CERTIFICAT D' INSTALLATION
INSTALLATION CERTIFICATE
EINBAUBESCHEINIGUNG
Je soussigné,installateur,certifie d'avoir fait personnellement l'installation du dispositif d'alarme
du véhicule ci décrit,conforme aux instructions du constructeur.
The undersigned,qualified installer,attests to have personally fitted the here described Vehicle
Security sistem following the manufacturer instructions.
Der Installateur bestätigt mit seiner Unterschrift, daß die Alarmanlage in dem genannten Fahrzeug
nach Vorgaben Des Herstellers eingebaut wurde.
Signature,Firma,Assinatura,Unterschrift .................................................................
AC 2519 - REV. 00 / 03 / 01
CERTIFICADO DE INSTALACION
El que suscribe, instalador, certifica el haber seguido personalmente la instalación del dispositivo
de alarma del vehículo descrito a continuación, de acuerdo con las instrucciones del fabricante.
CERTIFICATO DI INSTALLAZIONE.
Il sottoscritto,installatore,certifica di aver eseguito personalmente l'installazione del dispositivo
di allarme del veicolo descritto qui di seguito,conformemente alle istruzioni del fabbricante.
No forest has been destroyed to
produce this 100% recycled paper.
by GEMINI TRADING S.r.l. Via Luigi Galvani 12 21020 Bodio Lomnago (VA) Italia
Tel. +39 0332 943211 - Fax +39 0332 948080
E-mail : info@gemini-alarm.com
CERTIFICADO DE INSTALAÇAO
~
O abaixo assinado,instalador,certica que executou pessoalmente a instalaçao do dispositivo
de alarme do veículo descrito a seguir,conforme as instruçoes do fabricante.
~
~
By :
Da :
Par :
Von :
Por :
De :
Sold on :
Venduto il :
Vendu le :
Verkauft am :
Vendido el :
Vendido em :
Type of product :
Tipo di prodotto :
Produktartikel :
Type de dispositif:
Dispositivo ciclo :
Tipo de dispositivo :
Car
Véhicule
Fahrzeug
Veículo
Auto
7208
0682
DESCRIPTION
GEMINI 7090
The system 7090 is an alarm system with sensors, which can be installed on cars with 12 volts battery (negative earth).
FUNCTIONS
- Remote controlled modular alarm with dynamic code.
- Blinker, universal central door locking control, electric windows and sunroof closure for selected vehicles
equipped with “Pack Comfort” system.
- Perimetric and volumetric protection.
- Controls for self-powered and additional siren (continuous or alternate sound).
- LED’s Memory, acoustic arming and disarming (through siren or horn).
- Remote controlled panic function and/or boot opening.
- Electric engine immobilisation.
- Alarm unit functions programmable through the transmitter.
The unit is equipped with two 2-channel transmitters (art. 7208E, frequency 433.92 Mhz) and two electronic keys
(CDE2).
Gemini 7090W
The system 7090W has the same functions of the 7090 but without the electronic keys and the receptacle.
USEFUL SUGGESTIONS FOR THE INSTALLATION
- Connect the positive and negative feeding wire of the alarm system to the battery.
- Connect always the alarm Green-Brown wire to the door pin switch.
- On catalysed vehicles the engine immobilisation must be carried out on the fuel pump and the starter motor.
- Avoid routing connection wires next to interference sources.
- The ultrasonic heads must be positioned at the top of each windscreen pillar and must be pointing at each
opposite diagonal corner away from the facia outlets.
WIRING CONNECTIONS
Disconnect the negative terminal of the battery and only re-connect after the installation is complete.
FUNCTION WIRE COLOR
Earth ðð BROWN
Battery positive terminal ðð RED
Engine immobilisation (max. 10 A) ðð 2 X GREY
Ignition live ðð YELLOW
Direction indicator lights ðð 2 x ORANGE
Door pin switch ðð GREEN-BROWN
Boot/bonnet pin switches ðð GREEN
Positive alarm armed ðð PINK
External sensors inlet ðð GREEN-BLACK
Self-powered siren control ðð BLUE
Additional siren negative control or klaxon ðð YELLOW-BLACK
Comfort positive ðð RED-BLACK
Comfort negative ðð WHITE-BLACK
Central door locking ðð
YELLOW- -BLUE, RED BLUE, YELLOW-GREY,
RED-GREY, YELLOW- -BROWN, RED BROWN
Note: The wiring harness has 3 connectors: connect the two 2-pin connectors to the receptacle of the
electronic key (art. 2390) and the connector with the thermal yellow sheath to the immobiliser. In the
7090W there are two connectors. One 2-pin connector to connect to the LED, the connector with the
thermal Yellow sheath to an immobiliser.
Table of programmable functions through the two-channels transmitter.
ACTIONS ALARM CONDITION VISIBLE
ACTIONS
LED FLASHING AND
SELECTED FUNCTIONS
ALTERNATIV
EACTIONS
POWER OFF Alarm OFF - - -
Turn the ignition
key to ON
Alarm OFF
-
-
-
FEED THE UNIT
7090
Alarm ON - - -
Push on the
transmitter 1 button
within 10 seconds
Access to the Set-up 1
function: Supplementary siren One blinker
flashing
One flashing = continuous
Two flashing = intermittent
Push on the
transmitter 1 button
Access to the Set-up 2
function : acoustic signalling
with supplementary siren
Two blinker
flashing
One flashing = de-activated
Two flashing = activated
Push on the
transmitter 1 button
Access to the Set-up 3
function: Panic and additional
siren or boot opening through
the transmitter
Three blinker
flashing
One flashing = Panic and
additional siren
Two flashing = Boot opening
Push on the
transmitter 1 button
Access to the Set-up 4
function: boot opening while
alarm armed
Four blinker
flashing
One flashing =
While alarm disarmed
Two flashing =
For both functions
Push on the
transmitter 1 button
Access to the Set-up 5
function: vehicle check while
arming the system
Five blinker
flashing
One flashing = de-activated
Two flashing = activated
Push on the
transmitter 1 button
Access to the Set-up 6
function: closure control period Six blinker
flashing
One flashing = 0,5 seconds
Two flashing = 6 seconds
Push on the
transmitter 1 button
Set-up function 7 function:
Passive arming Seven blinker
flashing
One flashing = de-activated
Two flashing = activated
Push on the
transmitter 1 button
Set-up 8 functi voltage drop
sensor Eight blinker
flashing
One flashing = de-activated
Two flashing = activated
Press the
transmitter 2
button to
change the
selected
option.
De-activate
+15 to
memorise the
selected
options and to
exit from User
set-up.
Turn the ignition
key to OFF
Set-up exit, normal working
of the alarm - - -
Recapitulatory table of the programmable functions through the
two-channels transmitter.
Function Manufacturer
function
Programmable
function
1 Additional siren outlet Continuous sound Alternate sound
2 Acoustic signalling De -activated Activated
3 Boot opening with alarm disarmed De -activated Activated
4 Boot opening with alarm armed De -activated Activated
5 Vehicle’s check De -activated Activated
6 Central door locking period 0,5 seconds 6 seconds
7 Passive arming De -activated Activated
8 Voltage drop sensor De -activated Activated
