Side 1/12

Helium100

www.genesis-zone.com

Quick installation guide

2.0 USB speakers

SPECIFICATION

• Power Output

• Speaker diameter

• Frequency response

• Impedance

• Cable length beetwen each speaker

• Cable length

10 W

75 mm

120 Hz - 20 kHz

2 Ω

150 cm

PACKAGE CONTENT

PAIRING NEW DEVICE WITH THE SPEAKERS

BUTTONS FUNCTIONALITY

• Speakers Genesis Helium 100BT

• Quick installation guide

If your speakers were previously connected to another source device, you need to turn o the Bluetooth function of that device.

Otherwise, your speakers will connect to that device automatically and you cannot pair them with any other device.

1. Press the M button to switch the speaker into the Bluetooth mode. The speaker will inform that it is ready to connect with

a repeated audio signal while the light ashes alternately in red and blue.

2. Turn on the Bluetooth function of the device you want to pair with your speaker and set that device to the pairing mode.

3. Select “Helium 100BT” speakers from the list on your device.

4. The speakers conrm the connection with a short audio signal while the notication light is red.

From now the devices will pair automatically if they are in near proximity of each other and the Bluetooth mode is on.

warranty

• 2 years limited manufacturer warranty

requirements

SAFeTY information general

• Use as intended.

• Non-authorized repairs or disassembly voids the warranty

and may damage the product.

• Dropping or hitting the device may lead to device being

damaged, scratched or awed in other way.

• Do not use the product in low and high temperatures, strong

magnetic elds and damp or dusty surroundings.

• Improper usage may break the device.

• The safe product, conforming to the EU requirements.

• The product is made in accordance with RoHS European standard.

• The WEEE symbol (the crossed-out wheeled bin) using indicates that this

product in not home waste. Appropriate waste management aids in

avoiding consequences which are harmful for people and environment

and result from dangerous materials used in the device, as well as

improper storage and processing. Segregated household waste collection

aids recycle materials and components of which the device was made.

In order to get detailed information about recycling this product please

contact your retailer or a local authority.

InstalLation

• Connect the device to the

minijack port and USB.

• PC or compatible device with a minijack port

• To turn the speakers on/o,

hold the button for 3 seconds.

• Single Press - Change the mode

• Long Press - Turn the backlight on/o

• Single Press - Volume [-]

• Long Press - Previous track

• Single Press - Volume [+]

• Long Press - Next track

Frequency range: 2402 - 2480 MHz

Maximum radio-frequency power transmitted: -3,23 dBm

Produkt Specifikationer

Mærke:	Genesis
Kategori:	Højttaler
Model:	Helium 100BT RGB
Tænd-/slukkontakt:	Ja
Bredde:	85 mm
Dybde:	105 mm
Højde:	200 mm
Produktfarve:	Sort, sølv
Bluetooth:	Ja
Udgangseffekt (RMS):	10 W
Antal USB 2.0-porte:	1
Udgange til hovedtelefoner:	1
Volumenkontrol:	Knapper
Husmateriale:	Acrylonitrile butadiene styrene (ABS), Metal
Bluetooth-version:	5.0
Anbefalet brug:	Universel
Forbindelsesteknologi:	Kabel & trådløs
Lyd-output kanaler:	2.0 kanaler
Strømkilde:	USB
Tilslutning af hovedtelefoner:	3,5 mm
Bluetooth-område:	10 m
Satellithøjttalere RMS-effekt:	10 W
Antal satellithøjttalere:	2
Satellithøjttaler type:	1-vejs
Frekvensområde for satellithøjttaler:	120 - 20000 Hz
Forstærkningsenhed inkluderet:	Ingen
Strømkabellængde:	1.5 m
Basrefleks:	Ja
