Thank you for selecting a Gamko Froster.
Your Froster will provide many years of trouble free service, if the instructions below
are followed.
INSTALLATION
1. Do not place your Gamko Froster in direct sunlight, or near heat sources. The
condenser requires cold air to circulate through the condenser (coiled tube in the
machine unit). This air is sucked in and expelled through the square holes in the
front of the Froster. Therefore these air holes at the front must be kept clear
at all times.
2. The Froster should be installed on a level surface. If the cabinet is not level, the
door will not close properly.
3. Click the shelve supports into the climbing strips and fit the shelves.
4. After installation leave your Froster to stand for at least 2 hours prior to
connection to the mains, to avoid damaging the compressor.
5. Power supply must be 220V/240V ac. 50Hz. Plug into an earthed socket.
6. Mains ON/OFF switch is located inside the cabinet on the back panel. In case of a
light switch, the switch is located to the right/left of the thermostat.
TEMPERATURE
Your Gamko Froster is set to operate at temperatures between 10ºC -21ºC. –and
To adjust the temperature the plastic panel in front of the thermostat should be
removed. For further instructions please refer to the instruction manual of the
thermostat.
DEFROSTING
The cabinet has automatic defrost. Due to warm moist air entering the Froster each
time the door is opened, the build up of ice on the evaporator (inside back panel) is
inevitable. This ice is automatically removed during the defrost cycles. The defrost
water will automatically evaporate in the driptray of the machine unit.
MAINTENANCE
Your Gamko Froster should be cleaned using a mild domestic detergent and warm
water, never use abrasives or harsh chemicals. Consult the instructions for cleaning
and maintenance of stainless steel.
In order to guarantee optimal performance the condenser (radiator in machine unit)
should be cleaned weekly. Before cleaning the cabinet should be turned off and the
unit be allowed to cool down sufficiently. To reach the condenser the small panel on
the side of the cabinet should be opened, by undoing the 4 screws that hold the
panel in place. The condenser can be cleaned using a vacuum cleaner or brush,
replace the panel after cleaning.
