Side 1/7

For all EU Countries AC XXXX Rev. 04 - 08/07

INSTALLER AND USER

MANUAL

7833

7832

2.0 - GENERAL NOTE FOR INSTALLATION

Dear installer, this manual has been written based on a complete system, therefore some functions,

electrical connections and other can be present in one alarm version and not in another.

In order to avoid repetitions in the manual, before installing the alarm, verify its version and then

follow the suitable instructions.

Furthermore, in order to carry out correctly the various procedures required, please

Device power supply (positive and ground).

Positive under key (+15/54)

Bonnet switch (if not on CAN-BUS line).

CAN-BUS line.

same as 7833 without self-powered battery.

VERIFY VERY

CAREFULLY ALL THE ELECTRICAL CONNECTIONS, IN PARTICULAR THE CONNECTIONS

LISTED BELOW:

GEMINI 7832:

PAGE 02

3.0 - FUNCTIONS

System arming and disarming by the vehicle original remote.

Acoustic arming/disarming signaling (excludable by programming).

Optical signalling (programmabili per inserimento e disinserimento se non presenti sul veicolo).

Perimetric protection.

Volumetric protection (excludable by arming).

Electrical engine immobiliser.

Negative output for additional siren.

Comfort negative output (about 20 seconds) or satellite system control.

LED memory.

Multifunction electronic key (random rolling code, 4,2 milliard of different codes).

Furthermore, in order to indicate to the installer and to the user some particular functions or

connections, an icon symbology has been used, which is briefly described below:

4.0 - OPERATING DESCRIPTION

PAGE 03

4.1 - COMPLETE SYSTEM ARMING

Press the lock button on the original radio control of the vehicle or insert the electronic key into the

specific receptacle.

Arming will be indicated by two short acoustic signals and by a number of optical signals (default

vehicles manufacturer setting).

Indications useful for the installer.

This icon indicates to the installer a diversificated operating, according to the connection

and the programming of the system or it simply provides indications useful for the

installation.

In case the vehicle has not optical signals when is closed, it is possible to activate these

signals by programming.

In this case, when the system is armed, two optical signals will be emitted

Indications useful for the user.

The user with indications for a diversificated use of the system or it simply provides

indications useful for the use.

4.2 - SYSTEM ARMING WITH SENSOR EXCLUSION

This function allows the user to arm the system, with volumetric protection excluded.

To active this function, the system must be disarmed and the ignition switched in “OFF” position and

than proceed as follows:

Turn the vehicle ignition key in “ON” position and wait for one second the status LED switches off

(the drivers door can be open or close at this point).

Introduce the electronic key into the receptacle; t

Turn the vehicle ignition key in “OFF” position.

he status LED will flash for one second and two

short acoustic signals will indicate the exclusion of volumetric sensors

When an immediate re-arming of volumetric sensors is required, switch the vehicle

ignition key in “ON” and “OFF” position.

1.0 - CONTENTS

1.0

2.0

3.0

4.0

5.0

6.0

7.0

8.0

9.0

11.0

12.0

16.0

- CONTENTS..... .......................................................................................................

- GENERAL NOTE FOR INSTALLATION..................................................................

- FUNCTIONS...........................................................................................................

- OPERATING DESCRIPTION.................................................................................

4.1 - Complete system arming......................................................................................

4.2 - System arming with sensor exclusion...................................................................

4.3 - Passive arming.....................................................................................................

4.4 - Arming inhibit time.................................................................................................

4.5 - System armed.......................................................................................................

4.6 - Alarm, inhibit time and alarm cycles.....................................................................

4.7 - System disarming.................................................................................................

4.8 - Emergency disarming by electronic key...............................................................

4.9 - Alarm memory.......................................................................................................

- ELECTRICAL CONNECTIONS..............................................................................

- CONNECTOR TABLE............................................................................................

- .............................................

- COMPLETE ELECTRIC DIAGRAM........................................................................

- SYSTEM PROGRAMMING............... ..................................................

...............................................................................................

........................................................................................

....................................................................

.........................................................................................

.................................................................................................

....................................................................................

................................................................

.....................................

..............................................................................

WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEE) DIRECTIVE....

WARRANTY CONDITIONS...................................................................................

- TECHNICAL DATA...............................................................................................

CONNECTION FOR TURN SIGNALS ACTIVATION

...................

9.1 - Acoustic signalling

9.2 - Impulse optic signalling

9.3 - Optic signalling by arming/disarming

9.4 - System passive arming

9.5 - Negative comfort

9.6 - Satellite system activation

- SYSTEM PROGRAMMING EXAMPLE

VEHICLE CODE PROGRAMMING .....................................................................

- VEHICLE CODE PROGRAMMING EXAMPLE...............

- ADD NEW ELECTRONIC KEY

10.0

13.0

14.0

15.0

PAGE 02

PAGE 03

PAGE 04

PAGE 05

PAGE 06

PAGE 07

PAGE 08

PAGE 09

PAGE 10

PAGE 11

PAGE 12

PAGE 13
