1032C

Smart Active Monitor

Operating Manual

Introduction

Congratulations and a thank you for the purchase of this

Genelec Smart Active Monitor™ (SAM™) system. This manual

addresses the stand-alone setup and use of the 1032C SAM

monitor. This monitors can also be set up and used with the

Genelec Loudspeaker Manager GLM™ and the proprietary

Genelec monitor control network and software, offering much

more versatile acoustic settings and features. Use with the

GLM™ is described in the GLM™ System Operating Manual.

All Genelec SAM systems are designed to integrate easily

into all professional environments, supporting both standard

analog line level audio and AES/EBU formatted digital audio

signals.

The 1032C is suitable for professional monitoring tasks

demanding high precision and reliability of monitoring.

The Directivity Control Waveguide™ (DCW™) technology

provides excellent frequency balance even in difficult acoustic

environments.

Each monitor is supplied with a mains cable, one 5 m GLM

network cable and an operating manual.

Energy saving Intelligent Signal Sensing (ISS™) can be turned

on to put the monitor automatically into a deep sleep state

where the product consumes less than one Watt of power. Upon

sensing an input signal the monitor automatically wakes up to

full operation. The wait until entering the ISS power save can be

configured using the GLM software. When the ISS is active you

can have your monitoring system ready for action at all times.

System setup using GLM™ Control

Network

Although the 1032C can be used without the GLM™ software

and control network, they only reach their full potential when

set up and calibrated using the GLM™ software. Genelec

Loudspeaker Manager GLM™ and the proprietary Genelec

monitor control network and software offer automated acoustic

equalization and alignment for any reproduction system from

simple stereo to very complex 3D immersive audio setups

including also one or more subwoofers. GLM setup is fast and

accurate. The settings can be controlled with a computer or be

permanently stored in the monitors to make the setup available

at all times even when a computer is not in use. Genelec

recommends setting up SAM monitoring systems using GLM.

You can find a detailed description of the setup and the use of

GLM™ in the GLM™ System Operating Manual.

The setup is fast and consists of the following steps:

• Connect a CAT5 (RJ45) cable between each monitor (and

subwoofer) and finally to the control network input of the

GLM Adapter device (see Figure 1).

• Connect the GLM Adapter device to computer USB

connector.

• Using a microphone stand, place the Genelec measurement

microphone at the listening location with the microphone

pointing upwards and the microphone top at the height of the

engineer’s ear. The microphone is a part of the GLM User Kit.

• Connect the microphone cable to the microphone input in

the GLM Adapter device.

• Download the GLM software at the Genelec web site (www.

genelec.com).

• Install the GLM software and follow the instructions in the

software to measure and set up your monitors.

• If you plan to not use a computer for controlling the

monitors, use the GLM software to write the setting into the

monitors (use menu item “Store | Store the Current Group

Settings…”).

While the GLM network is disconnected the settings stored

using the Genelec Loudspeaker Manager software can be

selected in use by setting the STORED switch ON.

Setup without using the GLM

When GLM is not available, you can use the settings on the

monitor for system setup. These settings are limited but provide

the basic acoustical calibrations and input selection. To use this

method, set the STORED switch OFF.

Produkt Specifikationer

Mærke:	Genelec
Kategori:	Højttaler
Model:	1032 CPM
