M800 User Guide Document: M800-3

-----------------------------------------------------------------------------------------------------------------------------------------------

M800 Edge Blending processor User Guide

The absolute opposite of ordinary

Input: up to 4096*2160 @60Hz 4:4:4 full color sampling

Output: 2048*1080 @60Hz

New generation Warp & Edge blending engine

M801 (1 CH), M802 (2 CH), M803 (3 CH), M804 (4 CH)

M800 User Guide Document: M800-3

-----------------------------------------------------------------------------------------------------------------------------------------------

Table of Contents

Disclaimer/Copyright Statement.......................................................................................................... 3

Warranty/RMA………………………………………………………………………………………………… 3

FCC/CE Statement............................................................................................................................... 3

Introduction……………………………………………………………....................................................... 4

Specification…………………………………………………………………………………………………… 6

Functions and Features....................................................................................................................... 7

1. Content in the packing box............................................................................................................ 10

2. Basic operation & settings………………………………………………………………………………. 10

2.1. Connecting the Inputs.........………………………………………….…..................................... 10

2.2. Connecting the Outputs....................................................…………....................................... 10

2.3. Input / Output Selection & LED indicators.........…………………………………………………. 11

2.4. System Connection and Power On.......…………………………………………………………… 13

2.5. HDMI Loop Out for daisy chain connection..............……………….………………………….... 14

2.6. System Settings: Box ID, RS232, Ethernet............................................................................. 14

2.7. How to use IR Remote Controller........................................................................................... 16

2.8. Full screen and native aspect ratio………………………………………………………………… 17

2.9. Image rotation and flip………………………………………………………………………………. 17

2.10. Global Color adjustment…………………………………………………………………………… 18

2.11. OSD Lock and unlock……………………………………………………………………………… 19

2.12. System synchronization…………………………………………………………………………… 19

2.13. Dual window display—PIP/POP (Picture in picture & side by side) …………………………. 20

2.14. Image Orientation (Flip & Rotation) ……………………………………………………………… 22

3. Project plan and preparation for edge blending………………………………………………………… 23

3.1. Determine source signal resolution………………………………………………………………... 23

3.2. Determine overlap region size and pixels…………………………………………………………. 23

3.3. Relation between Overlap pixels and geometry alignment accuracy…………………………. 24

3.4. Get installation data from VNS Excel Spread Sheet……………………………………………… 25

3.5. Apply Spread Sheet data for projector installation and GeoBox setting………………………. 27

3.6. Projector settings before edge blending…………………………………………………………… 28

3.7. GeoBox settings before edge blending…………………………………………………………… 29

4. Geometry Alignment………………………………………………………………………………………. 29

4.1. Select the right Grid Pattern for geometry alignment……………………………………………. 29

4.2. Grid pattern pixel size selection……………………………………………………………………. 30

4.3. Geometry alignment………………………………………………………………………………… 31

4.3.1. Geometry alignment through remote controller……………………………………………. 32

4.3.2. Activate grid pattern…………………………………………………………………………… 32

4.3.3. [2x2] 4 corner geometry alignment…………………………………………………………… 32

4.3.4. [3x3], [5x3], [9x5] warp alignment……………………………………………………………. 33

4.3.5. Linearity grid line adjustment…………………………………………………………………. 35

4.3.6. Corner [Wall] geometry adjustment…………………………………………………………… 36

4.3.7. [Gwarp3] PC Tool ...……………………………………………………………………………. 38

5. [Video Wall] settings………………………………………………………………………………………. 39

5.1. [Zoom]: split the signal source……………………………………………………………………… 40

Produkt Specifikationer

Mærke:	GeoBox
Kategori:	Processor
Model:	M801
Bredde:	303 mm
Dybde:	180 mm
Højde:	45 mm
Vægt:	1800 g
Produktfarve:	Sort
Indbygget skærm:	Ingen
HDCP:	Ja
Ethernet LAN:	Ja
Certificering:	CE/FCC/RoHS
HDMI-version:	2.0b
DisplayPort-version:	1.2a
Antal DisplayPorts:	1
Antal VGA-porte (D-sub):	1
Antal RJ-45-porte:	1
Antal HDMI-indgangsporte:	2
Antal HDMI-udgangsporte:	1
RS-232/422 stik:	Ja
