AORUS LIQUID COOLER Quick Installation Guide

Installing the AORUS LIQUID COOLER

For Intel motherboard:

12QM-LIQ248-2NR

1 x AORUS LIQUID COOLER 360

1 x AORUS LIQUID COOLER 280

1 x AORUS LIQUID COOLER 240

Package contents:

1 x Intel Backplate 1 x Intel Mounting Bracket 1 x AMD Mounting Bracket

4 x LGA 115X/1200/1366

Standoff Screws

4 x LGA 2011/2011-3/2066

Standoff Screws

8 or 12 x UNC 6-32x30mm

Fan Screws

4 x Thumbscrew caps

4 x AM4 Standoff Screws

16 or 24 UNC 6-32x8mm

Randiator Screws

8 or 16 x Washers

For LGA 20XX socket

For LGA 1366

socket

For LGA 115X/1200

socket

For LGA 115X/1200/1366 socket

AORUS LIQUID COOLER 360:

3 x 12cm fans

AORUS LIQUID COOLER 280:

2 x 14cm fans

AORUS LIQUID COOLER 240:

2 x 12cm fans

8 or 12 x Metal gaskets

for fan

Installing the AORUS LIQUID COOLER

Cable Connection

GIGA-BYTE TECHNOLOGY CO., LTD.

Address: No.6, Baoqiang Rd., Xindian Dist., New Taipei City 231, Taiwan

TEL: +886-2-8912-4000, FAX: +886-2-8912-4005

Tech. and Non-Tech. Support (Sales/Marketing) : https://esupport.gigabyte.com

WEB address (English): https://www.gigabyte.com

WEB address (Chinese): https://www.gigabyte.com/tw

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE's prior written permission.

For product-related information, check on our website at: https://www.gigabyte.com

For AMD motherboard:

USB 2.0 Cable

LED Headers

Fan Headers

SATA Power

Produkt Specifikationer

Mærke:	Gigabyte
Kategori:	CPU kølere
Model:	AORUS Liquid Cooler 280
Type:	Alt-i-en væskekøler
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Harmoniseret systemkode (HS):	84733080
Belysningsfarve:	Flere
Antal blæsere:	2 blæser(e)
Passende til rumtype:	Processor
Ventilator diameter:	140 mm
Maksimal luftstrøm:	100.16 kubikfod/min.
Ventilatorens støjniveau (min.):	22.3 dB
Ventilatorens støjniveau (maks.):	44.5 dB
Køler materiale:	Aluminium
Blæser, hastighed (maks.):	2300 rpm
Understøttede procesorsokler:	LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1366 (Socket B), LGA 2011-v3 (Socket R), LGA 2066, Socket AM4, Socket TR4
Understøttelse af puls-bredde modulering (PWM):	Ingen
Køler bredde:	315 mm
Køler dybde:	143 mm
Køler højde:	30 mm
Maksimalt lufttryk:	5.16 mmH2O
Vandblokerende materiale:	Kobber
Ventilatorlejeteknologi:	Dobbelt kugleleje
Belysning LED:	Ja
Pumpe bredde:	80 mm
Pumpe dybde:	80 mm
Pumpe højde:	60 mm
Ventilatorens middeltid til fejl (MTTF):	70000 t
Ventilatorstyring:	Ja
