations. Do not dispose of used batteries with

your normal household waste.

Technical:

• 24 months Warranty ● FPO-11 does not con-

tain any service components/accessories ●

maintenance only through the service depart-

ment of Fysic.

Calibration:

• The FPO-11 does not need to be calibrated.

Declaration of Conformity:

• http://DOC.hesdo.com/FPO-11-DOC.pdf

Specications:

• Display: Colour, type OLED

• Pulse rate:

Range: 30bpm ~ 250bpm

Resolution: 1bpm

Accuracy: 1bpm

Strength: bar chart

(bpm = beats per minute)

• SpO2:

Range: 35 -100%

Resolution: 1%

Accuracy: 90% -100%: ±2%

70% - 90%: ±3%

< 70%: unspecied

• Perfusion Index:

Range: 0-20%

Resolution: 0,1%

Accuracy: 0% - 1%: 0,1%

1% - 20%: 1%

• Batteries: 2x AAA, 1.5V, Alkaline

Consumption: 30mA (nominal)

Battery life: >20 hours continuous use

• Dimensions, weight:

62,8 x 38 x 29mm / 51 grams (incl. batt)

• Surroundings:

Operating temperature: 5°C ~ 40°C

Storage temperature: -10°C ~ 50°C

Operating humidity: 15% ~ 80%

Storage Humidity: 10% ~ 93%

: Shanghai International Holding Corp.

GmbH (Europe).

Ei󰀨estrasse 80, 20537, Hamburg, Germany.

: Shenzhen AEON Technology Co. LTD.

RM6H02, Block 27-29, Tianxia IC Industrial Park

Majialong, No. 133 of Yiyuan Road, Nantou

Street, Nanshan District, Shenzhen, China.

Model: A340

v1.20123
