GA-946GM-DS2/S2 (rev. 2.0)
Intel® CoreTM 2 Extreme quad-core / CoreTM 2 Quad /
Intel® CoreTM 2 Extreme dual-core / CoreTM 2 Duo /
Intel® Pentium® Processor Extreme Edition /
Intel® Pentium® D / Pentium® 4 LGA775 Processor Motherboard
User's Manual
Rev. 2002
12ME-946GMDR-2002R
* The WEEE marking on the product indicates this product must not be disposed of with user's other household waste
and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!!
* The WEEE marking applies only in European Union's member states.
Moth erb oard
GA-946GM-DS2/
GA-946GM-S2 (rev. 2.0)
Oct. 20, 2006
Oct. 20, 2006
Mot h erbo ard
GA-946GM-DS2/GA-946GM-S2 (rev. 2.0)
Copyright
© 2006 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in the manual are legally registered to their respective companies.
Notice
The written content provided with this product is the property of Gigabyte.
No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any
means without Gigabyte's prior written permission. Specifications and features are subject to
change without prior notice.
Product Manual Classification
In order to assist in the use of this product, Gigabyte has categorized the user manual in the
following:
For detailed product information and specifications, please carefully read the
"Product User Manual".
For detailed information related to Gigabyte's unique features, please go to "Technology
Guide" section on Gigabyte's website to read or download the information you need.
For more product details, please click onto Gigabyte's website at www.gigabyte.com.tw
- 8 -
Block Diagram
(Note) To use a DDRII 667 memory module on the motherboard, you must install a 1066/800 MHz
FSB processor.
Center/Subwoofer Speaker Out
Line-Out
MIC
CPU CLK+/-(133/200/266 MHz)
PCI Express x16
Host
Interface
DDRII 667(Note)/533 MHz DIMM
IT8718
Line-In
2 PCI
PCI Bus
SPDIF In
SPDIF Out
8 USB
Ports
Dual Channel Memory
Side Speaker Out
Surround Speaker Out
LAN
PCI CLK (33 MHz)
CODEC
PCIe CLK
(100 MHz)
Intel®
946GZ
Intel®
ICH7
LGA775
Processor
4 SATA 3Gb/s
ATA 33/66/100
IDE Channel
BIOS
PS/2 KB/Mouse
VGA
COM Ports
LPT Port
Floppy
1 PCI Express x1
PCI Express Bus
PCIe CLK
(100 MHz) RTL8111B
RJ45
x 1 x 1
