GE Monogram®
48" Built-In Refrigerators
Custom
Options Guide
and
Installation
Instructions
With Custom Panel Dimensions
and Trim Kit
Installation Instructions
Models:
ZIS48N
ZISW48D
ZISB48D
These Monogram built-in refrigerators are
designed to be customized with decorator
door and grille panels. Field installed
panels are required.
Factory installed trim will accommodate
1/4" thick custom panels or optional
Lexan® and Stainless Steel panel kits.
Optional trim kits allow an even broader
range of custom appearance options.
Read this booklet carefully to accomplish the
desired appearance and to insure a trouble free
installation.
This booklet contains information and
illustrations to demonstrate custom
possibilities. Custom door and grille panel
sizes vary to accommodate the kit being
used. Dimensions for each application are
included and can be faxed or sent to the
cabinet manufacturer so that the panels can
be constructed accurately.

Before you begin - Read these instructions completely and carefully.
IMPORTANT - Save these instructions for local inspector’s use.
IMPORTANT - OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer - Be sure to leave these instructions with the Consumer.
Note to Consumer - Keep these instructions with your Use and Care Book for future reference.
2
Contents
Design Information
Advance Planning for a Flush Installation ................................................................................................................................... 3
Cutout and Product Dimensions .................................................................................................................................................. 3
Installation Between Base & Wall Cabinets ............................................................................................................................. 4
Installation At End-of-Run ............................................................................................................................................................. 4
Frameless Cabinets ........................................................................................................................................................................ 4
Accessory Panel Kits ..................................................................................................................................................................... 4
Advance Planning, Exterior Appearance Options...................................................................................................................... 5
Appearance Examples, Trim Kit Descriptions .......................................................................................................................... 5
Custom Panel Dimensions
ZIS48N ............................................................................................................................................................................................6-9
ZISW48D, ZISB48D ..................................................................................................................................................................10-13
Side Panel or Filler Options ........................................................................................................................................................ 14
Installation Instructions ...........................................................................................................................................................15-20
Trim Kits
ZKH1 Trim Kit Installation Instructions
Custom Handles with 1/4" Thick Panels .............................................................................................................................21-25
ZG2 Trim Kit Installation Instructions
Grille Panel Frame Adjustment .................................................................................................................................................. 26
ZKT48 Trim Kit Installation Instructions
3/4" Thick Custom Panels .......................................................................................................................................................27-32
ZKHT1 Trim kit Installation Instructions
Custom Handles with 3/4" Thick Panels ..............................................................................................................................33-37
ZKHSS1 Trim Kit Installation Instructions
Tubular Stainless Steel Handles for 1/4" Panel Installation ............................................................................................38-41
ZKHTSS1 Trim Kit Installation Instructions
Tubular Stainless Steel Handles for 3/4" Panel Installation ............................................................................................42-45
ZWCD2 Trim Kit Installation Instructions
Custom Dispenser Collar ........................................................................................................................................................46-47
If you have a question concerning the installation of this
product, call the GE Answer Center® Consumer
Information Service at 800.626.2000, 24 hours a day,
7 days a week.
If you received a damaged refrigerator, you should
immediately contact your dealer or builder.
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the GE Appliance Warranty. See the
Use & Care Guide for warranty information.
For Monogram local service in your area,
1-800-444-1845.
For Monogram service in Canada, 1-888-880-3030.
For Monogram Parts and Accessories, call
1-800-626-2002.
WARNING
WARNING
• Il ne faut utiliser cet appareil que pour l’usage pour
lequel il a été construit.
• Il faut réparer ou remplacer immédiatement tout
cordon d’alimentation électrique effiloché ou
endommagé.
• Débrancher le réfrigérateur avant le nettoyage ou
toute intervention.
• Les réparations doivent être faites par un
technicien qualifié.
CAUTION
ATTENTION
Cet appareil doit être correctement mis à la terre.
Consulter « Mise à terre du réfrigérateur », page 15.
• Use this appliance only for its intended purpose.
• Immediately repair or replace electric service
cords that have become frayed or damaged.
• Unplug the refrigerator before cleaning or making
repairs.
• Repairs should be made by a qualified service
technician.
ATTENTION
This appliance must be properly grounded. See “Grounding the Refrigerator,” page 15.
