Side 1/4
RGB LED Fresnel with 6.5 in. Lens
LF-RGB-65
RGB LED Fresnel with 6.5 In. Lens - USER MANUAL
1
THANK YOU FOR CHOOSING GENARAY
The Genaray LF-RGB-65 boasts a large 6.5-inch Fresnel lens
to focus its spot-to-flood beam from 25° to 60° for ideal key,
fill, and accent light applications. With a peak intensity of nearly
20,000 lux, this light is perfect for photos, videos, theaters, and
houses of worship. It offers a full-spectrum RGB light and a color
temperature range of 2800 to 6500 K. Accurate color temperature
and green/magenta shift adjustment allows this fixture to
conform to natural or artificial ambient lighting conditions as
well as other light fixtures on the set. Multiple operating modes
help you get the most out of this versatile light, and programmed
effects add realistic and dramatic looks to any scene.
The LF-RGB-65 runs on AC power and is operated by its
simple control panel. It can also be operated via DMX 512
protocols, and DMX input and output ports allow for daisy-
chaining and using this light with a DMX universe.
· Please read and follow these instructions, and keep this manual in a safe place.
· Keep this unit away from water and any flammable gases or liquids.
· Make sure the unit is powered off when plugging it into a power source.
· Use only the correct, recommended voltage.
· Do not attempt to disassemble or repair the equipment—doing so will void the
warranty, and Genaray will not be responsible for any damage.
· Handle the unit with care.
· Do not stare directly at the lights when they are powered on.
· Always use a steel safety cable (not included) when suspending a light fixture or
other assembly.
· Clean the unit with only a soft, dry cloth.
· Images are for illustrative purposes only.
PRECAUTIONS
OVERVIEW
Color knob
Mode selector Confirm button
Dimmer knob
RGB/CCT selector
DMX output
DMX input
Fresnel lock
Locking handle
LCD display
Yoke
4-way barndoors
6.5 in. Fresnel lens
Focusing knob
5/8 in. receiver
3-prong AC power input
Fuse
Power switch
Barndoor clip
RGB LED Fresnel with 6.5 In. Lens - USER MANUAL
2
MOUNTING THE LF-RGB-65
ATTACHING THE YOKE
ATTACHING THE BARNDOORS
POWERING THE LF-RGB-65
Mount the LF-RBG-65 on any heavy-duty light stand with a 5/8-inch baby pin, and turn the locking knob until secure.
Important!
When suspending the fixture from a ceiling mount or boom arm, using a safety cable is recommended.
Use the brake plates, washers, and locking handles to attach the yoke to the LF-RBG-65
Lift the barndoor clip and turn it to the side. Then slide the barndoors into the outer slots.
Raise the barndoor clip and turn it so the slot fits onto the barndoors, and press it down to lock the barndoors in place.
Once the barndoors are attached, rotate them to the desired orientation.
The LF-RGB-65 runs only on AC power. Connect the power cable to the power input socket and a power source, such as a
wall outlet.
The LF-RGB-65 is a multivoltage fixture capable of running on 110–240 V, 50/60 Hz. The included cable has a 120 V, 50 Hz
(North American) plug. To use this fixture with other voltages, you must use a plug adapter (sold separately).
FOCUSING THE FRESNEL
Turn the Focusing knob on the back panel of the light to lengthen or shorten the focal length between the LED display and
the lens.
The light has a focusing range of 25° to 65°.
CONTENTS INCLUDE
· RGB LED Fresnel
· 4-way Barndoors
· Yoke
· Brake plate (×2)
· Washers (×2)
· Ratchet handles (×2)
· AC power cord
· QuickStart guide
